Summary of Contents for Kystar KS604
- Page 1 Sending box Version: v1.2 Release Date: November 2021 Manual...
- Page 2 version number Change details release time V1.0 first release 2014.07.01 V1.1 change cover 2021.10.25 V1.2 Correct size data 2021.11.18...
-
Page 3: Certification Instructions
Statement Thank you for using our company's products. The copyright of this manual belongs to our company, and any content of this document is strictly prohibited to be reproduced, transmitted, distributed and stored in any form without the written permission of our company. The company reserves the right to modify and improve any product features described in this document without prior notice. -
Page 4: Safety Precautions
Safety Precautions For your safety, please read this section carefully. Power supply The power supply for normal operation of this device is 100~220V AC, please make sure to use this product within this voltage range. High voltage This equipment contains high voltage components. Non-professionals do not disassemble This device is not equipped with maintenance parts for users to maintain and use by themselves, please do not open the case to operate... - Page 5 Catalog 1. Product introduction........................ 1 2.Panel introduction..........................1 3.Port Specifications........................2 4.Installation Notes..........................3 4.1Sending card installation......................3 4.2 Connect method........................4 5.debug step............................4...
-
Page 6: Product Introduction
Sending box KS604 manual 1. Product introduction KS604 is a management end device for sending cards. It is an independent management unit, which is convenient for the management of power supply and signals on the site of multiple sending cards, and conforms to international and industry standards. -
Page 7: Port Specifications
4 two-network port sending cards into two 4-network port sending cards for use KS604 can be compatible with 4 two network port sending cards of mainstream brands on the market, and has an independent power supply unit, which is convenient for on-site power supply and signal management of multiple sending cards. -
Page 8: Installation Notes
Remove the screws on the left and right sides of the KS604, remove the hexagonal screws of the sending card, remove the front cover of the sending card, and then put ES2 into the KS604 box. After the installation is... - Page 9 Sending box KS604 manual Install sending card 4.2 Connect method The out of Video Processor is connected to the DVI input of the sending card box, and the DVI output is connected to the DVI input of the sending card.
- Page 10 Sending box KS604 manual It is recommended to use expert screen adjustment for debugging. The wizard screen adjustment will cause slow debugging due to the large number of network ports and receiving cards. 2、Receiving card interface: ①Enter the module selection to see if there is a file matching the unit board, if not, select the smart setting ②Single card loading: Input the loading points of each receiving card.
- Page 11 Sending box KS604 manual...
