Summary of Contents for Union Community MCP-040
- Page 1 Installation & Wiring Guide Installation guide for MCP-040 V2.0 with VSR20D & EB030 Doc. Ver. : V2.0 2014.10.23 R&D Center Union Community Co., Ltd.
- Page 2 1. Power Connector connection BAT(-) Backup Battery Interface BAT(+) DC 15V OUT DC 15V OUT 12V G 12V G 12V G PWR+ PWR- DC 15V 6A DC 5V OUT DC 15V OUT Power Adapter Installation for MCP-040 V2.0...
- Page 3 Switch Setting III [ RS485 T_Resistor Selection ] JP151 : ON [ 120ohm termination resistor ] OFF [ Open the termination resistor ] JP152 : ON [ 120ohm termination resistor ] OFF [ Open the termination resistor ] JP201~JP204 JP205~JP208 Lock Type Switch Installation for MCP-040 V2.0...
- Page 4 3. Connection of Wires to terminal blocks D11 OUT1 OUT2 D13 OUT5 OUT6 RDRA RDRB EXPA EXPB BELL+ BELL- D14 OUT7 OUT8 D12 OUT3 OUT4 PWR+ PWR- Installation for MCP-040 V2.0...
- Page 5 VSR20D EXPB- EXPA+ VSR20D RDRB- RDRA+ VSR20D J252 or J254 One MCP-040 can be connected with VSR20D readers max 8ea in parallel 4:Blue : 485B- 3:Green : 485A+ 2:Black : GND JP151 1:RED : +12V JP152 RS-485 Termination Resistor Select S/W : SW151 Installation for MCP-040 V2.0...
- Page 6 Each VSR20D reader should be set the different RS485 ID with DIP switch when they are connected to MCP in parallel 485 ID = 4 485 ID = 2 485 ID = 1 485 ID = 6 485 ID = 5 485 ID = 3 485 ID = 0 485 ID = 7 Installation for MCP-040 V2.0...
- Page 7 6. Connecting Dead-Bolt Type Door Lock (Fail Safe) J251 LOCK4 NO/NC NO/NC : Lock (+) NO/NC Black : Lock (-) Green : Door Monitor (NO) NO/NC LOCK3 Gray : Ground (Door Status J251 Com) Z4/Z8 Z3/Z7 Z2/Z6 LOCK2 Z1/Z2 LOCK1 Installation for MCP-040 V2.0...
- Page 8 7. How to do pairing each lock to each reader Do pairing between 4 locks to 12 readers on MCP-040 from the Terminal Setup Option on UNIS 1> Select the reader among the readers are connected to MCP-040 2> Select the lock number among the locks are connected to MCP-040 3>...
- Page 9 8. How to connect four EB030 units to MCP-040 J252 or J254 J253 Red : 12V Black : GND Green : NO Brown : COM EB-030 Installation for MCP-040 V2.0...
- Page 10 9. How to do pairing each EXIT button to each lock Do pairing between 4 EXIT buttons to 4 locks on MCP-040 from the Terminal Setup Option on UNIS 1> Select the tab “In/Output” 2> Select the Exit button number among the buttons are connected to MCP-040 2>...
