Summary of Contents for Euromedics WL-2103A
- Page 1 Transcutaneous Electrical Nerve Stimulation Device REF WL-2103A/S2646 Operation Manual Read Before Using...
-
Page 2: Table Of Contents
TABLE OF CONTENTS What Is Pain………………………………………………… 1 What Is TENS……………………………………………… . 1 Indications and Contraindications………………………… 2 Warnings and Precautions………………………………… 3 About This Device………………………………………….. 5 Using Controls……………………………………………… 6 Mode Functions…………………………………………….. 7 Electrode Selection and Care…………………………….. 8 Tips For Skin Care…………………………………………. 8 Connecting the TENS device…………………………….. -
Page 3: What Is Pain
INTRODUCTION TO TENS What is Pain? Pain is the body’s warning system. Pain is important because it signals an unusual condition in the body and alerts us before additional damage or injury can occur. However, long-lasting, persistent pain, often called chronic pain, once diagnosed serves no apparent purpose. -
Page 4: Indications And Contraindications
INDICATIONS AND CONTRAINDICATIONS Read the operation manual before using TENS INDICATIONS Transcutaneous Electrical Nerve Stimulation (TENS) may be used, with a physician’s prescription, for the symptomatic relief and management of chronic (long term) pain. CONTRAINDICATIONS ● Patients with implanted electronic devices(for example, a pacemaker) or metallic implants should not undertake TENS treatment without first consulting a physician. -
Page 5: Warnings And Precautions
WARNINGS AND PRECAUTION WARNINGS ● TENS devices must be kept out of reach of children. ● The safety of TENS devices for use during pregnancy or delivery has not been established. ● TENS is not effective for pain of central origin (headaches). ●... - Page 6 PRECAUTIONS/ADVERSE REACTIONS ● Isolated cases of skin irritations may occur at the site of electrode placement during long term application. ● Effectiveness is highly dependent upon patient selection by a person qualified in the management of pain patients. ● Skin irritation and electrode burns are potential adverse reactions. ●...
-
Page 7: About This Device
ABOUT THIS DEVICE Your TENS device is a battery operated device that includes two controllable output channels. This TENS device creates electrical impulses whose amplitude, duration, and modulation can be altered with the controls or switches. The TENS dial controls are very easy to use and the slide cover prevents accidental changes in settings. -
Page 8: Using Controls
UNIT CONTROLS Panel Cover A cover conceals the controls for Pulse Width, Pulse Rate, Mode Selector and Modulation Selector. The TENS dial controls are very easy to use and the slide cover protects accidental changes in settings. Intensity The intensity knobs located on the top of the unit affect the strength of the stimulation and also function as ON/OFF controls. -
Page 9: Mode Functions
Mode Functions Burst (B) releases individual bursts twice per second, pulse width is adjustable and the pulse rate is set at 100Hz per second. Continuous (C) stimulation is delivered continuously at the settings determined by intensity, rate, and width knobs. Modulation (M) pulse width decrease from its setting by 60% and maintain the decreased width for 2 seconds before returning to the original width setting, which is maintained for 3.5 seconds. -
Page 10: Electrode Selection And Care
ELECTRODE SELECTION AND CARE Your physician/clinician should decide which type of electrode is best for your condition. Follow application procedures outlined in electrode packaging will provide instructions for care, maintenance and proper storage of your electrodes. TIPS FOR SKIN CARE Good skin care is important for comfortable use of your TENS device. -
Page 11: Connecting The Tens Device
CONNECTING THE TENS DEVICE 1. Prepare the skin as previously discussed and according to instructions provided with your electrodes. Before attaching the electrodes, identify the area which your clinician has recommended for electrode placement. 2. Connect the lead wires to the electrodes before applying the electrodes to the skin. -
Page 12: Battery Information
Changing the Battery When the yellow indicator light located on the front of the unit does not remain lit once the unit is turned on, the battery should be replaced with a new battery. When the yellow indicator light on the front of the unit does not remain lit once the unit is turned ON, the battery should be replaced with a newly charged battery. -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS Channel: Dual, isolated between channels Modes of Operations: Burst, Continuous, Modulation Pulse Intensity: Adjustable 0-80mA peak into 500 ohm load each channel, constant current Pulse Rate: 2Hz-150Hz (adjustable) Pulse Width: 30uS-260uS (adjustable) Timer: Continuous, 30 min., 60 min. Burst Mode: Burst consists 2 burst per sec at 100 Hz Wave Form:... -
Page 14: Description Of Symbol
Description of Symbols : (i) There are a number of technical symbols on your unit explained as follows: This symbols means “ Serial number “ This symbols means “ Attention, consult the accompanying documents” This symbols means “ Manufacturer “ This symbol means type BF equipment;... -
Page 15: Electromagnetic Compatibility
Electromagnetic Compatibility ● The device complies with current specifications with regard to electromagnetic compatibility and is suitable for use in all premises, including those designated for private residential purposes. The radio frequency emissions of the device are extremely low and in all probability do not cause any interference with other devices in the proximity. - Page 16 Declara�on – electromagne�c immunity The EMS Electrical S�mulator system is intended for use in the electromagne�c environment specified below. The customer or the user of the EMS Electrical S�mulator system should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level...
- Page 17 Declaration – electromagnetic emissions and immunity – for EQUIPMENT and SYSTEMS that are use in the professional healthcare facility environment or in the home healthcare environment The EMS Electrical S�mulator declara�on – electromagne�c immunity The EMS Electrical S�mulator system is intended for use in the electromagne�c environment specified below.
- Page 18 Recommended separa�on distances between portable and mobile RF communications equipment and the ME equipment The EMS Electrical S�mulator is intended for use in an electromagne�c environment in which radiated RF disturbances are controlled. The customer or the user of the EMS Electrical S�mulator can help prevent electromagne�c interference by maintaining a minimum distance between portable and mobile RF communica�ons equipment (transmi�ers) and the EMS Electrical S�mulator as recommended below, according to the maximum output power of the communica�ons equipment.
-
Page 19: Warranty
The distributors reserve the right to replace or repair the unit at their discretion. Manufactured for: Independent Living Specialists Pty Ltd. Free Call : 1300 008 267 Ilsau.com.au Well-Life Healthcare Limited 6F., No. 168, Lide St., Jhonghe District, New Taipei City, 23512 Taiwan EUROMEDICS GmbH Beckers Kreuz 13, D-53343 Wachtberg, Germany IM-21-047 RevC20...
