Summary of Contents for COX 2M OBDLRA1
- Page 1 OBDLRA1 OBD II Based Vehicle Telemetry and Location User’s Manual...
- Page 2 Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment Federal Communication Commission Statement (FCC, U.S.) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 Contents Frequency Table ............................ 4 Device Specifications ..........................5 Installation Instructions .......................... 6...
- Page 4 Chip SX1272 nRF52 Modulation LoRa: Chirp Spread Spectrum BT: GFSK TX Frequency 902.3-927.7MHz 2402-2480 GHz Version BLE 5 Antenna Gain 2dBi -1.5dBi Temperature (operating) -30C to 80C -30C to 80C Frequency Table...
- Page 5 Device Specifications Frequency 902-928MHz Antenna gain 2dBi RF sensitivity -137 dBm Battery type Lithium Iron Phosphate Rechargeable - 300mAh Physical security Proprietary Universal Locking Mechanism GPS Connectivity Tri-mode GPS/Galileo GLONASS, Geofencing and IMESS/QZSS optimization. 72 Channel Network protocol LoRa, Bluetooth Low Energy 5 Accelerometer 3 axis 2g/4g/8g/16g ultra low power MEMS Temperature range...
- Page 6 Installation Instructions By using user manual of the vehicle find the OBD connector on your car Typically OBD plug can be located: • Near the breaks unit • Near the fuse box • Under the dashboard • In the middle console Plug the connector into the Check that the device is fully Lock the Secondary Lock to...
