  • Page 1 OBX-4770-P MODEL: Owner’s Manual Weatherproof Televisions IMPORTANT: Please read this owners manual before starting or operating the equipment.

  • Page 3: W Elcome

    Congratulations on purchasing your new outdoor weather-proof television. We welcome you to our SkyVue family. To gain the full potential of your new SkyVue Outdoor Television, please read carefully the instructions within this document. There is a wealth of relevant information to get started and fully utilize all of the unique capabilities of your new SkyVue Outdoor Television.

  • Page 5: Important Information

    SKY4230 & SKY4630 OBX-4770-P Model : OBX - SERIES OPTICALLY BONDED OUTDOOR LED TELEVISION OWNER’S MANUAL LED TELEVISION ENGLISH OPERATION MANUAL IMPORTANT: To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space provided. The numbers are located at the rear of the TV.
  • Page 6 1439 Dave Lyle Blvd Unit 15 Rock Hill, SC 29730 TEL: 1-877-475-9883 Visit us online at www.skyvue.com INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: S Afety I Nformation

    19) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer. Operator’s Manual - Model OBX-4770-P afety nformatIon...
  • Page 8 Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers inside the plastic may cause the cabinet to deform and cause the paint to peel off. ® All Rights Reserved. 2015 SkyVue 2012 SKYVUE 2012 SKYVUE LC-60LE632U_70LE732U_E_01.indd 4...
  • Page 9 More than 2,200 companies enjoy the benefi ts of CEA membership, including legislative advocacy, market research, technical training and education, industry promotion and the fostering of business and strategic relationships Operator’s Manual - Model OBX-4770-P afety nformatIon 2012 SKYVUE 2012 SKYVUE...
  • Page 10 Do not submerge SkyVue Outdoor TV’s in water: The SkyVue Outdoor TV’s will resist water exposure from normal rain, sprinklers, garden hoses, etc.; however, it is not designed to withstand pressure washers, high-pressure water jets, hurricane-type weather or be submerged in water.

  • Page 11: Table Of Contents

    Table of Contents ..........................1 elcOme ......................3 mpOrtant nfOrmatIOn ....................... 4 afety nfOrmatIOn tV I ......................... 10 nStallatIOn ..................11 anel omPonent ouRCe ....................12 anel onneCtionS ....................15 etaChable PeakeRbaR ....................24 anual OntrOlS ..................24 rOnt anel IghtS and enSOrS ......................
  • Page 12 After unpacking the SkuVue Outdoor TV, please make sure that the following items are included in the carton and that they are in good condition. If items are damaged or missing, contact your dealer immediately. Model OBX-4770-P Front View Model OBX-4770-P Back View...

  • Page 13: Tv I Nstallation

    1. The Internal Component Source is inside the Component Cover located on the back of the unit. 2. Loosen the 6 thumbscrews located on the back cover of your SkyVue TV , and slide the cover toward the left to reveal the Component Source.

  • Page 14: Rear Panel Connections

    PC Audio IN - This connection port is for people who want to provide audio to the TV when using a PC or a DVI video device. Use a 3.5mm mini-jack audio cable (headphone jack) to provide audio for a HDCP enabled DVI video device or PCs with VGA or DVI connection. (Continued on next page) ® All Rights Reserved. 2015 SkyVue...
  • Page 15 13. Digital Audio Out - This type of jack is used for the digital audio inputs and/or outputs on A/V components such as receivers, CD players, DVD players, and more. Coaxial digital jacks are also sometimes found on higher-end PC soundcards for digital audio input and output. Owners’s Manual - Model OBX-4770-P TV I & C nsTallaTIon onneCTIons...
  • Page 16 Switching Inputs: Cable Name Cable End Images Your SkyVue TV offers several options when connecting your devices to the TV. The chart below will help you understand which input you select for each of the connections. HDMI or HDMI-DVI Connections...

  • Page 17: D Etachable S Peakerbar

    6. Plug in power cord only after all other connections are made. SPEAKER BAR Do Not Remove Figure 1 Owners’s Manual - Model OBX-4770-P TV I & C nsTallaTIon onneCTIons...
  • Page 18 Installation / Mounting Notes Figure 1 Figure 2 Remove for Speakerbar Do Not Remove Figure 3 Figure 4 Figure 5 ® All Rights Reserved. 2015 SkyVue...
  • Page 19 TV might lose picture or sound. This TV will turn off automatically if there’s no signal present for more than 15 minutes. Owners’s Manual - Model OBX-4770-P TV I & C nsTallaTIon...
  • Page 20 Refer to the DVD/Blu-ray player’s manual to make sure the DVD/Blu-ray player is configured to output correctly to the TV. This TV will turn off automatically if there’s no signal present for more than 15 minutes. ® All Rights Reserved. 2015 SkyVue...
  • Page 21 HDMI 3. This TV will turn off automatically if there’s no signal present for more than 15 minutes. Located on Back of TV Owners’s Manual - Model OBX-4770-P TV I & C nsTallaTIon onneCTIons...
  • Page 22 TV. 3. Connect the white color connector to both your DVD/Blu-ray player and Composite’s white connector port off the back of your TV. (Continued on next page) Located on Back of TV ® All Rights Reserved. 2015 SkyVue...
  • Page 23 If your receiver is making static noises when receiving Bit Stream, you must use the PCM option instead. Refer to the receiver’s manual to make sure the receiver is configured to receive signals correctly from the TV. Located on Back of TV Owners’s Manual - Model OBX-4770-P TV I & C nsTallaTIon onneCTIons...
  • Page 24 Connecting with RCA Audio Analog (For use when Skyvue Speakerbar is not in use) 1. Make sure the power of the TV and your receiver is turned off. 2. Obtain a 3.5mm stereo/audio cable (if your amplifier audio connection re- quires RCA audio out jacks you will need to obtain an 1/8”...
  • Page 25 The VGA port of the TV features a power saving mode which will automatically turn off the TV if there is no signal provided for more than 15 minutes. Owners’s Manual - Model OBX-4770-P TV I & C nsTallaTIon onneCTIons...

  • Page 26: M Anual C Ontrols O N Tv

    AC outlet that is in compliance with local regulations. Manual Controls Panel The Side or Bottom Control Panel can be found by reaching your hand on the underside of the SkyVue logo . Location of Manual Controls Panel This button switches between the different sources of the TV. When the On-Screen Display (OSD) is active, this INPUT button acts as the enter button and confirms the menu selection.

  • Page 27: Remote Control Guide

    It is designed to operate the Freeze - Push this to temporarily freeze picture on the screen SkyVue TV, Satellite, Cable Box, and SRND SOUND - Activate enhanced sound mode DVD Players. Sleep - Push to activate the sleep timer...

  • Page 28: On-Screen Display (Osd) Functions

    Vol+ and Vol- to select a choice. Vol(-) - This button decreases the volume and functions as right direction in the OSD. If the OSD is active, use Vol+/Vol- to select a choice. ® All Rights Reserved. 2015 SkyVue...

  • Page 29: On-Screen Display Menu

    Contrast Zoom Mode Brightness 3D Noise Reduction Sharpness Backlight Tint Color Audio Menu This menu manages Audio functions including: Equalizer mode Equalizer frequencies MTS Stereo mode Audio Language Digital Output type Surround Sound Owner’s Manual - Model OBX-4770-P creen iSplayS...

  • Page 30: Time Menu

    Closed Caption Ambient Light Sensor Restore Default Ambient Sensor Value Setup Wizard Auto Backlight Floor Software Update Backlight Sensor Floor Lock Menu This menu manages Lock functions including: System Lock Change Password Input Block ® All Rights Reserved. 2015 SkyVue...

  • Page 31: Adjusting On-Screen Displays - Channel Menu

    To delete a channel from your favorites list, press the buttons to highlight the channel. Press the button delete the channel from your favorites. The red heart next to the channel will disappear. Owners’s Manual - Model OBX-4770-P djusting creen isplAys...
  • Page 32 Channel No. item of the menu. The longer the horizontal bar appears, the better the signal strength. If the signal strength is extremely poor, no meter will appear and the menu will simply say Bad. ® All Rights Reserved. 2015 SkyVue...

  • Page 33: Adjusting On-Screen Displays - Picture Menu

    Tint adjustment is not supported on this model. Color Press the buttons to highlight the Color adjustment, then use to adjust color satura- tion. This control is active only when Personal picture mode is selected. Owners’s Manual - Model OBX-4770-P djusting creen isplAys...

  • Page 34: Adjusting On-Screen Displays - Audio Menu

    VOL+/VOL- on the TV to make the desired adjustments. 3. When adjustments are complete, press MENU or EXIT on remote or MENU on the TV to exit the main menu. ® All Rights Reserved. 2015 SkyVue...
  • Page 35 10 kHz (upper treble) audio band. This adjustment is available only when Personal sound mode is selected. This function is supported only with analog broadcast signals,which are no longer used in the U.S. Owners’s Manual - Model OBX-4770-P djusting creen isplAys...

  • Page 36: Adjusting On-Screen Displays - Time Menu

    VOL+/VOL- on the TV to make the desired adjustments. 3. When adjustments are complete, press MENU or EXIT on remote or MENU on the TV to exit the main menu. ® All Rights Reserved. 2015 SkyVue...
  • Page 37 Wake Up submenu pictured at left. Now press the buttons to highlight the adjustment you want to make (day, hour, minute, etc.), then use to make the adjustment. Repeat until the desired wake up time is set. Owners’s Manual - Model OBX-4770-P djusting creen isplAys...

  • Page 38: Adjusting On-Screen Displays - Setup Menu

    CC Mode submenu shown at left. Pressing will now select among the three closed caption modes: Off, On and CC on Mute. The last option shows captions only when mute is activated. ® All Rights Reserved. 2015 SkyVue...
  • Page 39 Setup Wizard. When you have finished with the third Setup Wizard screen, the Setup Wizard will automatically activate Auto Scan to identify and memorize the channels that can be received. Owners’s Manual - Model OBX-4770-P djusting creen isplAys...

  • Page 40: Adjusting On-Screen Displays - Lock Menu

    Software Update (USB) This function is used to update the software on your TV. Consult SkyVue Outdoor TV for more information. Blue Screen Press the buttons to highlight the Blue Screen adjustment, then use to activate or deactivate the blue screen that appears when no signal is available at the selected input.
  • Page 41 (0000 unless you previously changed it), then enter the new password twice. If you enter a new password but forget it later, contact SkyVue Outdoor TV for assistance. Owners’s Manual - Model...
  • Page 42 If an input is blocked, using it will require entering the system password. Canada RRT Setting Reset RRT These functions are not adjustable and are for service use only. ® All Rights Reserved. 2015 SkyVue...

  • Page 43: Sing The Usb I Nput

    USB stick, or to the folders on the stick that the media is stored in. If folders appear, press to highlight the folder you want, then press to open the folder. Owner’s Manual - Model OBX-4770-P UsB i sing the npUt...
  • Page 44 Listening to Music from the USB Stick to highlight the song you want to listen to, then press to play the song. The song will begin playing and a text screen that shows data about the file will appear. ® All Rights Reserved. 2015 SkyVue...

  • Page 45: T Roubleshooting

    Trouble Solutions Check the following: Power cord is connected correctly. Power is turned on. The video cable is connected correctly. You have selected the proper input signal source. No picture If you have done the above, without resolve, unplug TV for at least 1 hour to perform Hard Reset.
  • Page 46 This is common to all LED screens used in display and television color products, and is not specific to SkyVue Outdoor TV’s. For more information, see SkyVue Outdoor TV’s’s Pixel Quality Policy in this manual. Switching a channel Different channels and inputs sometimes have this effect because the channel signal’s...

  • Page 47: Care Of Skyvue Outdoor Tv

    (do not spray the solution directly on the panel) and gently clean the panel. A “special outdoor formula” LED Cleaning Kit is now available and can be ordered from SkyVue Outdoor When the TV is not in use, keep it covered with a Deluxe SkyVue Outdoor TV Cover: When the unit is not being used, the SkyVue team strongly recommends using the all weather protective cover.

  • Page 48: Specifications

    • 2 Year Parts and Labor Warranty applies to all SkyVue OBX Series Outdoor Televisions. 1) Satin Black, 2) White, 3) Dark Brown, 4) Slate Gray, 5) Sandstone, 6) Mint Green, 7) Hunter Green, 8) Terra Copper, 9) Patriot Blue SkyVue TV, 1439 Dave Lyle Blvd., Bld.

  • Page 49: Tv Care & Policy Information

    TV Care & Policy Information Extreme Climate Warning If temperatures below -24º F are expected, we recommend that you bring your SkyVue Outdoor TV inside to prevent damage to the LED screen. SkyVue Outdoor TV Pixel Quality Policy (Applicable to LED TVs sold within USA and Canada only.) SkyVue Outdoor TV LED screens are manufactured with rigorous standards to maintain optimal viewing.

  • Page 50: Rs232 Control Codes

    A0 F0 55 FF 58 A7 Go To Next A0 F0 55 FF 13 EC Go to Prev A0 F0 55 FF 47 B8 Guide A0 F0 55 FF 15 EA Sleep: A0 F0 55 FF 53 AC ® All Rights Reserved. 2015 SkyVue...
  • Page 51 A0 F0 55 FF 29 d6 A0 F0 55 FF 46 B9 Green A0 F0 55 FF 4A B5 Yellow A0 F0 55 FF 52 A1 Blue A0 F0 55 FF 5E A1 Owner’s Manual - Model OBX-4770-P TV C are and mporTanT nformaTIon...
