Hire and Rental Industry Association Ltd

Product Safety Assessment Sheet

PLANT INFORMATION

PSA Ref #: 00366

Model No: GTS1300SH & GTS1300S

Plant Name: Crommelins 13.5hp Wood Chippper GTS1300SH

Manufacturer: Crommelins Machinery WA

Manufacturer's Website: www.crommelins.com.au

Web Link for Plant: www.crommelins.com.au

Potential noise level in dB: 85 to less than 90

Required hearing protection class: 1

Mandatory Personal Protective Equipment:

Dust Mask

Face

Protection

RISK ASSESSMENT INFORMATION

Operator Competency: Plant Licence Not Required

Potential Hazard(s)

Protective Equipment

Explosion or fire from fuel

vapours.

Exposure to ultraviolet radiation

if working outdoors.

Coming into contact with hot

parts of the engine.

Foot

Hand

Protection

and Eye Protection

Risk Level

High

Medium

Medium/Low

Head,

Protective

Hearing

Clothing

Control Measure(s)

• Face, Eye and Ear protection must be worn

while chipper is in operation

• Stop the engine before refuelling. Do not

refuel while hot. Avoid spillage of fuel when

refuelling. Ensure the fuel cap is properly

secured after refuelling. Carry out visual

checks for fuel leaks and repair before

operation. Keep flammables away from the

engine. Warning label on engine. Do not

smoke while operating, servicing or refuelling

this machine.

• Wear sunscreen, hat, long sleeves and long

trousers.

• The muffler is fitted with a heat shield. Let

the engine cool down before attempting any

maintenance. Avoid contact with hot

components. Warning label on engine.

Page 1 of 3

Table of Contents

Need help?

Do you have a question about the GTS1300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Crommelins GTS1300

Page 1 Product Safety Assessment Sheet PLANT INFORMATION PSA Ref #: 00366 Model No: GTS1300SH & GTS1300S Plant Name: Crommelins 13.5hp Wood Chippper GTS1300SH Manufacturer: Crommelins Machinery WA Manufacturer's Website: www.crommelins.com.au Web Link for Plant: www.crommelins.com.au Potential noise level in dB: 85 to less than 90...
Page 2 Inhaling exhaust or fuel fumes. Medium/Low • Only operate in a well ventilated area. Do not operate in a confined space. Avoid breathing petrol fumes. Avoid skin contact with petrol. Coming into contact with moving • Belt guard fitted to plant. Do not remove parts.
Page 3 Key Operating Instructions The hardness of the wood depends on the wood type, the time between pruning and chipping and how dry the branches are. The machine performs best if the branches are chipped right after pruning. The GTS1300SH & GTS1300S is made only for chipping newly cut wood having a maximum diameter of 75mm. It is prohibited to feed in any other materials into the machine ie metal, stones, plastics, paper, processed timber or any other materials.
Page 4 CROMMELINS™ CHIPPER GTS1300 OPERATION & INSTRUCTION MANUAL Thank you for your selection of a CROMMELINS™ Chipper GTS1300. This Operation Manual explains its use, installation, checking and maintenance. We highly recommend that you retain this manual for ready reference regarding proper handling of the CROMMELINS™ Chipper GTS1300.
Page 5 Thank you very much for purchasing a CROMMELINS™ CHIPPER GTS1300. This manual covers operation and maintenance of the CROMMELINS™ CHIPPER GTS1300. This CROMMELINS™ CHIPPER GTS1300 can be used by arbor industries, landscaping, councils, hire industries and general use. Please take a moment to familiarise yourself with the proper operation and maintenance procedures in order to maximise the safe and efficient use of this product.
Page 6: Table Of Contents
CONTENTS 1. General 1.1 Safety & Environment 1.2 Personal Safety 1.3 Explanation of the warning signs 2. Using the chipper 2.1 Safety and Technical remarks 2.2 Starting the chipper 2.3 Using the chipper 2.4 Transporting 3. Maintenance of the chipper and checks 3.1 Removing the input tube 3.2 Replacing and adjusting the belts 3.3 Changing the engine oil...
Page 7: General
Do not wear any loose clothes, or clothes with strings or ties. Use the chipper only in the open air. The GTS1300 is made only for chipping newly cut wood having a maximum diameter of 75mm. It is prohibited to feed any other material into the machine (e.g. metal, stones, plastics or any other material).
Page 8: Explanation Of The Warning Signs
Every time you want to use the machine, check beforehand that machine is working properly and replace any faulty or worn parts immediately. Check the following before every use: Loose bolts and nuts Damaged rubber flaps in the input tube – change them if they are damaged or worn Oil level in the engine Cracks in the plating and/or failed welding...
Page 9: Using The Chipper
2. USING THE CHIPPER 2.1 Safety and Technical remarks The machine must be prepared and operated according to the following instructions: When fitting the blades, the bolts must be tightened by a torque wrench (70Nm for the cutting blades (nr. 19 on the spare parts drawing) and 40 NM for the counter blade (nr.
Page 10: Using The Chipper
Never leave the machine running unattended. Stop the engine and remove the key from the ignition switch before replacing the blades or the counter blade. Check after one hour’s work that all bolts, nuts and screws are tight. If not, tighten them or consult your dealer.
Page 11: Transporting
Always check that the two bolts at the bottom of the input tube are securely tightened (fig. 12 & 13), if you wish to stop chipping allow the machine to run for several minutes to chip and eject all debris which otherwise can jam the rotor when you next want to start the machine.
Page 12: Removing The Input Tube
3.1 Removing the input tub First remove the output tube by un-tightening the 2 Allen-screws (picture 1.1 & 1.2). Then remove the Allen-screws from the input tube (picture 1.3). Tilt the input tube backwards carefully (picture 1.4). Be aware that the machine could lose its balance – if need be support the frame at the bumper (picture 1.5).
Page 13: Changing The Engine Oil
3.3 Changing the engine oil. Change the engine oil at the recommended interval see engine user manual for instructions. Fill the engine with SAE30 engine oil. Use funnel to avoid spillage. 4. PROBLEMS, CAUSES & SOLUTIONS PROBLEM CAUSE SOLUTION The shredder does - The blades are worn too much Reverse, sharpen or change the blades.
Page 14: Technical Specifications
5. TECHNICAL SPECIFICATIONS GTS1300 Powered by a SUBARU EX40 14hp engine Maximum RPM 3600 Dimensions – 150L x 75W x 152H cm Weight – 165kg Chipping system: 2 blades on rotor and 1 counter blade on chassis 6. PARTS DIAGRAM...
Page 15: Spare Parts List
7. SPARE PARTS LIST...
Page 16: Spare Parts List Continued
8. SPARE PARTS LIST...
Page 17: Warranty
9. WARRANTY Consult the CROMMELINS Machinery warranty leaflet (supplied with your new product) for full details and a list of service dealers for this product, also available online at www.crommelins.com.au.
Page 18 NOTES ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
