B1924-02 Education Primary Compound
Microscopes Instructions
Content
Before use...
1.Nomenclature....................................................
2.Operation.........................................................
2-1 Set the specimen slide...........................................3
2- 2 S et il l u m i n a t i on ...... ... ... ... ... ... ... ... ... ... ... ... ... ... 3
2-3 Adjust focus......................................................3
2-4 Adjust diopter of binocular head..............................4
2-5 Adjust condenser................................................4
2- 6 Ad j u s t di a p h r a g m ... . ...... . ...... ... ... . ...... ... ... ... ... 4
2-7 Choose the objective ............... ....... ................... 5
2-8 Change the lamp ........................ ...................... 5
3
.
4
.
5
.
...................................................
......................................................6
........................................7
...........................................................9
0
Address:800 S Wineville Avenue, Ontario, CA 91761,USA
B1924-02
Website:www.aladdin-e.com
Email: tech@aladdin-e.com
1
2
3
Advertisement
Table of Contents
Related Manuals for Aladdin B1924-02
Summary of Contents for Aladdin B1924-02
-
Page 1: Table Of Contents
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com B1924-02 Education Primary Compound Microscopes Instructions Content B1924-02 Before use… …………………………………………… 1.Nomenclature.…………………………………………… 2.Operation………………………………………………… 2-1 Set the specimen slide……….……..…….………………3 2- 2 S et il l u m i n a t i on …… … … … … … … … … … … … … … 3 2-3 Adjust focus………………………………………………3... -
Page 2: Before Use
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com Before use B1924-02 1、Operation （1）As the microscope is a precision instrument, always handle it with care, avoiding impact or abrupt movement during transportation. （2）Do not let the microscope emerge in the sun directly. Keep it in a dry and clean place. -
Page 3: Nomenclature
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 1. Nomenclature B1924-02... -
Page 4: Operation
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 2.Operation B1924-02 The microscope is housed in a molded styrofoam container. First take the container out of the carton, and lay the container on its side. Open the container carefully and don’t let the optical items drop down, avoiding them being damaged. -
Page 5: Adjust Diopter Of Binocular Head
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 2.Operation B1924-02 adjustments: interpupillary (1)Hold the two ends of the head-cover and adjust the distance by pushing or pulling the cover, until one circle of light can be seen. (2)After finishing the interpupillary adjustment, look at the graduation value in the middle of the head-cover. -
Page 6: Choose The Objective
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 2.Operation B1924-02 2-7 Choose the objective Turn the nosepiece to choose the objective. Objective selected should be set vertically right to the slide. Generally, first use the objective 4X to focus to reveal general structural image. Then use the high power objective to reveal smaller details. -
Page 7: General Specification
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 3.General specifications B1924-02 B1924-02 Microscope General specifications (For option) Install Model Parts B1924-02 Specifications ● WF10X/18mm WF10X/18mm with pointer WF10X/18mm with reticle eyepiece WF15X/13mm WF20X/10mm H5X/ H6X Huygens H10X eyepiece H12.5X... -
Page 8: Parameter/Technical Terms
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 4.Parameter/technical terms B1924-02 4-1 Objective Numerical Parfocal Magnification aperture distance market Type Magnification Medium （color ring） （N.A） （mm） 0.10 0.25 Yellow achromatic 0.65 Light blue objective 0.85 Deep blue 195mm... - Page 9 Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 4.Parameter/technical terms B1924-02 4-5 Technical terms (1)Total magnification=(magnification of objective) X (magnification of eyepiece) (2)Field of view=(line field of view of the eyepiece selected) ÷(magnification of the objective selected) (3) N.A.=n·sinα (max), N.A.is very important parameter which marks the features of the objective and condenser.
-
Page 10: Troubleshooting
Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 5.Troubleshooting B1924-02 Symptom Cause Remedy Optics (1)The side of the Turn the nosepiece into The nosepiece is not in the right position. field of view is the right position. dark or not even. - Page 11 Address:800 S Wineville Avenue, Ontario, CA 91761,USA Website:www.aladdin-e.com Email: tech@aladdin-e.com 5.Troubleshooting B1924-02 Symptom Cause Remedy Mechanics (1) The image Put the cover glass to The cover glass faces down. face up. is not focused while using Use a standard cover high power The cover glass is not standard.
