Summary of Contents for AGRI EASE BE-P3FK
- Page 1 FIXED MOULD BOARD PLOUGH BE-P3FK OPERATIONS & PARTS MANUAL FOR MODELS: • BE-P3FK PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TECHNICAL DATA Introduction USAGE INSTRUCTIONS Before Use Attaching Plough to the tractor Note TRACTOR PREPARATION Instructions for Tractor Preparation Adjustments Warning for the Driver Danger Draft of the M.B. Plough Adjustments for Deeper Ploughing MAINTENANCE Maintenance Instructions Storage of Machine after Work Instruction for Driver EXPLODED VIEW &... - Page 3 (The BE AG & INDUSTRIAL Factory may inspect equipment or parts before warranty claims are honored.) 5. All costs incurred by the dealer for traveling to or transporting the equipment for warranty inspection and claims will be borne by the customer. BE-P3FK USER MANUAL...
-
Page 4: Technical Data
Readjust the plough alignments if need be. The first bar point will pick up a lot or a little soil depending on how far or near the rear wheel is to the furrow respectively BE-P3FK USER MANUAL... -
Page 5: Tractor Preparation
2. Reducing or increasing, as per the soil, the tilt angle. A correctly tilted plough tends to penetrate better. 3. If the ground is covered with trash, set the plough in almost vertical position and add weight to the plough. In such soils notched plough gives better results. BE-P3FK USER MANUAL... -
Page 6: Maintenance
1. When M.B. plough is ready to use don’t stand between M.B. plough & the tractor. 2. Properly fit the three point linkage as mentioned above & lock with the lynch pin. 3. Never turn or reverse the tractor when the plough is engaged in the soil. BE-P3FK USER MANUAL... -
Page 7: Exploded View & Part Lists
EXPLODED VIEW & PART LISTS Fixed Mould Board Plough (USA Type) 3 Bottom 1.12 3.83 4.14 4.11 BE-P3FK USER MANUAL... - Page 8 BIG MOULD BOARD ASSEMBLY-USA TYPE HEX HEAD BOLT M18X135X2.5MM (8.8 GRADE) NYLOCK NUT M18X2.5MM SPRING WASHER 18 MM HEX HEAD BOLT 12X70X1.75MM (8.8 GRADE) SPRING WASHER 12 MM 4.10 NYLOCK NUT M12X1.75 (P) HEX HEAD BOLT 16X65X2MM (8.8 4.11 GRADE) BE-P3FK USER MANUAL...
- Page 9 COLTER FLAT R.H.S (ROUND TYPE) 79490015 COLTER HOLDING THREADED BUSH 79490017 HEX HEAD BOLT M10X25X1.5MM (8.8 GRADE) 10260361 HEX HEAD BOLT M18X160X2.5MM (8.8 GRADE) 10260402 SPRING WASHER 18 MM 10270006 NYLOCK NUT M18X2.5MM 10280020 R PIN 3/8 10020076 BE-P3FK USER MANUAL...
- Page 10 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-P3FK USER MANUAL...
