- Page 1 BATTERY & CHARGER FOR JAM 7-SERIES ORIGINAL USER GUIDE ENGLISH Version 2 I 18.08.2022...
- Page 2 BATTERY & CHARGER FOR JAM 7-SERIES DEAR CUSTOMER This user guide contains information on how to operate and care for your battery and its charger. Read this guide and all of the safety instructions carefully through before charging for the first time and retain the guide for future use.
-
Page 3: Safety Information
1. SAFETY INFORMATION WARNINGS SERIOUS INJURY DUE TO INCORRECT OPERATION. • During charging, ensure that there is sufficient ventilation, and nev- People (including children) who are unable to use the battery and er place the battery or charger close to or on combustible materi- charger because of their physical, sensory or intellectual capabilities, als (e.g., paper, textiles, etc.). - Page 4 2. TECHNICAL DETAILS CAUTION MINOR INJURIES DUE TO DAMAGE OR INCORRECT OPERATION. • Vapours emitted from the battery can irritate the respiratory tract. Ensure that there is a supply of fresh air and consult a doctor in case of any discomfort. BATTERY BUTTON •...
- Page 5 LED CHARGE INDICATOR will give you information about the state of the battery. POWER CABLE BATTERY CABLE WITH CHARGING PLUG BATTERY BUTTON CHARGER Part number BC222360040 Nominal voltage 90 - 240 V Frequency 50/60 Hz Battery charging voltage 42 V Charging current (max.)
- Page 6 3.1 CHARGING STATE 3.2 CAPACITY INFORMATION Briefly press the battery button in standby mode. Capacity indicates the quantity of electric charge the battery can de- DISPLAY DESCRIPTION CHARGE LEVEL liver or store. It is specified in ampere hours (Ah). Even when used properly, the capacity diminishes over time due to chemical reactions (ageing).
- Page 7 4. CHARGING THE BATTERY INFORMATION 4.1 BATTERY DISPLAY DURING CHARGING The battery can remain on the Pedelec during the charging process. It can also be removed and charged elsewhere. Connect the power cable to the battery charger. DISPLAY DESCRIPTION CHARGE LEVEL If you are charging the battery on the bicycle, now, slide the cover 4 LEDs light up 80 –...
-
Page 8: Removing And Inserting The Battery
5. REMOVING AND INSERTING THE BATTERY 5.1 REMOVING THE BATTERY Open the cover flap. Remove the battery from the down tube. Hold the battery firmly from below. Turn the bolt counterclock- wise with a 6mm Allen key and remove. - Page 9 5. REMOVING AND INSERTING THE BATTERY 5.2 INSERTING THE BATTERY Slide the battery into the down tube. Insert the bolt into the opening and tighten clockwise to 6 Nm using a torque wrench (Allen key 6 mm). Close the cover flap.
- Page 10 6. CLEANING WARNING 6. 1 CLEANING THE BATTERY SEVERE INJURY FROM ELECTRICAL SHOCK WARNING Before cleaning the battery and/or charger, these must be discon- nected from the mains power. SERIOUS CRUSHING INJURY DUE TO ACCIDENTAL ACTUATION OF THE ON BUTTON. PLEASE NOTE Remove the battery before cleaning it.
-
Page 11: Storing The Battery
7. STORAGE 7.1 STORING THE BATTERY Remove the battery from the Pedelec. Store the battery in a dry, not excessively warm room. The storage temperature should be between 0°C and 20°C. The battery should not be exposed to direct sun. 7.2 STORING THE CHARGER Store the battery in a dry, not excessively warm room. -
Page 12: Faults And Remedies
8. FAULTS AND REMEDIES 8. 1 BATTERY DESCRIPTION CAUSE REMEDY The battery gets hot when charging Excessively high ambient temperature Immediately stop the charge process and allow the battery to cool. Then resume charging in a cooler environment. If the problem recurs, get in touch with your specialist workshop. - Page 13 FOCUS BIKES Rotenwaldstraße 158 70197 Stuttgart Germany Legal Base: Kalkhoff Werke GmbH Europa-Allee 26 49685 Emstek Germany Telefon: +49 (0)4471 966-0 Telefax: +49 (0)4471.966-210 E-Mail: info@focus-bikes.com Subject to misprints, errors and technical alterations. 1973K0023019...
