Summary of Contents for dp smart Rogy360

Page 1 Rogy360 Operation Guide...
Page 2: Table Of Contents
Table of Contents In The Box Camera Overview Do This First Camera Operation App - Camera Mode Setting App - Broadcast Account Setting App - Mobile Connection and Live Binding Image Gallery Optional Accessory Automatic Update via Smartphone Specification Safety Notice...
Page 4: In The Box
Welcome to the GoVideo Family! We would like to welcome you the Rogy family. By this time you have opened the box, now let’s get to know Rogy. In the box you should find the following items: ROGY Power Adapter USB-C Cable Protective Hard Case microSD Card...
Page 5: Camera Overview
Camera Overview Front Lens Top-Left Lens Rear Lens Status Display Shutter Charging LED Function Keys micro SD Card Slot IO Panel SN Label Speaker IO Door Menu / Left Power / OK Type-C USB Port Wi-Fi Mode Shortcut Key Tripod Mount Port Wi-Fi / Right / Wi-FI LED Wrist Strap Holder Function Keys...
Page 6 Camera Overview - Display Status 1. Shooting Function Photo Mode Record Mode Live Mode Time-lapse Mode Bracket Mode 2. Resolution Photo REC. \ Live 5760x2880 1920x960 0003455 6720x3360 2880x1440 7680x384 3840x1920 3. SD Card Capacity Photo Frames 0001234 12:34:56 Recording Time 4.
Page 7: Do This First
Do This First - Charging Your Camera Insert USB cable into USB AC adaptor and insert into USB port of camera. Charging LED Insert wall charger into outlet. The charging LED will be red while charging. The charging LED turns to green when the battery is fully charged.
Page 8 Do This First - App Installation You can find the Cupola360 app from Apple Store or Google Play. Click on the Cupola360 app icon to open the app once the installation is completed.
Page 9 Do This First - Power ON and Turn ON Wi-Fi 0003455 0003455 The Wi-Fi status show Long press Power Release after the When the power “On-line” that mean key for about 5 Cupola360 icon is turned on, short the Wi-Fi has booted seconds.
Page 10 Do This First - Mobile Connection Turn on mobile Wi-Fi, Enter an online pass- select The device word at the beginning of 12345678, Rogy, and go online. and complete the online. Wi-Fi Mode Shortcut Key Power on then long Wi-Fi Mode icon press the Wi-Fi key about Direct Internet...
Page 11 Do This First - Mobile Connection Open Cupola360 The camera display App 。 show APP control mean the camera has connected with the mobile phone App completly. (Anyway the Wi-Fi Mode in Direct Mode or Internet Mode are same.) Highlights: You can’t control the camera direct- ly .
Page 12: Camera Operation
Camera Operation - Rogy Shooting Function 0003455 4-1 Shooting Mode 4-2 Photo Mode 4-3 Recording Mode 4-4 Live Mode Short Press Menu key Press L/R keys to the ap- Press L/R keys to the ap- Press L/R keys to the to enter Shooting Mode point mode then press point mode then press...
Page 13 Camera Operation - Optional Setting 0003455 5-1 Optional Setting 5-2 Record Resolution 5-3 Photo Resolution 5-4 Live Resolution 5-5 Time-Lapse Long Press Menu key Press L/R keys to Press L/R keys to Press L/R keys to Press L/R keys to select select S / M / L / select S / M / L / Customize (setting by...
Page 14 Camera Operation - Wi-Fi Mode Switching 0003455 6-5 Quit 6-1 Optional Setting 6-2 Wi-Fi Mode 6-3 Internet Mode 6-4 Direct Mode Long Press Menu key Press L/R keys to se- Use for the Live Use for the Mobile Press L/R keys to to enter the Optional lect Wi-Fi Mode then Broadcast.
Page 15 Camera Operation - Wi-Fi Channel Setting 0003455 7-2 Info. Review 7-4 Channel Switch 7-5 Quit 7-1 Optional Setting 7-3 Wi-Fi Channel Press L/R keys to Long Press Menu key Press L/R keys to The default Wi-Fi Press L/R keys to Channel settion select Information to enter the Optional...
Page 16: App - Camera Mode Setting
App - Camera Mode Setting Click on the Camera Live preview in the icon, go to the cam- middle of Camera era page. page, default is photo mode.
Page 17 App - Camera Mode Setting EV value adjustment. Self-timer setting.
Page 18 App - Camera Mode Setting Advanced function Other advance settings. function settings. The advanced setting Include Shooting size, sits according to Horizontal correction, the shooting needs. Shotting unsticted, Include Exposure, ISO, Gyro and shooting Shutter Speed, White guides. Balance, Contrast, Sharpness, Saturation, WDR, Flicker and Image Quality.
Page 19 App - Camera Mode Setting Recording mode. Wi-Fi Live Mode, to complete the camera Wi-Fi and live account settings, and the camera Wi-Fi mode to Internet Mode. (The detail operation, please reference page 23~26 “App - Mobile Connection and Live Binding”.) Live platform settings.
Page 20 App - Camera Mode Setting Time-lapse mode. Shrink interval setting.
Page 21: App - Broadcast Account Setting
App - Broadcast Account Setting Power off the camera Click on the Face- or disable the Wi-Fi. book and YouTube Disconnect with the icons in sequence camera first. and set up your ac- Open the Cupola360 count as prompted. App then click on the Settings icon, go to the camera page.
Page 22 App - Broadcast Account Setting Depending on the Facebook and different Wi-Fi protocol YouTube icons will be used in your country displayed in color or region, you need once account setting to adjust the “Wi-Fi are completed. support country” to correspond to the cor- rect country or region.
Page 23: App - Mobile Connection And Live Binding
App - Mobile Connection and Live Binding 10-1 10-2 Power on the camera If online is successful, and active the Wi-Fi. the page shows the Connect with the status of Rogy. camera first. If it doesn’t, go back Open the Cupola360 to the previous step App then click on the to confirm that Wi-Fi is...
Page 24 App - Mobile Connection and Live Binding 10-3 10-4 Enter the name and Click on the Wi-Fi password of the Wi-Fi de- setting option to go to vice you are connected the settings page. to while broadcasting. Names should be consistent.
Page 25 App - Mobile Connection and Live Binding 10-5 10-6 Change the Wi-Fi Live binding complete. mode setting of camera into Internet mode. Exit the Setting page of App the press the camera icon to enter the camera page. Wi-Fi Mode Shortcut Key Power on then long press the Wi-Fi key about 3 sec- onds and release when...
Page 26 App - Mobile Connection and Live Binding 10-7 10-8 Seclet the shooting Select the Streaming Mode to the Live Platform by Facebook mode then press the or YouTube then press Send to finish the Streaming Platform icon . setting. Select the streaming platform...
Page 27: Image Gallery
Image Gallery 11-1 11-2 Click on the Image Under Image Library, Gallery icon to go you’ll automatically to the Image Library sync photos and page. movies in your phone’s Cupola folder, sorted by the date of your shooting.
Page 28 Image Gallery 11-3 11-4 Top left corner for Select the image you image library switch want to delete. options- Device (mo- bile phone) / Camera (Rogy). The image Deletion option in the upper right corner. 11-5 Click the Delete icon to delete the image.
Page 29 Image Gallery 11-6 11-7 Switch image display Click on the drop- styles: down arrow, you can Perspective Projection do the basic setting Fisheye of the image, it is Crystal Ball recommended to Little Planet turn on the horizontal Equirectangular. fixed function, auto- matically correct the image level.
Page 30 Optical Accessory Rogy Pouch Rogy Fan RogyLAN RJ-45 Network Kits Rogy Spike...
Page 31 Optical Accessory Rogy Stand Kots Rogy Docking...
Page 32: Automatic Update Via Smartphone
Automatic Update via Smartphone Your Smartphone should be able to connect the Internet for this update process. The app is required to update the firmware. Please download the Cupola360 app from the https://cupola360.com/. ATTENTION! • Plug your Camera into power or keep the battery level over 60%. •...
Page 33 Automatic Update via Smartphone Important: • Please free up the storage space of the smartphone & MicroSD card for camera before performing the firmware update. • To ensure normal recording, use microSD card with a speed class of V30, exFAT format.
Page 34: Specification
Specification Aspeed AST1220 Sensor PS5510 x 6 S (5760x2880), M (6720x3360), L (7680x3840) Image Resolution S (1920x960), M (2880x1440), L (3840x1920) Video Resolution S (1920x960), M (2880x1440), L (3840x1920) Live Streaming Resolution Mode Photo / Video / Live Streaming (YouTube or Facebook) / Time-lapse / Bracket Exposure Microphone Built-in 4 mic...
Page 35 Specification Power Rechargeable Li-ION battery 3.7V / 3300mAH Power Adapter 5V / 3A Interface USB 2.0 Type-C OLED monochrome, Indicate Power and Status iPhone : iOS 11.2 or higher Operating System Request of Mobile Devices iPad : iPadOS 11.2 or higher iPod touch : iOS 11.2 or higher Android : 6.0 or higher Waterproof Level...
Page 36 Safety Notice - Caution On Use • Do not disassemble this product; there are no user-serviceable parts inside and will void warranty. • Opening and tampering with the camera will void your warranty. • Keep camera away from extreme temperatures or prolonged exposure to direct sunlight.
Page 37: Safety Notice
Safety Notice Federal Communications Commission (FCC) Statement 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 38 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncon- trolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. FCC ID : 2AVSX-ROGY360...
Page 39 Safety Notice Canada, Industry Canada (IC) Notices This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device.
Page 40 Safety Notice Canada, avis d’Industry Canada (IC) L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux ap- pareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1.
Page 41 • Simplified DoC: Hereby, dp smart technology declares that the radio equipment type Rogy360 is in compliance with Directive 2014/53/EU The full text of the EU declaration of conformity is available at the following internet...
Page 42 Safety Notice - the Built-in Rechargeable Battery Denger: Do not try to replace the built-in lithium ion rechargeable battery. If you use a battery type that is incompatible with the assigned model, there may be an explosion, overheating, or other risks. Do not try to disassemble or modify the built-in battery pack.
Page 43 Safety Notice - the Built-in Rechargeable Battery In order to prolong the battery life, it is recommended to charge the battery to more than 30% ~ 50% of the power every time, and recharge it at least every three months to avoid excessive battery discharge. Warning: If the liquid of the battery gets into your eyes accidentally, do not rub your eyes and immediately rinse eyes thoroughly with water such as clean water.
