Single/Double Internal
3 Drawer Chest
Assembly Instructions -
Dimensions
Width - 46,8/96,8cm
Depth - 45,8cm
Height - 56,8cm
Important -
Please read these instructions fully before starting assembly
Please keep for future reference
405769
867492
Ref. no HB 05.07 Date: 18/04/11
Advertisement
Related Manuals for Schreiber Messtechnik 405769
Summary of Contents for Schreiber Messtechnik 405769
- Page 1 Single/Double Internal 3 Drawer Chest Assembly Instructions - Please keep for future reference 405769 867492 Dimensions Width - 46,8/96,8cm Depth - 45,8cm Height - 56,8cm Important - Please read these instructions fully before starting assembly Ref. no HB 05.07 Date: 18/04/11...
- Page 2 Safety and care advice Important – Please read these instructions fully before starting assembly • Check you have all the • Assemble on a soft level • We do not components and tools listed on surface to avoid damaging the recommend the pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 1) Left end panel 2) Right end panel 3) Top panel 4) Back rail 5) Front rail 6) Side filler 7) Front drawer 8) Left drawer side 9) Back drawer panel 10)Right drawer 11)Drawer bottom...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more - ttings may be supplied than are required. x 12 Wooden dowel x 32 Metal dowel x 14 30mm Screw x 6 Long locking...
- Page 5 Assembly Instructions Step 1 Prepare panels Please note the correct fixing holes in the drawer runner – as shown. The top row of holes are used and when fixed into position the front edge of the runner should sit 2 mm. from the front of the end panel.
- Page 6 Assembly Instructions Step 2 Step 3...
- Page 7 Assembly Instructions Step 4 Step 5 Note that the assembled cabinet should be fitted into the wardrobe before the hinge plates are fitted !
- Page 8 Assembly Instructions Step 6 Assembly for drawer boxes...
- Page 9 Assembly Instructions Step 7 Insert drawer Ensure plastic securing pegs are to the out position. Drawer front adjustment Drawer front...
- Page 10 Assembly Instructions Step 8 Handle drill Handle fitting Only for SINGLE drawer Blind holes are pre-drilled on the back face of the doors & drawers. Use these as a guide to drill through with 5mm. drill bit together with scrap piece of wood to avoid chipping the front face.
-
Page 11: Cleaning Instructions
Assembly Instructions That's the internal 3 drawer chest completed. Take care of your unit by using a damp cloth to clean it. Please remember to occasionally check that all Cams and Screws are tight. CLEANING INSTRUCTIONS This product has been manufactured using modern manufacturing methods and materials.
