AKPDS
Satellite Keypad & Display Kit, Wall Mount Enclosure
Ref.
Part No.
AKPDS
1
AKPDS
2
3
4
www.SignatureControlSystems.com
Description
Satellite Keypad & Display Kit, Wall Mount Enclosure
Satellite Keypad & Display, Wall Mount Enclosure
Ground Wire, Green, 1 Nut
Cable (15-Pin)
Screws
Component Parts/Packing List
AKPDS (Rev A)
Qty
1
1
1
1
4
1
Advertisement
Table of Contents
Summary of Contents for Signature Control Systems AKPDS
- Page 1 Satellite Keypad & Display Kit, Wall Mount Enclosure Ref. Part No. Description AKPDS Satellite Keypad & Display Kit, Wall Mount Enclosure AKPDS Satellite Keypad & Display, Wall Mount Enclosure Ground Wire, Green, 1 Nut Cable (15-Pin) Screws www.SignatureControlSystems.com AKPDS (Rev A)
- Page 2 (See Front View) Connect loose end of Green Ground Wire (3) to chassis screw with nut. Mount Keypad (1), use four small screws (5). (See below) Mount expansion plates with screws as required. Front View Keypad Install www.SignatureControlSystems.com AKPDS (Rev A)
