Summary of Contents for HikRobot MV-HR6000M
- Page 1 HANGZHOU HIKROBOT TECHNOLOGY CO., LTD. MV-HR6000M User Manual...
-
Page 2: Statement
(licensed program). Except as noted below, such license may not be assigned, sublicensed, or otherwise transferred by the user without prior written consent of HIKROBOT. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright law. -
Page 3: Table Of Contents
Contents Statement......................1 Chapter 1 Brief Instruction................4 1.1 Brief Instruction................... 4 1.2 Precaution Before Using Battery............5 Chapter 2 Installation Guide................ 7 2.1 Appearance..................7 2.2 Buttons....................8 2.3 Micro SD、SIM、PSAM Card Installation........9 2.4 Battery Charging................. 9 2.5 Device Power on/off................. 10 Chapter 3 Call Function................11 3.1 Phone....................11 3.2 Contacts..................... - Page 4 6.4 Volume Settings................22 6.5 Sensor....................23 6.6 Keyboard.................... 24 6.7 Network....................24 Chapter 7 Device Specifications...............25 Restrictions:....................28 SAR Information..................28 Simplified EU declaration of conformity..........28...
-
Page 5: Chapter 1 Brief Instruction
With the build-in high performance Cortex-A7 1GHZ quad core processor technology, the operators need only one device to enjoy a convenient and easy job, MV-HR6000M will be the ideal choice for key-fact business in mobile solutions, for simplified task flow, enhanced work efficiency, for shortened time to customer response, more satisfied customer care service. -
Page 6: Precaution Before Using Battery
Precaution Before Using Battery Do not leave batteries unused for extended periods of time, either in the product or in storage. When the battery has been unused for 6 months, check the charge status and charge or dispose of the battery as appropriate. ... - Page 7 The battery run time drops below about 80% of the original run time. The battery charge time increases significantly. If a battery is stored or otherwise unused for an extended period, be sure to follow the storage instructions in this document.
-
Page 8: Chapter 2 Installation Guide
Chapter 2 Installation Guide 2.1 Appearance The MV-HR6000M device has black and white appearance optional. -
Page 9: Buttons
2.2 Buttons Button Function Power Button Press and hold to turn the device on or off. Custom Function Button Customize function by software SCAN Scan Button Cancel Button Switch white keyboard function Switch orange keyboard function Setting Button Right of the Fn Button Enter Enter Button... -
Page 10: Micro Sd、Sim、Psam Card Installation
2.3 Micro SD、SIM、PSAM Card Installation Detailed installation of Micro SD、SIM、PSAM Card steps are as follows: TF card PSAM 2.4 Battery Charging Use the adapter to charge the battery via the USB connector of the snap-on. Don't use other brands of charger for device. -
Page 11: Device Power On/Off
2.5 Device Power on/off Press the ‘Power’ button on the top about 3s due to power on/off. And press it shortly to wake up. -
Page 12: Chapter 3 Call Function
Chapter 3 Call Function 3.1 Phone Click this icon Click the number button to input the numbers. Click the button to confirm and dial. Click the to end the calling. Cont Emul ated Numeric Keyboard Voice... -
Page 13: Contacts
3.2 Contacts Click ‘Contacts’ to open the contacts list. Click to add the new contact. Click to import/export or delete the contact list. Conta... -
Page 14: Messaging
3.3 Messaging Click to open the message list. Click to input the content. Click to send the message. Click to add photos, videos. -
Page 15: Chapter 4 Barcode Reader
Chapter 4 Barcode Reader Open the Barcode Demo in APP Center and then press the ‘Scan’ button to start scanning. Note: Please scan the barcode correctly, otherwise the scanning might be failed. -
Page 16: Chapter 5 Rfid Reader
Chapter 5 RFID Reader 5.1 High Frequency 5.1.1 14443A Open the 14443A demo within Appcenter, and press the ‘Scan’ button to start reading. Mifare and Ultralight reading/writing are also supported. -
Page 17: 14443B
5.1.2 14443B Open the 14443B demo within Appcenter, and gain UID of the card. - Page 18 5.1.3 15693 Open the “15693” demo within Appcenter, and then reading and writing information of the tag.
-
Page 19: Nfc
5.2 NFC Open the “NFC” demo within Appcenter, and then reading and writing information of the tag. -
Page 20: Chapter 6 Other Functions
Chapter 6 Other Functions 6.1 PING Open the Ping in Appcenter. Set the Ping parameters and select the internal/external addresses. -
Page 21: Bluetooth
6.2 Bluetooth 1. Open the Bluetooth demo in Appcenter and turn on the Bluetooth. 2. Input the content or select the file, then scan the nearby Bluetooth printer and pair them. 3. Select the printer and click ‘Print’ to print the content. -
Page 22: Gps
6.3 GPS 1. Open the GPS demo in Appcenter and turn on GPS module. 2. Set the GPS parameters and get the GPS data information. -
Page 23: Volume Settings
6.4 Volume Settings 1. Open the Volume Setting demo in Appcenter. 2. Set the volumes based on the requirements. -
Page 24: Sensor
6.5 Sensor Open the Sensor demo in Appcenter. Test the sensor based on the requirements. -
Page 25: Keyboard
6.6 Keyboard 1. Open the Keyboard demo in Handset Appcenter. 2. Set and test the key values of the device. 6.7 Network 1. Open the Network demo in Appcenter. 2. Test the WIFI/Mobile signal based on the requirements. -
Page 26: Chapter 7 Device Specifications
Chapter 7 Device Specifications Physical Parameters Dimensions 157.6mm*73.7mm*29mm Weight 297g (includes main battery) Screen 4in.WVGA (480*800) TFT-LCD, capacitive dual touch Keyboard numeric keypad, 3 side buttons Battery Main bat. (rechargeable li-ion polymer, 3.7V, 4000 mAh) Expansion Slot MicroSD/TF, maximum capacity of 32G SIM Slot 1 PSAM, 1 SIM, 1 MicroSD Audio... - Page 27 Environmental Parameters Operating Temperature -20℃ to 50℃ Storage Temperature -40℃ to 70℃ Humidity 5%RH-95%RH (non-condensing) Dropping Survive 1.5m/3.9ft. drop, 6 sides, concrete floor under operating temp. Sealing IP65, IEC compliance EU Wireless Communication WWAN 2G： 900/1800MHz; max. power 32.6dBm 3G： 900/2100MHz; max. power 22.94dBm 4G：...
- Page 28 7.5 in./191 mm. 100% UPC/ENA: 1.6 in./41 mm. 15.5 in./394 mm. 6.7 mil PDF417: 3.4 in./86 mm. 7.1 in./180 mm. RFID HF 13.56MHz, ISO14443A/ISO15693 (optional). 40.46 dBμV/m (3m) -34.84 dBμV/m (10m) Developing Environment HIKROBOT SDK Programming Language Java Developing Tool Eclipse/Android Studio...
-
Page 29: Restrictions
RF exposure requirements, and should be avoided. Simplified EU declaration of conformity Hereby, Hangzhou Hikrobot Technology Co., Ltd. declares that the radio equipment type MV-HR6000M is in compliance with Directive... - Page 30 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.xxxxxxx.net FCC statements: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 31 FCC RF exposure requirements, and should be avoided. RF Exposure Information(SAR) The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device Types MV-HR6000M (FCC ID: 2AVXLMV-HR6000M) has also been tested against this SAR limit.
- Page 32 The highest SAR value reported under this standard during product certification for use when properly worn on the body is 0.322 W/kg and for head is 0.320 W/kg.
