User Manual
Material No.:
SBXSTCH43 Model Series
Material Description:
Indoor Touch Screen Floor Standing Digital Sign
Operating Instructions for Digital Signage
Note: Before using the product, please read the instructions carefully!
Do not attempt to disassemble this product. If the product does not work properly, please
contact your local dealer or the company.
1
Advertisement
Table of Contents
Related Manuals for D2G SBXSTCH43 Series
Summary of Contents for D2G SBXSTCH43 Series
- Page 1 User Manual Material No.: SBXSTCH43 Model Series Material Description: Indoor Touch Screen Floor Standing Digital Sign Operating Instructions for Digital Signage Note: Before using the product, please read the instructions carefully! Do not attempt to disassemble this product. If the product does not work properly, please contact your local dealer or the company.
-
Page 2: Table Of Contents
Contents Features ............................3 Safety Warnings and Precautions ..................... 3 Installation and Connection ......................5 Packing List ............................5 Interfaces ............................6 Steps of Installation ........................... 6 Remote Control ..........................7 Description of Basic Operation ......................8 Power on/Standby ..........................8 About Launch Desktop ........................ -
Page 3: Features
Features Embedded with Android 5.1.1 smart operating system and unique UI design, bringing you a more convenient operation and better visual experience. Support USB mouse and keyboard, realizing easy manipulation like a computer. Built-in Wi-Fi module, high capacity memory and high capacity cache, making it smoother to watch 1080P HD movies and play big games. - Page 4 Warning Do not use power supply other than AC outlet in parallel, or else it may cause fire 110V, 50Hz. due to excessive power consumption. Cut off the power supply before Do not approach the Digital Signage with connecting or disconnecting any cables. open flame (e.g.
-
Page 5: Installation And Connection
malfunction. resulting in machine failure. Before cleaning the Digital Signage, If the unit displays the same screen for a please pull out the power plug; wipe long time or the moving picture has fixed with soft cloth; do not use industrial text or icon, it will leave ghosting on the chemicals;... -
Page 6: Interfaces
Interfaces 1. USB interface ;2. RJ45 interface (Ethernet); 3.HDMI input;4. Power port;5. on/off button; Note: Please pull out the power plug before installing or disassembling the unit! Steps of Installation Open the top cover as shown in Fig. 2; Remove EPE on both sides of the box as shown in Fig. 3; Take out the base as shown in Fig. -
Page 7: Remote Control
Remote Control Installing batteries for the remote control: Remove the battery cover, and insert two AAA batteries (1.5V). Ensure that the battery polarity matches the “+”/“-” marks in the battery compartment of the remote control. Precautions for using the remote control: Aim the remote control at the receiver window. -
Page 8: Description Of Basic Operation
Description of Basic Operation Power on/Standby Insert the power plug into the outlet. If the Digital Signage has the switch button “I”, turn it on; if you press the switch button “O”, the Digital Signage enters standby state. power button on the remote In power on state, enter “System Aid”... -
Page 9: File Manager
Description of Basic Operation File Manager 1. Tap the Main Apps button in the Home page to enter the “APPS” menu interface (Fig. 2); 2. Tap the “Explorer” icon in the “APPS” menu interface (Fig. 2) and enter “Explorer” menu (Fig. 3); 3. - Page 10 Fig. 1 Fig. 2 Fig. 3 Description of Settings Interface (shown on the right) Description of Settings Interface (shown on the right) Icon Function WIFI switch Data usage Bluetooth Sound & notification Battery saver HDMI Display Storage Apps Screenshot Setting Location Accounts Backup &...
- Page 11 Status of Menu bar 1. Step1: Click the setting 2. Step2: At the setting menu click the display menu At the setting menu click the display menu 3. Step3: At the display setting menu unselect the display navigation check box At the display setting menu unselect the display navigation check box At the display setting menu unselect the display navigation check box Fig.
-
Page 12: Slide Show App Introduction
Slide Show APP Introduction Slide Show APP Introduction How to upload media files ： ： Step1: Open the Android launcher screen and launcher screen and click the explorer app Step2: Go to the USB storage menu storage menu click the USB storage button... - Page 13 Step3: At the USB storage menu select menu select the media files which you want to copy to the media folder the media files which you want to copy to the media folder click the edit button, the pop menu will show then click the Copy button button, the pop menu will show then click the Copy button Step4: Click HOME button and go to the NAND FLASH Click HOME button and go to the NAND FLASH menu you will see the media folder, open it...
- Page 14 Step5: At the media folder click the edit button at the top of the screen the pop menu will Step5: At the media folder click the edit button at the top of the screen the pop menu will Step5: At the media folder click the edit button at the top of the screen the pop menu will show and click the Paste command button the files will start copy to the media folder click the Paste command button the files will start copy to the media folder Step6: Exit the Explorer app and go to the launcher screen run the Slide Show app to display the...
- Page 15 How to Delete the media files: How to Delete the media files: Step1: Open the Android laun laun cher screen and click the explorer app Step2: Click home button and go to the NAND FLASH Click home button and go to the NAND FLASH menu you will see the media folder open it menu you will see the media folder open it...
- Page 16 Step3: At the media folder select the media files which you want to delete and click the edit button Step3: At the media folder select the media files which you want to delete and click the edit button Step3: At the media folder select the media files which you want to delete and click the edit button at the top of the screen the pop menu will show and click the Delete command at the top of the screen the pop menu will show and click the Delete command at the top of the screen the pop menu will show and click the Delete command button the files will...
-
Page 17: Technical Specifications
Technical Specifications Model Parameters Panel LCD size LCD supplier Panel model LD430EUE-FHB1 Light source LED backlight Resolution 1920*1080 (pixels) Luminance (typ.)/(min) 450cd/m2 (typ.) Contrast (typ.) 1100:1 (typ.) Response (ms) 12ms (typ.) Pixel pitch 0.4902 (H) mm * 0.4902(V) mm Frame rate 60Hz Viewing angle 178°... - Page 18 HDMI Headset USB2.0 Structure Net weight ≈44kg Gross weight ≈58kg Unit dimensions (W*D*H) 640(W)*66(D)*1760(H)mm ≈1827*507*902mm (honeycomb box) Package dimensions (W*D*H) Shell material Aluminum profile/sheet metal Shell color Silver/black Language English/Simplified Chinese...
-
Page 19: Troubleshooting
Troubleshooting the Digital Signs – SBXSNT43, SBXSNT55, SBXSNT43S, SBXSNT55S Issue Probable Cause Solutions Unit not plugged into wall outlet No picture or sound Check that the unit is plugged into wall Power cord not properly outlet. connected to the terminal on the Confirm that the power cord is connected to back of the unit. -
Page 20: Cleaning And Maintain
Batteries are dead. working positive and negative orientation. Standing too close or too far from Insert new batteries. the unit. Stand within 1 foot of the front of the unit and point the remote directly at the unit. ... -
Page 21: Names And Contents Of Toxic And Hazardous Substances Or Elements In The Product
Names and Contents of Toxic and Hazardous Substances or Elements in the Product Names and Contents of Toxic and Hazardous Substances or Elements in the Product Part name Toxic and hazardous substances or elements PBDE Display Shell × × Circuit board assembly * Wires Metal parts Packaging materials*...
