Summary of Contents for T-Mobile SyncUP DRIVE SD-7000T1
- Page 1 Product: SD-7000T1 User Manual...
- Page 2 About This Manual Thank you for choosing this SyncUP DRIVE SD-7000T1. To keep your device in its best condition, please read this manual and keep it for future reference. Notice This manual has been designed with the utmost care to ensure the accuracy of its content.
-
Page 3: Table Of Contents
Contents Getting Started Know your OBD (On-Board Diagnostics) Device Status LED Indicator Installing your OBD Device Manage Your OBD Device and Settings Connect Devices to your OBD Device’s Wi-Fi Reset the OBD Device Use Your OBD Device 4G Mobile Hotspot Configuration Security Credentials Security Change Wi-Fi Network Name and Password. -
Page 4: Getting Started
Getting Started Know your OBD (On-Board Diagnostics) Device OBDII interface Reset pinhole LED 2 LED 1... - Page 5 Getting Started LED Indicator Status LED indicator LED status LED 1 (Power) Device not being powered and/device is completely off LED 1 (Power) Green blinking slow 10 ms every 3 sec Device is in low power mode LED 1 (Power) Green solid Device is being powered by the vehicle while in operational mode LED 2 (Signal)
-
Page 6: Installing Your Obd Device
Installing your OBD device ● Download the T-Mobile SyncUP DRIVE Application from Google Play and the Apple Store. ● Log-in to your App and follow the onboarding process ● Make sure your vehicle is parked outside in a safe location and the engine is turned off. - Page 7 Connect devices with your OBD device’s Wi-Fi ● Connect your smartphone or other WPS (Wi-Fi Protected Setup) - enabled devices to your network: Use your normal Wi-Fi application on the client device to search for the available wireless network T-Mobile_Broadband## ●...
-
Page 8: Manage Your Obd Device And Settings
Manage Your OBD Device and Settings The SyncUP Drive OBD Dongle Device includes a 4G Mobile Hotspot accessible via local connectivity (Wi-Fi). It includes the newest 802.11 b/g/n/ac Wi-Fi connectivity, both for 2.4 and 5GHz, enabling an enhanced customer experience with the newest generations of smartphones or tablets. To personalize the OBD device and change the Wi-Fi settings, use the SyncUP DRIVE Application WiFi configuration menu: Wi-Fi ON/OFF... -
Page 9: Use Your Obd Device
This chapter describes the main features of the App for managing your OBD device. Wi-Fi Hotspot Configuration Screen Wi-Fi ON/OFF (by default: ON) Modify Wi-Fi local network SSID name (by default: T-Mobile Broadband XX) Modify Wi-Fi password (by default: set randomly in factory) Enable/Disable Wi-Fi... -
Page 10: Troubleshooting
Troubleshooting Physical Inspection Ensure that the Device is adequately plugged in the vehicle OBDII port. Refer to the LED Indicator Status section in this manual. Device Conditions Status via SyncUP DRIVE Application Within the SyncUP DRIVE Application Help Menu, you will be able to check historical and current information related to your Device conditions SyncUP DRIVE status Network... -
Page 11: Frequently Asked Questions
Frequently Asked Questions Problem Suggested Solution ● Cannot establish the Wi- Refresh network list and select correct SSID Fi connection between ● Refresh visible Wi-Fi networks from the client your device and client smartphone or tablet ● Device must be connected and the 2 LEDs in green solid mode ●... -
Page 12: Compatible Vehicles
Your vehicle will be automatically identified when installing your OBD device for the first time. However, if your experience missing features when using your device, visit the https://www.t-mobile.com/offers/syncup web page to check compatibility. Contact your customer care if your vehicle does not appear on the list.
