Replacing an SPE2 Power Supply
November 28, 2006
This document describes how to replace a power supply in an SPE2.
Handling field replaceable units (FRUs) .......................................... 2
Unlocking and removing the front bezel ......................................... 4
Removing a failed power supply module ........................................ 5
Installing a power supply module .................................................. 6
Installing and locking the front bezel .............................................. 7
Manager ...................................................................................... 8
Returning the failed part ................................................................ 9
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX3 UltraScale Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EMC2 CX3 UltraScale Series

Summary of Contents for EMC2 CX3 UltraScale Series

  • Page 1: Table Of Contents

    CX3 UltraScale™ Series Replacing an SPE2 Power Supply November 28, 2006 This document describes how to replace a power supply in an SPE2. Handling field replaceable units (FRUs) .......... 2 Unlocking and removing the front bezel ......... 4 Removing a failed power supply module ........5 Installing a power supply module ..........

  • Page 2: Handling Field Replaceable Units (Frus)

    Handling field replaceable units (FRUs) This section describes the precautions that you must take and the general procedures you must follow when removing, installing, and storing any field replaceable unit (FRU). Power issues and FRUs Your storage system is designed to be powered on continuously. Most components are hot repairable;...
  • Page 3 Use the ESD kit when handling any FRU. If an emergency arises and the ESD kit is not available, follow the procedures in the “Emergency procedures (without an ESD kit)” section. Emergency procedures (without an ESD kit) In an emergency when an ESD kit is not available, use the following procedures to reduce the possibility of an electrostatic discharge by ensuring that your body and the subassembly are at the same electrostatic potential.

  • Page 4: Unlocking And Removing The Front Bezel

    Unlocking and removing the front bezel To remove the front bezel, do the following: 1. Unlock the front bezel by turning the key at the front of the enclosure counterclockwise (Figure 1). 2. Press the buttons on the front of the bezel and pull the bezel toward you.

  • Page 5: Removing A Failed Power Supply Module

    Removing a failed power supply module Make sure the second power supply is working properly before removing the faulty power supply module. Verify that its power LED is green with no amber fault light. Removing a power supply 1. Unscrew the captive screw on the faulty power supply module’s latch and open the locking latch bar to release it (Figure 2).

  • Page 6: Installing A Power Supply Module

    Installing a power supply module To install a power supply module from the front of the cabinet, do the following: 1. Align the power supply module with the enclosure slot (Figure 3). 2. Make sure the locking latch bar is fully open before installing the power supply.

  • Page 7: Installing And Locking The Front Bezel

    Installing and locking the front bezel 1. While holding the front bezel by its edges, engage it with the two brackets on the front of the enclosure (Figure 4). 2. Push the bezel in until you feel it latch in place. Pull back on the bezel slightly to make sure it is secured (Figure 4).

  • Page 8: Verifying The Operation Of A New Or Replaced Part Using Navisphere Manager

    Verifying the operation of a new or replaced part using Navisphere Manager 1. Start Navisphere® Manager for the storage system by entering the IP address in a browser window. 2. In the Navisphere Manager Storage tree, locate the icon for the storage system in which you installed or replaced the part, expand the storage-system icon, and select the Physical icon.

  • Page 9: Returning The Failed Part

    Returning the failed part Ship the failed part to your service provider. To do this, follow the instructions in the return kit that was sent with the replacement part. Replacing an SPE2 Power Supply...
