- Page 1 SG3412 DEPLOYMENT GUIDE Streamcore.com Page 1 on 25 2021 Streamcore SAS - All rights reserved...
-
Page 2: Table Of Contents
Table des matières 1 Introduction ............................4 2 Preparing the deployment of the SG3412 ...................4 Task 1 - Unpack the SG3412 ........................4 Task 2 – Gather information and resources ....................4 Task 3 – Configure the appliance ....................... 4 Task 3 – Check the connectivity ........................ 5 3 Description of the SG3412 ........................5... - Page 3 Check connectivity with ping ........................24 Troubleshooting ............................. 24 7 Technical Specifications ........................24 Streamcore.com Page 3 on 25 2021 Streamcore SAS - All rights reserved...
-
Page 4: Introduction
If a backup SGM exists, the IP address of the backup SGM is also required. • IP address, mask of the SG3412 also called Administrative IP address. If two SG3412 are deployed in Dual or Tandem mode, an IP address and mask must be assigned to each SG. -
Page 5: Task 3 - Check The Connectivity
TASK 3 – CHECK THE CONNECTIVITY Refer to chapter Check Connectivity for this activity. 3 Description of the SG3412 UNPACKING THE SG3412 The SG3412 carton contains the appliance and some accessories: • 1 StreamGroomer SG3412 • 1 power supply cord and the power supply adapter •... -
Page 6: Rear Panel
There is traffic. REAR PANEL The rear side is composed of the interfaces for power supply, network, USB and management console. The figure below represents the rear panel of the SG3412. Power Console 2 WAN links The tables below describe the interfaces of the rear panel: •... -
Page 7: Configuring Boot Parameters
This interface is used as port to manage the SG3412 with the SGM. ADMIN An IP address will be assigned to this interface for that purpose. This interface is used to connect a second SG3412 to the appliance in order build the DUAL and TANDEM configurations. •... -
Page 8: Connect The Computer To The Sg3412
You have to connect a computer to on the console port of the StreamGroomer with the DB9 asynchronous cable (and the additional DB9 to USB adapter cable). The asynchronous cable is provided with the SG3412. The asynchronous cable has a RJ45 connector and a DB9 connector. -
Page 9: Maintenance Menu
Example 1: Display the software versions installed on the SG: [SG3412 > maintenance] show version Running OS : BOOT StreamCore-USINE-M4G64-S37-e1906c3689fe SG flash type : M4G64 SG type : SG3412 Streamcore.com Page 9 on 25 2021 Streamcore SAS - All rights reserved... - Page 10 : 22 [SG3412 > maintenance] Example 5: Show IP routing information: [SG3412 > maintenance] show iprouting Destination Netmask Gateway Metric Use 192.168.8.0 255.255.252.0 0.0.0.0 [SG3412 > maintenance] Streamcore.com Page 10 on 25 2021 Streamcore SAS - All rights reserved...
-
Page 11: Configuration Menu
Configuration file; pending configurations are still available. Enter the Configuration menu. Type the help command to get the list of available commands to configure the SG3412 as shown here: [SG3412 > maintenance] configure Welcome to Streamcore maintenance tool [SG3412 >... - Page 12 DNS server used by the SG (for admin purpose). It is needed for the web caching feature. dns_server1 [IP_add] dns_server2 [IP_add] Second DNS server used by the SG in case the first one does not answer. Streamcore.com Page 12 on 25 2021 Streamcore SAS - All rights reserved...
- Page 13 Last save date: Thu Sep 29 15:23:18 UTC 2016 version : 1.1 name : SG3412 admin_address : 192.168.8.181 admin_mask : 255.255.255.0 admin_gateway admin_port_speed : auto sgm_address : 192.168.8.180 sgm_address2 sgm_address3 sgm_address4 Streamcore.com Page 13 on 25 2021 Streamcore SAS - All rights reserved...
-
Page 14: Configure Streamgroomer Boot Ip Parameters With A Usb Key
In the Smart Service Tree, add a new site. • In the StreamGroomers Tree, add the StreamGroomer and fill all configuration information. 4.4.3 Download the boot file on the local host Streamcore.com Page 14 on 25 2021 Streamcore SAS - All rights reserved... -
Page 15: Load The Sg Configuration From The Usb Key
It check and imports the security parameters (password, optional strong SSH authentication…) The SG imports the other parameters. Finally, the SG generates a status of the procedure in the file named sgstatus_<sgname>.txt on the USB key. Streamcore.com Page 15 on 25 2021 Streamcore SAS - All rights reserved... -
Page 16: Case Of Strong Ssh Authentication
(and the other way around) without being processed by the SG. No statistics are produced by the SG in Boot mode. CONNECTING THE SG3412 The SG3412 manages 1 or 2 WAN access links. 5.1.1 Simple configuration – 2 WAN links The figure below shows how the SG is connected to the switches and the routers of a company. -
Page 17: Dual Configuration
Note that only LAN1 and WAN1 interfaces are used in Dual mode. LAN2 and WAN2 ports are ignored by the Streamcore software in this configuration. It is not necessary to connect them to the network. Refer to StreamView User Guide for further details. -
Page 18: Tandem Configuration
5.1.3 Tandem configuration The figure below explains the wiring to create a tandem configuration. LAN2 and WAN2 interfaces are not used in this configuration. Streamcore.com Page 18 on 25 2021 Streamcore SAS - All rights reserved... -
Page 19: Deploying The Sg3412
Figure 7 - SG3412 in Tandem configuration DEPLOYING THE SG3412 This section describes where and how to connect the SG3412 to network equipments to comply with the network requirements. It also describes the 4 configurations supported by Streamcore Software Suite, whatever the SG model. - Page 20 BETWEEN THE LAN AND THE SWITCH A SG can be transparently inserted in the LAN, in front of the switch: Figure 9 - SG in front of a switch, in the LAN Streamcore.com Page 20 on 25 2021 Streamcore SAS - All rights reserved...
-
Page 21: Manage A Single Wan Access Link
Refer to the paragraph 5.1.1 Simple configuration – 2 WAN links to know how to connect the SG to the switch and router. 5.2.3 Manage 2 WAN access links Streamcore.com Page 21 on 25 2021 Streamcore SAS - All rights reserved... -
Page 22: Implement High Availability (Tandem)
If the main SG fails, the secondary becomes active and continues operating on the network. To implement high availability with the SG3412, two appliances SG3412 must be installed on the network. The figure below shows that the appliances are connected with the EXT interface. Use crossover cables between the 2 SG. -
Page 23: Using The Ext Interface
2 WAN access links that are not close to each other. When the SG executes the Streamcore software version 6.2 and earlier versions, the management link between the SG on the EXT interface uses a layer 3 protocol. Although not recommended, the StreamGroomers can be connected through a router. - Page 24 Wait for the operational software reboot and the opening of the bypass Turn off the StreamGroomer Turn on the StreamGroomer The equipment will then automatically restart in boot software. 7 Technical Specifications The characteristics of the SG3412 are listed in the following table: Model SG3412 Height 4.4 cm...
- Page 25 Administration interface 10/100/1000 Base-T Console interface RJ45 USB port 2 x USB 2.0 FCC Class A Compliances RoHS LITHIUM METAL BATTERY Miscellaneous The SG3412 uses a lithium metal battery. Streamcore.com Page 25 on 25 2021 Streamcore SAS - All rights reserved...
