Quick Reference Guide - Viewing Section Status
Bin Status
Indicates if the bin is on
or off. Also indicates if the
bin is full or empty.
Desired Rate
Desired product rate of
flow.
Actual Rate
Actual product rate of
flow.
Fan Speed
Master Apply Status
Support: 877-912-5973
Section Status
Section is enabled
(green) or disabled (red).
If controlling sections
manually, tap a section
number to change status.
Task Controller Status
Select Off to manually
control each section.
Select On to let the
system control when
sections open and close.
www.intelligentag.com
Advertisement
Related Manuals for IntelligentAg ENGAGE SpreadControl
Summary of Contents for IntelligentAg ENGAGE SpreadControl
- Page 1 Actual Rate Task Controller Status Actual product rate of Select Off to manually flow. control each section. Select On to let the system control when Fan Speed sections open and close. Master Apply Status Support: 877-912-5973 www.intelligentag.com...
- Page 2 Positive numbers lengthen the actuator, and negative numbers shorten the actuator. c. Repeat the steps above for the left centered and left retracted positions. Then, calibrate all positions for the right funnel box. 600820-000038 Rev. 1.1 Support: 877-912-5973 www.intelligentag.com +1(701) 356 - 9222 support@intelligentag.com www.intelligentag.com...
