Saregama CARVAAN CBWY12 Installation Manual

MUSICBAR

I N S T A L L A T I O N

G U I D E

Table of Contents

Need help?

Do you have a question about the CARVAAN CBWY12 and is the answer not in the manual?

Page 1 MUSICBAR I N S T A L L A T I O N G U I D E...
Page 2 INSTALLATION KIT 2N WALLMOUNT BRACKETS (50*100) 2 PLASTIC FASTENER (4*32) 2 SELF THREAD SCREW (4*30) 4 SELF THREAD SCREW (2*6) 1 WALL MOUNT PAPER TEMPLATE 2 PLASTIC FOOT & SELF-ADHESIVE RUBBER FOOT...
Page 3 WALLMOUNT CARVAAN MUSICBAR Step 1: Fix the screws Stick the paper template in the installation kit using a tape on the wall. Mark the wall mount bracket hole location given on this template using a pen on the wall. Drill only centre hole at marked location and ﬁx the screws (4*30) along with plastic fasteners provided in the kit.
Page 4 Step 3: Hook the Caravan Musicbar on the wall Hook the brackets on the screws drilled on your wall. Connect HDMI cable before hanging. PLACE YOUR CARVAAN MUSICBAR ON A TABLE TOP Step 1: Fix the plastic foot pegs The installation kit comes with 2 plastic foot pegs. There are four holes (2 for each foot peg) on the bottom of the Carvaan Musicbar.
