Quick start proceDure

Additional software documentation may be available from
the Help menu item, as features may be added periodically.
Figure 2. Software Screenshot
HARDWARE SET-UP
Jumpers
MSPAN: Manual Span Control Pin. MSPAN is used to
configure the LTC2756 for operation in a single, fixed
output range. If MSPAN is 1 (high) it will be configured
for single span use. If MSPAN is low it will be set through
the QuikEval Software. Default position is 0 (low).
™
S0, S1, S2: Used to set the fixed output range if MSPAN
is 1 (high).
Table 1. MSPAN Configuration
S2
0
0
0
0
1
1
GEADJ: Gain Adjust Pin. If no adjustments are required,
select GND. Selecting EXT. connects the pin to the turret
allowing external adjustment to null gain error or com-
pensate for reference errors.
VOSADJ: Offset Adjustment Selection for DAC. If no
offset adjustment is required, select GND. Selecting EXT
connects the offset pin to the turret allowing external
adjustment of offset.
2
