- Page 1 Mounting Instructions DynamicCableRetract AHD2DOC01...
- Page 2 Not complying with these direction will result in a lost of the Arthur Holm warranty. Albiral Display Solution S.L. shall not be held liable for any loss or injury incurred as a result of modifications made to goods by anyone other than the supplier or the supplier's authorised representative without the supplier's written permission.
- Page 3 DynamicCableRetract Dimensions Cut a hole in the table surface where the DynamicCableRetract top surface will be installed. Ensure that there is enough space under the table to install the DynamicCableRetract. The output of the cable and connections of the device are in the back side (As shown in the picture).
- Page 4 If the cut-out in the table can’t be made with precision, a Cover Plate is supplied in order to hid the cut imperfections. DynamicCableRetract can be installed in tables with a thickness from 10mm [0,39] to 50mm [1.97]. For thickness over 50mm it will...
- Page 5 A jig is supplied in order to mark the holes and to make the installation easier. Mounting Jig 1- Make the cut out according to 2- Place mounting jig in the table the provided pattern hole in the bracket as indicated below. table surface.
- Page 6 Place the brackets as shown in the drawing and tighten them down using the nuts (M4). Place the vertical adjustment screws (2+2) in to the bracket so that the tip of the screw is flushed with the upper side of the bracket. Preparing the DynamicCableRetract...
- Page 7 Tighten each gradually until DynamicCableRetract top plate surface is flush with of the table surface or cover plate: View from above the table For the standard installation, flush the top plate surface with the top surface of the table.
- Page 8 There is a M6 screw in every corner, tighten one more than others level DynamicCableRetract top surface with the top surface of the table or Cover Plate. 4- Tighten x4 M6 screws to block the device Assembling with Cover Plate...
- Page 9 With the DynamicCableRetract is supplied a Cover Plate. This Cover Plate can help to hid the cut out of the table if it can not be made properly. Follow next steps to stick the Cover Plate to top surface. 1- Clean the table Surface where the Cover Plate is goning to be taped.
- Page 10 w w w . a r t h u r h o l m . c o m...
