Packing list:
* Gas Cooktop body
* Burner cap
* Pan Support
* LPG Nozzles
* 1/2'' Tracheal connector+Rubber gasket
* 5/8'' copper adapter
* 7mm Socket Wrench
* The Sponge article
* Manual book
1 pcs
1 set(5 pcs)
1 set(3 pcs)
1 set(5 pcs)
1 set
1 set(2 pcs)
1 pcs
1 Roll
1 pcs
GAS COOKTOP MANUAL
JZS75012
JZS75013
Advertisement
Table of Contents
Related Manuals for Trifecte JZS75012
Summary of Contents for Trifecte JZS75012
- Page 1 1 set(3 pcs) * LPG Nozzles 1 set(5 pcs) * 1/2’’ Tracheal connector+Rubber gasket 1 set * 5/8’’ copper adapter 1 set(2 pcs) * 7mm Socket Wrench 1 pcs * The Sponge article 1 Roll * Manual book 1 pcs JZS75012 JZS75013...
- Page 2 MAINTAIN THE FOLLOWING MINIMUM FIRE OR EXPLOSION HAZARD CLEARANCE DIMENSIONS If the information in these instructions is not followed exactly,a fire or explosion may result causing property damage,personal injury or death. Read these instructions completely and carefully. When installing a gas appliance the use of old flexible connectors can cause gas leaks and personal injury.Always use a new flexible connector.
- Page 3 INSTALLING THE COOKTOP The silver galvanized brackets to the bottom of the cooktop(on all the models) A. locate electric outlet and gas shut-off valve beneath cabinet. B. Locate and remove hold-down brackets from literature package. C. Insert the cooktop centered into the cutout opening.Make sure the front edge of the countertop is parallel to the cooktop.
- Page 4 CHECK SURFACE Quality of Flames ELECTRICAL CONNECTIONS BURNERS Determine the quality of flames visually.Normal burner flames Push and turn a knob to the IGNITE Shock Hazard:This appliance must be properly should look like(A) or (B). position.A clicking sound indicates grounded.Failure to do so can result in electric shock. (A)Soft blue flames- proper operation of the ignition Electrical Requirements--110-120volt,60Hz,properly grounded circuit protected by a...
- Page 5 Adapting To Different Types of Gas Matters needing attention Before carrying out any maintenance work,disconnect the appliance from the gas and A. Before installation,along the inside of the four edges of the hob, paste sponge electric supply. strips to buffer the friction between the hob and the cabinet panel. To change the nozzles of burners use the following procedure: B.
- Page 6 K. Cleaning of the enameled parts:to maintain the features of the enameled parts they must be cleaned frequently with soapy water.Never use the abrasive powders.Avoid leaving acid or alkaline substances on the enameled parts(vinegar,lemon juice,salt,tomato juice etc.) and washing the enameled parts when they are still warm.
