  • Page 1 Control Units ABT-CU-8LCD ABT-CU-11LT ABT-CU-11LCD User Manual EN 54-16: 2008 1488-CPR-0500/W ver. 04.2020 www.ambientsystem.eu...
  • Page 2: Table Of Contents

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Table of Contents 1. Safety __________________________________________________________________________________ 2. Control units ___________________________________________________________________________ ABT-CU-8LCD control unit ________________________________________________________ ABT-CU-8LCD rear panel _________________________________________________________ ABT-CU-11LCD control unit _______________________________________________________ ABT-CU-11LT control unit ________________________________________________________ ABT-CU-11LT / ABT-CU-11LCD rear panel __________________________________________ 3.
  • Page 3: Safety

    1. Safety Danger! High risk: This symbol indicates an imminently hazardous situation such as "Dangerous Voltage" inside the product. If not avoided, this will result in an electrical shock, serious bodily injury, or death. Warning! Medium risk: Indicates a potentially hazardous situation. If not avoided, this could result in minor or moderate bodily injury. Caution! Low risk: Indicates a potentially hazardous situation.
  • Page 4 Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat or in direct sunlight. No naked flame sources, such as lighted candles, should be placed on the apparatus.
  • Page 5 Do not disassemble the device or attempt to repair or modify it. The device does not include user replaceable components inside the chassis. Opening the chassis and unautho- rized repairs will void the warranty. Unauthorized substitutions may result in fire, electric shock or other hazards.
  • Page 6 Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual This label may appear on the bottom of the apparatus due to space limitations. Caution! To reduce the risk of electrical shock, DO NOT open covers. Refer servicing to qualified service personnel only.
  • Page 7: Control Units

    ABT-CU-8LCD is a matrix mixer for input signals. It assigns input signals to four internal audio buses 100 V, a 28-channel digital system bus or directly to audio outputs in the unit. ABT-CU-8LCD plays a role of a primary MULTIVES system controller.
  • Page 8: Abt-Cu-8Lcd Rear Panel

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual ABT-CU-8LCD rear panel Fig. 2. Rear panel of ABT-CU-8LCD Power supply, two identical connectors Connector for 100 V amplifier output to supply internal BUS available for all control cards Communication card slot, 1 item...
  • Page 9: Abt-Cu-11Lcd Control Unit

    ABT-CU-11LCD control unit ABT-CU-11LCD control unit was designed to perform minor VAS systems or as an extension unit in complex systems. In case of lack of connection with the superior unit, thanks to local configura- tion, it is able to carry out fire scenarios. The device attached to the main system communication “ring”...
  • Page 10: Abt-Cu-11Lt Control Unit

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual ABT-CU-11LT control unit ABT-CU-11LT control unit was designed to perform minor VAS system or serve as an extension unit in complex systems. In case of lack of connection with a superior unit, thanks to local configuration, itis able to carry out a fire scenario.
  • Page 11 Audio input Audio outputs Logic inputs/outputs Optical fiber connectors RS485 communication port LAN PoE port LAN/WAN port LAN port Fig. 6. Diagram of dedicated communication card of ABT-CU-11LT / ABT-CU-11LCD control unit Fig. 7. Rear panel of ABT-CU-11LT / ABT-CU-11LCD – example of extension card arrangement Power supply 48 V DC Connector for 100 V amplifier outputs to supply internal BUS available to all control cards RJ-45 connectors, LAN with PoE, 2 items...
  • Page 12: Connecting Control Units

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual 3. Connecting control units CHAIN typology In CHAIN typology, the connection is not redundant. Connecting units in this system does not guar- antee efficiency operation of the system in the event of communication cable damage. According to PN-EN 54-16 norm, connections between VAS control units in the distributed system must be redundant.
  • Page 13: Ring Typology

    In RING typology, the connection between system elements is redundant. The wires do not have any tips, but form a ring. In the event of cable/communication optic fiber damage, the system still functions by using the remaining part of the ring. ABT-CU-8LCD ABT-CU-11LT ABT-CU-11LT Fig.
  • Page 14: Individual Connection Without Backup Amplifier Using Abt-Cu-11Lt / Abt-Cu-11Lcd

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Individual connection without backup amplifier using ABT-CU-11LT / ABT-CU-11LCD Individual connection of each of the amplifier channels with control cards without backup amplifier. ABT-PA8080B Channel 4 IN Channel 3 IN Audio OUT4...
  • Page 15: Connection With 100 V Internal Buses Using Abt-Cu-11Lt / Abt-Cu-11Lcd

    Connection with 100 V internal buses using ABT-CU-11LT / ABT-CU-11LCD ABT-PA8080B Channel 4 IN Channel 3 IN Audio OUT4 Audio OUT3 Audio OUT2 Audio OUT1 Channel 2 IN ABT-ISLE Channel 1 IN ADDRESS RS485 RS485 AUDIO OUT ABT-CU-11LT ABT-PSM48 POWER SUPPLY MANAGER Fig.
  • Page 16: Individual Connection With Backup Amplifier Using Abt-Cu-11Lt / Abt-Cu-11Lcd

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Individual connection with backup amplifier using ABT-CU-11LT / ABT-CU-11LCD Individual connection of each of the amplifier channels with control cards with backup amplifier (possible to connect up to 4 backup channels/amplifiers). ABT-PA8080B...
  • Page 17: Connection Between Power Supply Manager And Control Unit

    Audio OUT4 Audio OUT3 Audio OUT2 Audio OUT1 Channel 2 IN ABT-ISLE Channel 1 IN ADDRESS RS485 RS485 AUDIO OUT ABT-CU-8LCD ABT-PSM48 POWER SUPPLY MANAGER Fig. 13. Connection between Power Supply Manager ABT-PSM48 and Control Unit by audio / RS interface ABT-ISLE...
  • Page 18: Power Supply

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Power supply ABT-PA8160B ABT-PA8080B ABT-CU-8LCD ABT-PSM48 POWER SUPPLY MANAGER Fig. 14. Power supply diagram...
  • Page 19: Technical Data

    4. Technical data Technical data of ABT-CU-8LCD Model ABT-CU-8LCD 48 V DC (operating range 40-57 V DC) Power supply connector with screw terminals M2.5, the distance between the partitions of 5.08 mm Power consumption Up to 60 W (depends on configuration)
  • Page 20: Technical Data Of Abt-Cu-11Lcd

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Storage temperature -20°C / +70°C Storage Humidity 15% to 80% (non-condensing) Finish Case Material Steel / The front panel is made of metal plate painted black Dimensions 482 (W) × 85 (H) × 325 (D) mm Mounting 19˝...
  • Page 21 Connector type 3 × RJ45 Frequency response 40 Hz… 20 kHz (@1 dB) / 400 Hz… 8 kHz (@0,1 dB) Harmonic distortion ≤ 0,05% (THD + IMD) Headroom 10 dB ≥ 90 dB Channel separation ≥ 80 dB Output impedance 600 Ω...
  • Page 22: Technical Data Of Abt-Cu-11Lt

    Control Units ABT-CU-8LCD / ABT-CU-11LT / ABT-CU-11LCD User Manual Technical data of ABT-CU-11LT Model ABT-CU-11LT 48 V DC (operating range 40-57 V DC) connector Power supply with screw terminals M2.5, the distance between the partitions of 5.08mm Power consumption Up to 100 W (depends on configuration)
  • Page 23 Communication between devices over large distances: Ű 1000BASE-X on the fiber Ű 2 ports provide a redundant connection Communication between devices installed side by side Ű 1000BASE-TX / RJ45 CAT5E cables – 2 ports available on the back panel. Data communication Ű...
  • Page 24 Ambient System Sp. z o.o. ul. Bysewska 27 | 80-298 Gdańsk | Poland T: +48 58 345 51 95 | ambient@ambientsystem.eu EN 54-16 certified by Building Research Institute www.ambientsystem.eu...
