Ultra Violet Germicidal Disinfection

Technical Overview .................................................................................................................................................................. 2

I. Important Notes ................................................................................................................................................................ 2

II. UV Specifications .............................................................................................................................................................. 2

III.WARNING .......................................................................................................................................................................... 3

IV. Before You Purchase/Open ............................................................................................................................................ 3

V. Before You Begin Installation .......................................................................................................................................... 4

VI. What is Standard Filtration ............................................................................................................................................ 4

VII. Product Application: What is UV light and How Does It Work?.................................................................................... 4

IX. Installation with other Systems ..................................................................................................................................... 5

Installation Introduction.......................................................................................................................................................... 5

I. Site Preparation ................................................................................................................................................................ 5

II. Stainless Steel Enclosure ................................................................................................................................................. 6

III. System Installation & Mounting ..................................................................................................................................... 6

IV. Installing Connections .................................................................................................................................................... 6

V. Filter Protection................................................................................................................................................................ 6

VI. Pressure Gauge Installation ........................................................................................................................................... 7

VII. Cartridge Installation .................................................................................................................................................... 7

Ultraviolet System Installation ............................................................................................................................................... 8

I. Thimble (Quartz Tube) Installation .................................................................................................................................. 8

II. UV Lamp Installation ..................................................................................................................................................... 10

III. Ballast Operation .......................................................................................................................................................... 11

System Start Up & Operation ................................................................................................................................................ 13

I. Plumber Commissioning ................................................................................................................................................ 13

II. Turning the System On/Off ............................................................................................................................................ 13

Maintenance ........................................................................................................................................................................... 13

I. Stainless Steel Enclosure + Filter Housing Replacement Parts .................................................................................... 13

II. Replacement Cartridges ................................................................................................................................................ 13

III. Testing Filters ................................................................................................................................................................ 14

Whole House Filtration

System with UV in

SS Enclosure

Contents

Page 1 of 21

Table of Contents

Need help?

Do you have a question about the HPFUV and is the answer not in the manual?

Questions and answers

Summary of Contents for HPF HPFUV

Page 1: Table Of Contents
Ultra Violet Germicidal Disinfection Whole House Filtration System with UV in SS Enclosure Contents Technical Overview .................................. 2 I. Important Notes ................................2 II. UV Specifications ................................2 III.WARNING ..................................3 IV. Before You Purchase/Open ............................3 V. Before You Begin Installation ............................4 VI.
Page 2: Technical Overview
IV. UV System Replacement Parts & Maintenance ......................14 V. Lamp Replacement ................................ 14 VI. Thimble (Quartz Tube) Replacement .......................... 14 Troubleshooting ..................................16 Warranty ....................................20 I. General Warranty ................................20 II. Qualification for Warranty ............................. 20 III. Exclusions ..................................20 IV.
Page 3: Iii.warning
III.WARNING This appliance must be installed directly into a single socket surge protector before being connected to a 240V 10A General Power Outlet (Power Point). It must be a surge protector - Circuit Breakers and Residual Current Devices (RCDs) are not suitable substitutes as they do not protect the unit from power surges.
Page 4: Before You Begin Installation
V. Before You Begin Installation The HPF-UV systems come pre-assembled on the bracket with centre joiners installed. These units are batch tested to ensure there are no leaks. Due to transit, fittings and other components may be loosened or damaged –...
Page 5: Installation With Other Systems
I. Site Preparation The HPFUV System will need to be installed on the water line between the water supply and your house. Ideally if you can find where the cold water enters the building or tees off to the HWS. Either way, you will need access to modify the pipe work to install the system in place.
Page 6: Stainless Steel Enclosure
IV. Installing Connections The HPF-UV system has a standard 1” Female BSP port for the inlet connection into the stage 1 Big Blue filter housing. The outlet point from the UV system has an internal and external thread to choose from depending on the installation requirements (i.e.
Page 7: Pressure Gauge Installation
VI. Pressure Gauge Installation The HPF-UV system is supplied pre-fit with gauges, if the gauges are to be removed or replaced, follow the below. Kit Contains: Opening Spanner, Pressure Gauges (If applicable), Gauge Port Bungs, O-Rings Install with Gauge Plugs: The housings are supplied with a thin o-ring is a zip-lock bag. Install this o-ring into the gauge port then screw in the gauge plugs firmly without thread tape.
Page 8: Ultraviolet System Installation
Ultraviolet System Installation I. Thimble (Quartz Tube) Installation Due to the fragile nature of the thimble, care must be taken when handling and installing the thimble and lamp. The below steps are for horizontal installations. 1. Remove the knurled nuts from either end of the UV chamber (shown below). Knurled Nut 2.
Page 9 4. When the O-rings are seated, firstly loosely install the bottom nut and then the top nut until you feel resistance. Simultaneously tighten (by hand) the top and the bottom nut equally to keep the thimble centred in the chamber. Caution: Do not apply any thread tape, grease, or sealant as this will void the warranty.
Page 10: Uv Lamp Installation
II. UV Lamp Installation Once the chamber has been pressure tested and there are no water leaks, the lamp can be installed. It is usually recommended to complete step 1 to 4 of I. Plumber Commissioning (below) before installing the lamp. 1.
Page 11: Ballast Operation
III. Ballast Operation This appliance must be installed directly into a single socket surge protector before being connected to a 240V 10A General Power Outlet (Power Point). It must be a surge protector - Circuit Breakers and Residual Current Devices (RCDs) are not suitable substitutes as they do not protect the unit from power surges.
Page 12  Temporary (7 Day) Alarm Pause/Cancellation: If the UV lamp cannot be immediately replaced, you can temporarily pause the alarm by pressing the “SELECT” button for 5 seconds until the buzzer sound stops. This will reset the Lamp Life Remaining display to 7 days, however, the display will continue to show “A3”...
Page 13: System Start Up & Operation
System Start Up & Operation I. Plumber Commissioning When you are confident that the system is correctly installed, do the following steps to start up the system and commence the flushing procedure. 1. Open a tap downstream from the system to allow air to bleed from the plumbing – if this is not easily achievable disregard, just note that sputtering may occur more prevalently in the house until the air has vented from the lines.
Page 14: Testing Filters
23mm OD O-Rings Replacement Ballast H7-90-PS HPF Electronic Ballast | 33W – 120W with Countdown Timer V. Lamp Replacement CAUTION: DO not touch the Lamp with your fingers. Handle by the ends only or wear soft non-abrasive heat-resistant gloves to prevent any finger marks or burning.
Page 15 a. Remove the input/output water pipe connector and withdraw the reactor chamber. b. Carefully remove as much of the broken thimble as possible from both ends of the chamber. c. To remove any fragments of glass, hold the system vertically and shake. The fragments will break and drop out from threaded fitting of the chamber.
Page 16: Troubleshooting
Troubleshooting In order to maintain UV unit in optimum operation condition, if specific problems are detected during the routine inspection, refer to applicable maintenance instructions for recommended repair procedure. Problem Possible Cause(s) Solution Twin 20” x 4.5” Filter System Leaking from Centre 1.
Page 17 pH levels in lower EC water (i.e. The guy at the pool shop is not going to cut it). We have access to high quality testing equipment and frequently test our units and conduct research. If you feel that there is an issue with your pH, please contact us.
Page 18 short distance between the outlet and the point of use. Whole house systems have a larger length of cold plumbing pipes downstream. 2. Oversized System 2. If the system is too large for the application it is likely that even with frequent water usage the water does not get a chance to cool down effectively.
Page 19 enough power from the ballast. The lamp will require replacement. Turn the system off, check connections and turn back on to see if it fixes the 2. Faulty ballast alarm. 2. The ballast could have a problem with the lamp failure protection and may require replacement.
Page 20: Warranty
HPF will not cover any labour charge incurred by the consumer for the replacement or repair of a product. The warranty is strictly parts only for the parts supplied by HPF. This warranty only applies to the original consumer of the product and is non-transferable.
Page 21: Extended Warranty Qualification
Sanitation Categories – Excluding Cartridges and Shower Filters. ² Other products not manufactured or assembled by HPF are covered under the applicable manufacturer’s warranty. ³ HPF specifies recommended or required filter maintenance – see product information for further details. If a maintenance schedule is not specified, filter maintenance is required at least once per 12-month period.
