Ref. 1795 GB - 4.33 / a - 11.00 Terminal cover Terminal cover IP 20 - START Protection kit for DIGISTART STV 2313 Installation...
Page 2
IP 20 - START 1 - GENERAL 1.2 - Kit composition 1.2.1 - IP 20 - START - 1 • It is the responsibility of the Number Description Quantity owner or user to ensure that the Support installation, operation and maintenance of the STV 2313 and its options are Movable part carried...
Page 3
Note: The 6 screws (3), the 6 prestole rings (4) and both "PLEXO" cable glands are supplied mounted on the cover (2). 1.3 - Dimensions and weight IP 20 START Height added to the Weight (kg) Reference STV 2313 (mm)
Page 4
IP 20 - START b) Slide the movable part 2 into the top h) Slide the terminal cover (3) into the slot part of support 1, repeat for the second in the support and fix it in place using the movable part.
Page 5
IP 20 - START 2.2.2 - IP 20 - START 2 a) Remove the STV 2313 terminal covers. Terminal cover Fixing lugs Note: The upper protective cover is distinguished from the lower protective cover by the different cutout shape. Terminal cover b) Slide the movable part 2 into the top part of support 1, repeat for the second movable part.
Page 6
IP 20 - START e) Position the parts assembled in b) at each end of the STV 2313 and fix in place with the screws (6). Motor cables Position for the bottom of the STV 2313. Fixing lugs j) Partially tighten both screws (6) on the captive nuts, slide the terminal cover (3) f) Insert the STV 2313.
Page 7
IP 20 - START 2.2.3 - IP 20 - START 3 c) Undo the screws (3) and remove the a) Remove the terminal cover and 3 SIM cover (2). No. 8 screws from the bottom of the STV 2313. 3 SIM No. 8 screws removed d) Insert the STV 2313.
