ZETR 25 Installation Manual

25-4P-DACC-BS7
TO O L S R E Q U I R E D
PH2 PH1
DRIVER DRIVER
WWW.ZETR.COM.AU / CONTACT@ZETR.COM.AU
25 POWER & DATA SYSTEM
AT T E N T I O N
THE SAFETY OF THE DEVICE IS GUARANTEED WHEN THE INSTRUCTIONS
AND USE ARE IN-LINE WITH THOSE OUTLINED. IT IS RECOMMENDED
THAT THIS MANUAL IS STORED SAFELY AND REFERRED TO
THROUGHOUT THE LIFE OF THE DEVICE.
D A N G E R
ELECTRIC SHOCK, EXPLOSION OR ARC FLASH HAZARD
Hazardous voltage and electrical current may be present at the wire leads of
this product even when the device is switched off.
WA R N I N G
WHEN CARRYING OUT INSTALLATION OR MAINTENANCE, IT IS ESSENTIAL
TO ISOLATE SUPPLY AND FOLLOW THE CORRECT LOCK OUT AND TAG
PROCEDURE AT THE POINT OF SUPPLY BEFORE ACCESSING THE DEVICE.
- The device must be installed
according to the instructions
outlined in this document.
- The device must be installed
with care, by a licensed electrician/
tradesman
- Installation must comply with
Australian and New Zealand
standards ASNZ3000.
- Pay attention to the wiring
diagrams and specifications related
to the installation.
- Do not use this product for any
other purpose than specified in this
manual.
I N T H E B OX
18-40MM UNDERCARRIAGE
SUBSTRATE
[NOT INCLUDED]
- If any part of the device is
damaged prior to installation it
must be replaced/repaired by the
manufacturer or licensed service
agent prior to installation
- The device must not be modified,
or force fit. Any modification or
non-compliant installation will
jeopardise system safety and/
or result in equipment damage or
malfunction.
- ZETR forfeits any liability and
warranty for any modified product
and/or installation
FACEPLATE
MECHANISM
GRID
LEVELING
FASTENER
