INTEGRATED
FREEZER -
ILFRZ217 /2
I
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ILFRZ217I/2 and is the answer not in the manual?

Questions and answers

Related Manuals for ILVE ILFRZ217I/2

Summary of Contents for ILVE ILFRZ217I/2

  • Page 1 INTEGRATED FREEZER - ILFRZ217 /2 USER MANUAL...
  • Page 2 FREE MASTERCLASS Although we encourage you to dive right in, as the owner of a brand new ILVE oven we’d also like to invite you to attend a complimentary 2 hour masterclass. As part of the class you’ll learn how to prepare and cook a number of delicious signature ILVE dishes, not to mention our top tips for getting the most out of your ILVE oven.
  • Page 5 OPEN 24 ILVE ACCESSORIES ONLINE SHOP For a wide range of Genuine ILVE accessories at the click of a button go to ilve.com.au...

  • Page 6: Table Of Contents

    Contents: Important information Important notes Before first use Important notes on use of the freezer Storage Control panel 10 Care and cleaning 11 Defrosting the freezer 11 Changing the light 12 Troubleshooting 14 Installation preparation 14 Ventilation requirements 16 Installation into the cabinet 17 Mounting the fascia door 19 Reversing the appliance door 20 Electrical information...
  • Page 7 Important The manufacturer cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that we reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance.

  • Page 8: Important Information

    This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Electrical safety (LVD) and Electromagnetic interference compatibility (EMC). Parts intended to come into contact with food conform to 1935/2004/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.

  • Page 9: Before First Use

    Important Never store inflammable or explosive items and strong corrosive • acids or alkalis in the appliance. This is a household appliance, which is produced in accordance • with the national standard. It is intended for food storage only, not for storage of blood, medicine and biological products.
  • Page 10 The freezer may have an odour to it at first use. This will disappear as the appliance cools. Please note: The appliance will start on temperature setting 3 and work continuously until it comes down to the correct temperature. If the appliance is switched off, you should allow five minutes before switching it on again to prevent unnecessary damage to the compressor.
  • Page 11 Label the food before freezing with information including type of • food and dates of storage and expiry. Once food is thawed, it must not be refrozen unless it has been • completely cooked. Only defrost as much food as is required to prevent wastage.

  • Page 12: Storage

    Storage The freezer is for short-mid term food storage. Although low temperatures can be maintained, extended periods of food storage is not recommended. As the cold air circulates within the freezer, the temperature can vary between the different sections. As such, foods should be stored in different sections according to type and storage term.

  • Page 13: Control Panel

    Control panel Fig. 3 A. Freezer temperature adjustment sensor This button is used to adjust the temperature within the freezer. Press this sensor once to activate adjustment, and then as many times as necessary until the desired level is selected. The settings range from 1 to super freeze (snowflake) with 1 being the warmest and super freeze being the coldest.

  • Page 14: Care And Cleaning

    Care and cleaning Always disconnect the appliance from the power supply before any cleaning or maintenance. The drawer sections should be cleaned using a solution of bicarbonate of soda and lukewarm water. Do not use abrasive products or detergents. After washing, rinse and dry thoroughly. Clean the compartments separately by hand with a mild solution of washing up liquid and water.

  • Page 15: Defrosting The Freezer

    Defrosting the freezer The freezer is self-defrosting. Any water created will run out through the channel at the back of the freezer, unless the drain hole is blocked. The defrosted water is collected in the evaporating tray at the back of the appliance and dissipated by evaporation (when the compressor gets hot).

  • Page 16: Troubleshooting

    Troubleshooting If you have any problems with your appliance, you should check the troubleshooting prior to calling Montpellier Customer Care. If the appliance is not working, check: That there is power to the appliance. • The house fuses are intact and the fuse in the plug has not •...
  • Page 17 If the appliance is beeping, check: That the door is closed. An alarm will sound after approximately • 60 seconds of a door being open. If there’s water in the base of the freezer, check: Check that there is some resistance when opening the door of the •...

  • Page 18: Installation Preparation

    Installation preparation 560-570 550 min. This appliance must never be installed close to heat sources, e.g. heating elements or cookers, nor in damp 1780 places. 1770 Seek the help of another individual, or min. 30 two, when installing this appliance. This appliance may have sharp edges.
  • Page 19 consumption, total system failure and may invalidate the warranty provided with the appliance. For products intended to be installed into a tall housing unit, the following requirements need to be met: Refrigerator The top of the cabinet needs to be outline An air intake should vented into the room...

  • Page 20: Installation Into The Cabinet

    be drawn over the compressor & heat exchange.The required air flow can be achieved by removal of a thin section of plinth (recommended 600mm x 10mm minimum). As a rule, the more air that can get in and out, the better and more efficient the operation of the product.

  • Page 21: Mounting The Fascia Door

    Secure the top of the appliance to the top of the cabinet through the metal trim screw holes marked ‘T’ in fig 10. Trim Fig. 10 Remove the white spacers from the base plates and secure the plates to the cabinet base using four of the supplied screws. Replace the spacers.
  • Page 22 Once complete, and if you are happy with the fit of the appliance in the cabinet, bend and snap the parts of the white spacers marked ‘S’ as shown by the dotted outline in fig. 13. Leave the rest of the spacer cover in place over the metal plates.

  • Page 23: Reversing The Appliance Door

    Reversing the appliance door We recommend you seek the help of another individual to support the doors whilst performing this operation. Always wear adequate PPE (Personal Protective Equipment) for the task at hand. Prepare a surface with a soft, clean towel or similar where you can place the door during these steps.
  • Page 24 adequate. When completed, allow the seal and door to cool before touching them. Once done, the seal should remain in position. Warning; Risk of fire / flammable materials This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 25: Electrical Information

    Please according to local regulations regarding disposal of the appliance for its flammable refrigerant and blowing gas. If the LED lamp is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard WARNING: To avoid a hazard due to instability of the appliance, it must be fixed in accordance with the instructions Electrical information...
  • Page 26 REGISTER YOUR WARRANTY ONLINE NOW GO TO: ilve.com.au > support > product registration As a part of our continued customer service offering, you can now register your ILVE products online at ilve.com.au > support > product registration Just follow our simple online registration process.
  • Page 27 We ask that you complete the installation; enclosed Warranty Registration Card and return it to us so that we have a record of the ILVE (d) use or operation after a defect has occurred or product purchased by you, Alternitivley, you can been discovered;...
  • Page 28 Address: State: Postcode: Email: Home Phone: Mobile: Purchase Date: (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ILVE on 1300 85 64 11) ILVE Operating Manual 01072021...
  • Page 29 LUXURY KITCHEN APPLIANCES 1/42 Cavendish Rd Coorparoo, QLD 10/55 Howe St Osborne Park, WA 48-50 Moore St Leichhardt, NSW NATIONAL SERVICE CENTRE Our high quality appliances are designed and manufactured to give you many years of cooking pleasure. Should you have any questions or issues with your appliance please email our national service centre customercare@eurolinx.com.au or phone us on 1300 85 64 11.
