Overview Geekworm NASPi Gemini is an ultra-compact dual 2.5-inch SATA HDD/SSD NAS storage kit with safe shutdown and auto power on function that specially designed for Raspberry Pi 4 Model B computer, it allows two pcs 2.5" HDD/SSD to working at the same time with your Raspberry Pi 4. Also support use with one single 2.5"...
Page 3: Interface Schematic
Interface Schematic https://geekworm.com Support: support@geekworm.com - 3 -...
Page 4 Support: support@geekworm.com - 4 -...
Page 5 Support: support@geekworm.com - 5 -...
Page 6 Dimensions https://geekworm.com Support: support@geekworm.com - 6 -...
Page 7: Naspi-Gemini Packing List
NASPi-Gemini Packing List 1 x NASPi Gemini Metal Case  1 x X882 V1.3 Dual 2.5 SATA SSD/HDD Shield  1 x X823-A3 metal bracket with PWM fan  1 x screws pack accessories  https://geekworm.com Support: support@geekworm.com - 7 -...
Page 8: How To Power
How to Power 1. Via USB-C port of X882, 5.1Vdc +/-5%, ≥ 4A （ Geekworm USB-C 5V 4A 20W power supply is recommended） 2. Via DC5521 Jack of X882, 5.1Vdc +/-5%, ≥4A (DC5525 Jack is compatible with DC5521, also support 5V PSU with DC5525 Jack) Note about PSU: Please use high quality power adapter, or the HDD/SSD may cannot be recognized.
Page 9 [NOTE] Once you set the RAID mode successfully, you need to partition & format & mount the HDD/SSD, so that it can be recognized by your Raspberry Pi OS. please refer to How to View/Partition/Format/Mount HDD/SSD https://geekworm.com Support: support@geekworm.com - 9 -...
Page 10: Software Guide
Software Guide https://wiki.geekworm.com/X-C1_Software or scan QR Code Installation Video https://youtu.be/7FzZeoTBQiI or scan QR Code Software Guide of script installation, please fast forward video to 5 minutes 10 seconds. You can also search “Geekworm” on Youtube. https://geekworm.com Support: support@geekworm.com - 10 -...
Page 11: Faq
A: The read and write performance is determined by the speed of the Raspberry Pi’s USB 3 bus and SSD. It should be noted that the Raspberry Pi’s USB3 bandwidth is only 3Gbps. Normally, the R/W speed is about 300MB/S. https://geekworm.com Support: support@geekworm.com - 11 -...
Page 12: Appendix
Properly Mount USB Storage on Raspberry Pi Auto Mount an NTFS USB Drive on Raspberry Pi Difficulty booting from SSD drive How to View/Partition/Format/Mount HDD/SSD Customer Service Support: support@geekworm.com(Please attach order number and issue details.) https://geekworm.com Support: support@geekworm.com - 12 -...
Page 13: Manual Revision History
Manual Revision History: Date Description Author 2022-05-12 Create document Cindy https://geekworm.com Support: support@geekworm.com - 13 -...
