U-Prox IC E Installation And Programming Manual

Access control panel

Advertisement

Quick Links

1.003
Access control panel
U-Prox IC E
(Elevator control)
Installation and programming manual

Advertisement

Table of Contents
loading

Summary of Contents for U-Prox IC E

  • Page 1 1.003 Access control panel U-Prox IC E (Elevator control) Installation and programming manual...
  • Page 2 About this document his manual covers installation, adjustment and use of U-Prox IC E (hereinafter panel) access control panel. Read this manual carefully prior to installing the system. Characteristics, Intended use and parameters of the panel are described in the section "Summary".
  • Page 3: Table Of Contents

    Contents Brief description of the panel ......................4 Summary ............................4 Terms ............................5 Description and operation ......................6 Panel ............................6 Assignment of the panel contacts and indication ..............7 Light emitting diodes (LED) ....................8 Reader’s annunciation ......................8 Panel operation ........................
  • Page 4: Brief Description Of The Panel

    Brief description of the panel U-Prox IC E control panel - a device designed to control access to stores of residential and business premises, including time of passage and events. Panel operates U-Prox RM relay modules. U-Prox mini 485 proximity readers with...
  • Page 5: Terms

     One U-Prox WRS485 interface convertes or one U-Prox mini 485 reader  Temperature range: 0 - +55 C at 80% relative humidity.  Maximum relative humidity 80% without condensation Terms Identifiers In access control systems each user has a unique RF ID. Identifiers can take the form of a plastic card, key FOB etc.
  • Page 6: Description And Operation

    The look of the control panel is shown in Fig. 1 (a and b) The Enclosure Reset button Panel board Micro USB B port Ethernet port Connectors Figure 1a. U-Prox IC E modification 1 The Enclosure Ethernet port Micro USB B port Reset button Connectors Figure 2b. U-Prox IC E modification 2 Location of jumpers and connectors on control panel board and their function is shown in Fig.
  • Page 7: Assignment Of The Panel Contacts And Indication

    Figure 2a. U-Prox IC E board modification 1 Figure 2b. U-Prox IC E board modification 2 Assignment of the panel contacts and indication Contact Name Purpose +12V +12V External 12V power supply connection RS 485 bus for reader, convertors and U-Prox...
  • Page 8: Light Emitting Diodes (Led)

    "Configurator" software and USB port or use the automatic adjustment mode. Panel goes to the “Normal” mode after uploading the configuration. To return to the factory settings use the command from the U-Prox software or with the routine described in Service Maintenance section.
  • Page 9: Normal" Mode

    RF ID recorded as lost and in case of RF ID matching attempt. If panel is in “Alarm mode", use of floor selection buttons prohibited. One may activate floor selection button with U-Prox RM relay module input. To exit from the "Alarm" mode pass the ID with "Disalarm" attribute or by command...
  • Page 10: Free Pass" Mode

    "Free Pass” Mode There are circumstances when you need to open some of access points for free pass of people. For this case, the panel has "Free Pass" mode. In "Free Pass” Mode LED of reader flashes green and yellow.
  • Page 11: Communicator Operation

    RF ID with VIP attribute checked. Communicator operation U-Prox IC E panel operates automatically. After the download from the access control system server the data from the readers, U-Prox RM modules and U-Prox WRS485 convertors processed and access event messages are sent to the access control system server.
  • Page 12: System Deployment

    Figure 4. System deployment The algorithms for operation on each step described below Server addresses automatic configuration for U-Prox IC E Panel checks for DHCP mode ON (panel address 0.0.0.0) or static IP...
  • Page 13: Interaction With Elevator Equipment

    RS-485 interface to the reader, placed in elevator cabin. To control the loops of the floor selection buttons up to four U-Prox RM relay modules connected to the U-Prox IC E control panel. The U-Prox RM relay terminals connected in series with buttons’...
  • Page 14 Remotely allowing access to the floor The inputs Z1-Z8 can be connected to a remote console placed on a guard post. On pressing floor selection button U-Prox IC E generates message "Access granted to the floor remotely" Floor selection buttons unblock in an emergency U-Prox RM relay modules have EMRG inputs.
  • Page 15: How To Work With The Device

    Loop's connection examples show in Fig. 6 Figure 6. Loop's connection examples How to work with the device U-Prox IC L control panel shipped in the plastic enclosure without the power supply. Dimensions marked on the Fig. 7. Connection...
  • Page 16: Mount Recommendations

    Figure 8b. Fixing holes marking, modification 2 Modules and interface convertors connection Modules and interface convertors connected to the U-Prox IC E with RS-485 interface. The length of the RS-485 bus is up to 1200 m. On the utmost devices, connected to the RS-485 bus terminal resistors connected with TERM jumper as depicted on Fig.9.
  • Page 17 Figure 9. Control panel, relay modules, intrface convertors and reader connection on RS-485 bus...
  • Page 18: Rs-485 Connection Recommendations

    RS-485 connection recommendations  DO NOT connect U-Prox RM relay modules as utmost on the RS-485 bus as they have no terminal resistors  Set DIFFERENT ID’s to U-Prox RM relay modules on single RS-485 bus  USE or U-Prox WRS485 interface convertors or U-Prox mini 485 reader ...
  • Page 19 Cross-over connection. Connection to computer 1. white-yellow 1. white-green 2. yellow 2. green 3. white-green 3. white-yellow 4. blue 4. blue 5. white-blue 5. white-blue 6. yellow 6. green 7. white-brown 7. white-brown 8. brown 8. brown Figure 10. Ethernet wiring To adjust panel communicator perform: ...
  • Page 20: Panel Program Order

    DNS server IP address, Internet gateway U-Prox IP Panel connection and enrollment in access control system software database (see U-Prox IP software instruction manual) Panel adjustment with U-Prox IP software Upload panel from U-Prox IP software Service maintenance Return to factory settings...
  • Page 21 Reference for device installation modification 2  --------------------------------------------------------------------------------------------------------------------...
