Summary of Contents for bit AutoFill V2
-
Page 2: Table Of Contents
AutoFill V2 Contents 1 Package contents ....................3 2. Overview ......................4 2.1 Display overview ....................4 2.2 Board overview ....................5 3 Safety symbols ...................... 6 4 Installation ......................7 4.1 General ......................7 4.2 Groundwire ...................... 7 4.3 Power supply ....................7 4.4 Ready contact .................... -
Page 3: Package Contents
AutoFill V2 1 Package contents Check Description Container with window Synthetic base Filltower Airfilter Control Box 4.0m granulate hose with a venturi and 10mm air tube Hose clamp Washer levelsensor Allen-head screw M6 x 16 Set of electrical components Optional:... -
Page 4: Overview
AutoFill V2 2. Overview 2.1 Display overview Figure 1 Description Function LED Sensor Is lit if level is ok LED Hand Is lit when turned on manual Button Hand Manual control LED Alarm Is lit when there is more than 1 minute ‘output’... -
Page 5: Board Overview
AutoFill V2 2.2 Board overview Figure 2 Description Function 24V in 24V/DC in Valve 24V/DC output to air valve Release Output release to machine Alarm Alarmsignal to e.g. siren/ alarmlight Supply low Release in Ready signal from hotmelt unit Sensor connector... -
Page 6: Safety Symbols
Wear safety glasses Wear full suit It is also possible to: - call BIT Hotmelt Technology for telephone consult for help with the installation - let BIT Hotmelt Technology carries out the installation. - let BIT Hotmelt Technology give courses on site. -
Page 7: Installation
AutoFill V2 4 Installation 4.1 General Following work is only to be carried out by qualified personnel. Beware of hot surface Disconnect the power plug of the hotmelt application before opening! General rules: - Always work with cable glands - Be careful when drilling, so that the wiring cannot be damaged... -
Page 8: The Sensor
AutoFill V2 5 The sensor 5.1 Adjust the levelsensor Figure 4 T 0031 (0) 348 563 839 W www.bithotmelt.com... -
Page 9: Calibrate The Levelsensor
AutoFill V2 Let the control unit of the Automatic Granulate Feeder turned off. Step 1: Check if the glue is completely melted. The sensor responses different to solid or liquid glue. Step 2: Place the sensor in the hole in the synthetic base. - Page 10 AutoFill V2 Step 5: Open the drain vale and place a box. Step 6: Let the adhesive level lower to below the sensor. Drain the tank through the drain valve or by opening a gun. Step 7: Close the drain valve.
-
Page 11: Maintenance
AutoFill V2 6 Maintenance For good operation of the system the screen and air filter on top of the filltower need to be clean. And not stucked with glue. The air, which transports the granulate, must be able to leave the system. -
Page 12: Partslist
AutoFill V2 7 Partslist Figure 5:Front view AutoFill Description Partno. Air Filter AutoFill 25-007-0001 Control unit 25-203-0004 Cable gland M12 75-003-0001 Air valve 2/2 24V/DC 03-001-0050 Synthetic base Washer 25-008-0002 Levelsensor V2, incl. cable gland M12 25-202-0002 Main Switch 25-202-0006... - Page 13 AutoFill V2 Figure 6: Side view AutoFill Description Partno. Filltower AutoFill 25-006-0003 Mounting bracket 25-008-0005 Bolt M5x10 Bolt M6x10 T 0031 (0) 348 563 839 W www.bithotmelt.com...
- Page 14 AutoFill V2 Figure 7: venturi Description Partno. Quantity Air coupling 1/8” x 8mm 90° 26-002-0802 Silincer 26-002-0023 Vibrator 25-007-0002 Venturi 25-007-1001 Figure 8: Mainboard Figure 9: Transformer 24V/DC Artikelomschrijving Artikelnummer Aantal Container 120L with window, blue 25-004-1001 (standard) (not shown)
-
Page 15: Troubleshooter
In this way the air valve will open. Hotmelt system does not Tank is compleet filled with Place the washer a little bit lower at the apply glue granulate. So many hotmelt sensor. adhesive is applied. The tank So that the range of the sensor is higher in can not melt fast enough.
