SpaceLas CELEB 18 User Manual

Laser show projector
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
Laser show projector Celeb 18
Please read this manual carefully before using the product

Advertisement

loading
Need help?

Need help?

Do you have a question about the CELEB 18 and is the answer not in the manual?

Questions and answers

Summary of Contents for SpaceLas CELEB 18

  • Page 1 USER MANUAL Laser show projector Celeb 18 Please read this manual carefully before using the product...
  • Page 2 Introduction Thank you for purchasing this product. We always try to develop our product with high-tech and high performance to meet your requirement and exception. The unit is designed strictly according to the international standard. The control way is single or master-slave in option. The manual include the skill parameter and detail instructions.
  • Page 3 Installation 1. Please check the voltage whether is the same with the one showed on the equipment or nor. 2. It must ask for the technical person and set the light safety when installation. And let the light beam at the suitable angle. 3.
  • Page 4 Attention 1. Please do not open the bottom cover yourself without permission. Operate it according the user manual. Call the technician when the machine breaks down. 2. Please do not see the light beam directly to avoid any damage. 3. Before connect or disconnect the power, please adjust the luminance of the diode to the least to avoid any damage to the diode.
  • Page 5 It’s recommended that each fixture has an independent power switch to turn fixture on or off at any time. 2. Signal connection This device accept DMX512(1990) digital signal, master or slave can work in music mode. We provide circle 3-pin DMX cable to connect console and equipment. Please check the following picture ...
  • Page 6 Animation ON/OFF Repeat ON/OFF ONE / FILE / ALL Music ON/OFF SD card Mode Directory File 1/48 Test Mode Image 1-3 Channel Setting 27CH / 52CH Master / Slave ON/OFF Scan-safety ON/OFF EASY ILDA ON/OFF Language CH/EN System Sound Sense 0-100 Setting Channel Num Operational Mode...
  • Page 7 Brightness 0-255 R Fade 0-255 G Fade 0-255 B Fade 0-255 Design Zoom 0-255 X Size 0-255 Y Size 0-255 Invert X ON/OFF Invert Y ON/OFF DMX Setting Input DMX signal, and the link the DMX controller and the lights by the control line as the following picture, you can control the lights by the controller.

  • Page 8: Master-Slave Setting

    Number Address LCD display(No.) 28 or 53 028 or 053 55 or 105 055 or 105 ┇ ┇ ┇ Master-slave Setting Link the lights as the following picture (the light which does not receive signal, only output signal, will be the master light)， Using before please must be check power supply link with earth ...

  • Page 9: Specification

    Specification 1. Rated voltage: AC 100V - 240V 50/60Hz 2. Power consumption: 100W 3. Color: □single color，□RGB 4. Modulation: analog 5. Scanner: 40kpps 6. DMX512 channel: 27CH/52CH 7. Control mode: music/ auto/ DMX512/ ILDA/ master-salve/ SD card 8. Cooling requirements: air-cooled optimized airflow 9.
  • Page 10 List Each 32 value be 1 list，total 8 list CH31 0～255 Macro each 64 value be 1 macro，total 4 macro Black 0～15 CH32 16～255 Each 12 value be 1 cue, total 20 cues CH33 X position 0～255 Left ..right（128 center） CH34 X fine 0～255...
  • Page 11 224～239 Macro 7 240～255 Macro 8 CH18 CH43 Write in 0～255 Visible point 100%-0 Invalid 0～15 16~31 Macro 1（valid for 14CH 25CH ） 32~47 Macro 2（valid for 14CH 25CH ） 48~63 Macro 3（valid for 14CH 25CH ） 64~79 Macro 4（valid for 14CH 25CH ） 80~95 Macro 5（valid for 14CH 25CH ）...
  • Page 12 Strobe 127～255 Slow... fast Invalid Macro 1 1～32 33～64 Macro 2 Macro 3 65～96 CH22 CH47 X position 97～128 Macro 4 129～160 Macro 5 Macro 6 161～192 Macro 7 193～224 225～255 Macro 8 Invalid 1～32 Macro 1 33～64 Macro 2 Macro 3 65～96 CH23...
  • Page 13 65～96 Macro 3 Macro 4 97～128 Macro 5 129～160 161～192 Macro 6 193～224 Macro 7 225～255 Macro 8 Invalid Macro 1 1～32 33～64 Macro 2 65～96 Macro 3 CH26 CH51 X flip 97～128 Macro 4 129～160 Macro 5 Macro 6 161～192 Macro 7 193～224...
  • Page 14 64～95 Auto play Music play 96～127 Manual play 128～159 160～191 Auto play SD mode 192～223 Music play (one file) 224～255 Music play (all files loop) Dimmer 0～255 Brightness 0% ..100% Brightness 0% ..100% 0～255 Green 0～255 Brightness 0% ..100% Blue 0～255 Brightness 0% ..
  • Page 15 160～191 Cyan 192～223 Blue 224～255 Purple CH18 Write in 0～255 Visible point 100%-0 0～15 Default CH19 Speed 16~31 Pause 32~255 25% - 200% 0～31 Default CH20 Scan rate 32～223 6k - 29k 224～255 Auto in-play mode In LCD display, UP/DOWN to select “Auto In-play”, Fast Beat, Medium Beat, Slow Beat and Animation for option Music in-play mode In LCD display, UP/DOWN to select “Music In-play”, Fast Beat, Medium Beat, Slow...
  • Page 16 2). Add file (.ild) to folder, (note:file name could be number or letter, and should not exceed 32 letters) as following 3). Folder and content play sequence as following The files in folder will be played in the order in which the files are copied to the SD card.
  • Page 17 Master-slave mode Master In LCD display, UP/DOWN select “system setting”, master/slave ON Slave In LCD display, UP/DOWN select “system setting”, master/slave OFF, set “DMX address” as 001 ILDA mode ILDA signal prior, connect ilda cable, no need any setting. RJ45 connector, connect our ILDA box, LCD display, UP/DOWN select”...
  • Page 18 Product common breakdown comparison table breakdown cause Major breakdown analysis and solution 1.Check the power cable whether to connect the fixture, The fixture no light or whether the fuse does bum out. 2.Check the input voltage whether to assign the voltage no work match with the fixture.
