- Page 1 Carmel / Lotus / Brandy 4 Piece Outdoor Conversation Set Model # AXCPTCON4-CAR...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. -
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for outdoor use. Coffee Table / Dining Table Wash frame parts with mild soap and water, rinse thoroughly and dry frame completely. Do not use bleach, acid or other solvents on the frame parts. Use placemats or coasters to prevent leaving marks from hot plates or cold glasses. - Page 7 Carmel / Lotus / Brandy Outdoor Conversation Chair Model # AXCPTCCH-CAR...
-
Page 8: Pre-Assembly Information
Pre-Assembly Information Model # AXCPTCCH-CAR Part Description CHAIR BACK CUSHION CHAIR SEAT CUSHION QTY 1 QTY 1 QTY 2 CHAIR SEAT BACK LEG FRONT LEG QTY 1 QTY 2 QTY 2 Hardware Description ALLEN KEY BOLT WASHER QTY 8 QTY 8 LOCK WASHER ALLEN KEY QTY 1... - Page 9 Components - Key Diagram Model # AXCPTCCH-CAR...
- Page 10 Assembly Model # AXCPTCCH-CAR Step 1 1. Attach Legs E , F to Chair Seat D using eight Allen Key Bolts 1 , eight Washers 2 and eight Lock Washers 3 through guide holes. 2. Use Allen Key 4 to tighten Bolts. Do not over-tighten.
- Page 11 Carmel / Lotus / Brandy Outdoor Sofa Model # AXCPTSOF-CAR...
- Page 12 Pre-Assembly Information Model # AXCPTSOF-CAR Part Description SOFA BACK CUSHION SOFA SEAT CUSHION QTY 3 QTY 1 QTY 4 SOFA SEAT BACK LEG FRONT LEG QTY 1 QTY 2 QTY 2 BOTTOM LEG QTY 1 Hardware Description LOCK WASHER ALLEN KEY BOLT WASHER ALLEN KEY QTY 1...
- Page 13 Components - Key Diagram Model # AXCPTSOF-CAR...
- Page 14 Assembly Model # AXCPTSOF-CAR Step 1 1. Attach Legs E , F to Chair Seat D using eight Allen Key Bolts 1 , eight Washers 2 and eight Lock Washers 3 through guide holes. 2. Use Allen Key 4 to tighten Bolts. Do not over-tighten. 3.
- Page 15 Assembly Model # AXCPTSOF-CAR Step 2 Note: Leveler on bottom of leg can be adjusted if floor is uneven.
- Page 16 Carmel / Lotus / Brandy Outdoor Coffee Table Model # AXCPTCT-CAR...
- Page 17 Pre-Assembly Information Model # AXCPTCT-CAR Part Description TABLE TOP QTY 1 QTY 4 Hardware Description WASHER LOCK WASHER Ø16 / Ø8 X 1 mm Ø15 / Ø8 X 2 mm QTY 8 QTY 8 WRENCH WR13 Ø13 / Ø8 x 6 mm QTY 8 QTY 1...
- Page 18 Components - Key Diagram Model # AXCPTCT-CAR...
- Page 19 Assembly Model # AXCPTCT-CAR Step 1 1. Attach Legs B to Table Top A using eight Washers 1 , eight Lock Washers 2 and eight Nut 3 . 2. Use Wrench 4 to tighten Nuts. Do not over-tighten.
