USE AND CARE GUIDE
E02GS008/ E02GS009
MODEL#: F210004-A1
F210004-B2
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
service@alphamarts.com
THANK YOU
We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing PHI VILLA!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PHI VILLA F210004-A1
Summary of Contents for PHI VILLA F210004-A1
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents 9-11 Table of Contents Operation Instructions Warnings & Important Safety Information Care and Maintenance Speci cation & Package Contents Warranty Assembly instructions WARNING: For Outdoor Use Only. INSTALLER: Leave this manual with the appliance. Installation and service must be performed CONSUMER: Retain this manual for future reference by a quali ed installer, service agency, or the gas supplier. - Page 3 IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable.
-
Page 4: Speci Cation & Package Contents
IMPORTANT SAFETY INFORMATION (About Propane Gas) The propane gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Speci cations for propane gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. - Page 5 PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY 1 pc Lava rock (6.6 lbs / pack) 1 pack 1 pc 1 pc Weather cover Table top assembly 1 pc 1 pc Back panel Door handle 1 pc Bolt (M6 x 12) 16 pcs Left panel 1 pc...
-
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. - Page 7 ASSEMBLY INSTRUCTIONS 5. Attach back panel (C) to back-left leg (G) and back-right leg (H) with bolts (AA) and washer (CC) using hex screw driver (DD), (see Figure 5). NOTE: DO NOT tighten the screws completely. Hardware Used Bolts (M6 x 12) Washer (M6) Hex screw driver Figure 5...
- Page 8 ASSEMBLY INSTRUCTIONS 9. Open the box of lava rocks, put the lava rocks (L) into the re bowl of the re table (B), (see Figure 9). A gas re pit requires 6.6 lbs lava rocks. WARNING Keep children away during assembly, as this item contains lava rock, which are small pieces and can be swallowed by children.
-
Page 9: Operation Instructions
ASSEMBLY INSTRUCTIONS 11. Once the repit has cooled completely after use, carefully place the lid (A) onto the re bowl and use the weather cover (M) to protect your re pit from the elements, (see Figure 11). WARNING Allow 30 minutes after use for re pit to cool down before placing the lid to prevent scalding. Figure 11 OPERATION INSTRUCTIONS Battery... - Page 10 OPERATION INSTRUCTIONS Leak test To prevent re or explosion hazard when testing for a leak: 1. Always perform the leak test as described below before lighting this appliance or each time the cylinder is connected for use. 2. Do not smoke or allow other sources of ignition in the area while conducting a leak test. 3.
- Page 11 OPERATION INSTRUCTIONS Lighting Instructions 1. Push in gas control knob slightly and turn to “OFF”. 2. Turn gas control knob to “ON/MIN”. 3. Push in gas control knob all the way and hold. Continue to press the ignition button for 15 seconds. 4.
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE To enjoy the outstanding performance from your re pit, make sure you perform the following activities on a regular basis: 1. Use warm soapy water for cleaning. Never use ammable or corrosive cleaning agents. 2. While cleaning the re pit, make sure to keep the area around the burner dry at all times. DO NOT submerge the control valve assembly. -
Page 13: Warranty
WARRANTY Firepits Burner, steel re pit bowl, all mechanical parts and ttings to control panel and burner assembly, and all re pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship. Rust is not covered.
