LED Patio Umbrella
Owner's Manual
Model: EO-PU22020
DESIGNED IN NEW YORK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EO-PU22020 and is the answer not in the manual?

Questions and answers

Summary of Contents for EAST OAK EO-PU22020

  • Page 1 LED Patio Umbrella Owner’s Manual Model: EO-PU22020 DESIGNED IN NEW YORK...
  • Page 2 eastoak.com Question? Comments? Reach out to us to get expert support! support@eastoak.com eastoak.com 1-833-EAST-OAK (USA) (1-833-327-8625)

  • Page 3: Important Caution

    IMPORTANT CAUTION Please check all parts and components to ensure that there are no damages or missing items before starting the construction of the product. If you have any problems or discover any missing parts, please contact customer service at support@eastoak.com •...

  • Page 4: Care And Maintenance

    IMPORTANT INFORMATION If the umbrella is showing ANY signs of stress, or IF the umbrella begins to move around excessively even when properly weighted it indicates the wind is too strong and the umbrella must be closed and secured immediately. CARE AND MAINTENANCE •...

  • Page 5: Parts List

    PARTS LIST Umbrella Frame and Canopy Lower Pole A (X1) B (X1) Solar Panel Spare LED Light Covers C (X1) D (X3) EASTOAK.COM OWNER’S MANUAL...
  • Page 6 ASSEMBLY INSTRUCTIONS Locate the plug at the top of the umbrella. Carefully insert the plug into the socket located on the underside of the solar panel. Place the solar panel on the top of the umbrella, taking care to conceal the wires inside the gap at the top of the umbrella, then gently turn the solar panel in a clockwise direction to attach it to the umbrella.
  • Page 7 Attach bottom pole (B) to umbrella frame (A), then tighten in the counterclockwise direction. Counterclockwise Stand and secure the umbrella in a suitable umbrella base (not included). Secure the umbrella pole firmly by tightening the locking nut, as shown in the picture.
  • Page 8 Locate the umbrella in direct sunlight to charge the batteries before first use. IMPORTANT NOTE: Charge the batteries for at least 8 hours in direct sunlight before first use. Failing to follow this step will shorten the lifespan of the rechargeable batteries and decrease the performance of the lights.
  • Page 9 OPERATING INSTRUCTIONS To open the umbrella, unfasten the Velcro storage straps and gently pull out each of the umbrella ribs by hand, at the same time wind the crank handle gently in a clockwise direction. CAUTION: Take care not to wind the crank in a counterclockwise direction to open as damage may occur.
  • Page 10 To tilt the canopy, push the tilt button with one hand gently allow the canopy to tilt with the other hand. Release the button to lock in the position. CAUTION: The tilt option should only be used on days with no wind. Use of the tilt function even in a light breeze is not recommended.

  • Page 11: Operating The Lights

    Use the Velcro storage straps to secure the umbrella when not in use. OPERATING THE LIGHTS To operate the lights, turn the switches (located on the end of one rib) to the ON (‘I’) position. Ensure both switches are set to the OFF (‘O’) position when the lights are not being used.

  • Page 12: Replacing The Batteries

    REPLACING THE BATTERIES The batteries in your LED umbrella must be replaced at least once every year when you feel that the light is fading more quickly). You can purchase replacement batteries at specialty retailers. You will need 3 pieces AA size 1.2v 800mAh NIMH rechargeable batteries which are the same as have been supplied from new.
  • Page 13 Carefully pull the plug out of the socket under the solar panel. IMPORTANT: Do not pull the wire to remove the plug. Set the solar panel upside down on a soft, clean surface to avoid scratching. Loosen all three screws on the bottom of the solar panel. EASTOAK.COM OWNER’S MANUAL...
  • Page 14 Carefully open the solar panel. Replace the batteries, matching the +/- on the battery with the +/- on the battery case. Make sure the O ring is correctly located before replacing the cover. LED PATIO UMBRELLA...
  • Page 15 Re-assemble the solar panel. Do not over-tighten the screws. EASTOAK.COM OWNER’S MANUAL...

  • Page 16: What's In The Box

    FEATURES • SOLAR-POWERED LIGHTS: Use it day or night, built-in 40 solar LED lights, and center LED light, can run for 6-7 hours simultaneously. • HIGH-DURABILITY FABRIC: Made with high-quality water-resistant fabric to last for years of enjoyment. • ADJUST YOUR SHADE: Stay cool at all times, as the easy push-button tilt system gives coverage no matter what time of day.

  • Page 17: Technical Specs

    ◦ Umbrella Pole Diameter: 1.5” WARRANTY AND SERVICE Default 12-Month Warranty Thank you for choosing East Oak. This product is covered with East Oak product and labor warranty for 12 months from the date of its original purchase. Extend Your Warranty Extend your warranty by registering your new product on our website eastoak.com/warranty.
  • Page 18 support@eastoak.com eastoak.com 1-833-EAST-OAK (USA)
