- Page 1 Multiplexer FMUX/SAT 4 x E1 ports V.35/RS-530/RS-449 link interface in codirectional mode Installation and Operations Manual Document version: 1.7E / 06.09.2006 © 2006 Cronyx...
- Page 2 This is to certify that the multiplexer equipment «FMUX» manufactured by «Cronyx» in compliance with Technical Specifications 150.RUS ТУ is compliant with the following requirements: • «Technical Requirements to secondary time trunking equipment for 2/8 Mbit/s digital transmission systems»...
- Page 3 Revision A, 28/04/2006 The unit is manufactured in the “/S” design, as a device in 1U high metal enclosure, for mounting in a 19” rack. Device specifications and design may be changed without prior notice to consumers. © 2006 Cronyx...
-
Page 4: Table Of Contents
FMUX/SAT Multiplexer Contents Section 1. Introduction ............6 1.1. Purpose ..................... 6 1.2. Features ....................6 1.3. Order Code ....................7 1.4. Connection Diagram ................8 1.5. Specifications ................... 9 E1 Ports ....................9 Link Port ....................9 Console Port ..................... 9 SNMP Management Port ............... - Page 5 "Restore parameters" Command ............39 4.9. "Login to remote device" Command ............. 40 4.10. "Reset" Command ................40 Section 5. Management over SNMP ......41 5.1. Configuring SNMP Parameters .............. 41 5.2. Management Information Blocks (MIBs) ..........42 © 2006 Cronyx...
-
Page 6: Section 1. Introduction
Section 1. Introduction 1.1. Purpose FMUX/SAT is a multiplexer with variable frame structure, which allows transmitting up to four E1 channels over synchronous link equipment with codirectional interface, such as satellite modem with V.35 DCE interface (see Section "1.3. Connection Diagram"). -
Page 7: Order Code
Commands to remote device are sent over monitoring channel, organized in the link path. The FMUX/SAT is equipped with LED indicators, which show state of ports and link equipment, loops enabled states, and testing modes. -
Page 8: Connection Diagram
ETC input of receiving multiplexer transparently. The FMUX/SAT multiplexer is DCE, and supports operation with CD, DSR, CTS, DTR, and RTS modem signals. The multiplexer uses the RTS signal loss for indicating the non-operating state of data transmission equipment (in this case "LOS"... -
Page 9: Specifications
Connector ............... HDB44 (female) Console Port Interface type ..............RS-232 DCE Data transmission protocol ..........Asynchronous, 9600 bit/s, 8 bits/character, 1 stop bit, no parity Modem signals ............... DTR, DSR, CTS, RTS, CD Connector ............... DB-9 (female) © 2006 Cronyx... -
Page 10: Snmp Management Port
FMUX/SAT Multiplexer SNMP Management Port Interface type ..............Ethernet 10Base-T Connector ............... RJ-45 Emergency Alarm Port Connector ............... DB-9 (male) Relay contacts current ............ Up to 600 mA Relay contacts voltage ........... Up to 110 VDC; up to 125 VAC Diagnostic Modes Loops................ -
Page 11: Section 2. Installation
Power supply cable (for "-AC" model) ..............1 pc. Removable part of power supply connector terminal unit (for "-DC" model) .1 pc. Installation and Operations Manual ..............1 pc. 2.3. Cable Connections All connectors are located on the front panel of multiplexer: Ground SNMP port E1 ports PORT FMUX LERR LOS SNMP CONSOLE ALARM RERR TST Link port Console (V.35/RS-530/RS-449) Alarm Power Fig. 2. Connector locations © 2006 Cronyx... -
Page 12: Power Supply Connector
FMUX/SAT Multiplexer Power Supply Connector Standard mains connector (IEC 320 C14) is used to connect AC power supply cable (for “-AC” model). The power supply cable is supplied with the device. To connect DC power supply cable (for “-DC” model), the power supply connector's terminal unit is used. The connector’s pin assignment shown below (view from device's front panel side): Fig. 3. DC power supply connector The corresponding removable part of terminal unit of the power supply connector, is supplied with the device. Grounding M4 screw is located on the front panel for device grounding. Before switching device on, and before connecting other cables, the device must be properly grounded. E1 Port Connectors RJ-48 connector is used for E1 port connections: Fig. 4. E1 port connector © 2006 Cronyx... -
Page 13: Link Port Connector (V.35, Rs-530, Rs-449)
RXC-b RTS-a — RTS-b DTR-a — DTR-b DSR-a — DSR-b CTS-a — CTS-b CD-a — CD-b 1,16 SEL-0* SEL-0* SEL-1 SEL-1* SEL-2 SEL-2 SEL-3 SEL-3* SEL-4* SEL-4 SEL-5* SEL-5 SEL-6* SEL-6 * - Connect contact to GND © 2006 Cronyx... -
Page 14: Cable Diagrams For Connections To Link Port
FMUX/SAT Multiplexer Cable Diagrams for Connections to Link Port Below are cable diagrams for connecting to DTE and DCE devices using external transmit clock. Multiplexer V.35 port input signals are denoted by left arrow (" ), and output ←" signals are denoted by right arrow ("... -
Page 15: Rs-530 Cable For Connection To Dсe
30 Not connected CTS-b → CTS-b CD-a → RTS-a CD-a → CD-a CD-b → RTS-b CD-b → CD-b ↔ ↔ ↔ ↔ SEL-x Connect SEL-x Connect 31, 32, 31, 33, 33, 37 to 37 to GND 1 GND 1 © 2006 Cronyx... -
Page 16: Rs-449 Cable For Connection To Dce
FMUX/SAT Multiplexer RS-449 Cable for Connection to RS-449 Cable for Connection to Signal HDB44 DB37 Signal Signal HDB44 DB37 Signal (male) (female) (male) (female) TXD-a ← RXD-a TXD-a 10 ← TXD-a TXD-b ← RXD-b TXD-b 25 ← TXD-b RXD-a →... -
Page 17: Snmp Port Connector
GND 5 TXD 3 TXD 3 RXD 2 RXD 2 RTS 7 RTS 7 CTS 8 CTS 8 DTR 4 DTR 4 DSR 6 CD 1 CD 1 Cable with modem control Cable without modem control Fig. 7. Console cable diagrams Use direct cable for connection to PC COM port. © 2006 Cronyx... -
Page 18: Emergency Alarm Connector
FMUX/SAT Multiplexer Emergency Alarm Connector DB-9 (male) connector is used for emergency alarm connection: External input sensor Connector pin-out: view from outside of the device Pin-out: 1 – open during no alarm, closed to the middle relay contact (6) during alarm 2 – closed to the middle relay contact (6) during no alarm, open during alarm 3 –... -
Page 19: Section 3. Operation
E1 port errors: • flashes during HDB3 coding errors in the correspond- ing E1 port; • lights during loss of carrier in corresponding E1 port; • lights when receiving AIS signal at the input of cor- responding E1 port. © 2006 Cronyx... - Page 20 FMUX/SAT Multiplexer Indicator Color Description PORT STATE Green E1 port operating mode: • lights – normal operation; • does not light – port is not used; • flashes – loop enabled on the port; • double flashes – tributary loop enabled on the port.
-
Page 21: Alarms
Section 3. Operation 3.2. Alarms The multiplexer is equipped with emergency alarm interface. The emergency alarm interface is designed for switching on external executive device (such as a bell, buzzer, indicator on control panel, etc.) during emergency. Alarm relay is used in the "dry contacts" mode (that is, its contacts are isolated from all electrical circuits in the multiplexer). The following situations are considered emergencies: • power failure; • loss of signal or frame synchronization in the link port; • loss of signal in at least one of the E1 ports used (in "In use" state"); • alarm signal received from external input sensor of remote device. Alarm from external input sensor for transmission to remote device is generated either when the sensor contacts close (this mode is enabled by default), or when they open (alarm generation mode is described in the "Sensor input" subsection of section 4.8 “ "Configure" menu”). If the multiplexer is installed in unserviceable room, then external input sensor contacts may be used, for example, for transmitting climate sensor signal, door opening signals, etc. The alarm connector pinout is presented in "Alarm connector" subsection of section 2.5 "Cable connections". © 2006 Cronyx... -
Page 22: Device Response To Emergencies
FMUX/SAT Multiplexer 3.3. Device Response to Emergencies Local Device Remote Device State Indicators Indicators Output Output and Relays and Relays to E1 to E1 Ports Ports Loss of power supply All indicators do LOS lights. To all not light. ports... -
Page 23: Loops
Loopback enabled on port 0, Remote Mux PORT STATE indicator of port 0 flashes Tributary Loop Ports Ports Link Local Mux: Remote Mux Tributary loopback enabled on port 0, PORT STATE indicator of port 0 double flashes © 2006 Cronyx... -
Page 24: Local Link Loop
FMUX/SAT Multiplexer Local Link Loop Ports Ports Link Local Mux: Remote Mux Local loopback enabled, TST indicator flashes Remote Link Loop Ports Ports Link Local Mux: Remote Mux: Remote loopback request Local loopback enabled by enabled, remote request, TST indicator double flashes TST indicator flashes ©... -
Page 25: Built-In Ber Tester
AIS signal is output to all E1 ports of the multiplexer. This situation is shown on the diagram below: E1 Ports E1 Ports BERT Link Local Mux Remote Mux BERT: Enabled AIS Output: To All E1 Ports State: «Test pattern not detected» LERR Indicator: On TST, LERR, RERR Indicators: On When working with BER tester the following two options should be considered. © 2006 Cronyx... -
Page 26: Link Testing Via Remote Loop
FMUX/SAT Multiplexer Link Testing Via Remote Loop BER tester is enabled on the local device, and a loop towards the link path is enabled on remote device: E1 Ports E1 Ports BERT Link Local Mux Remote Mux BERT: Enabled Link Loopback: Enabled AIS Output: To All E1 Ports AIS Output: To All E1 Ports TST Indicator: On TST Indicator: Blinking Regularly... -
Page 27: Section 4. Management Over Console Port
4.1. Upper Level Menu The console interface is designed as simple hierarchical menu. To select command, you must enter its number. To return to upper level menu, you must press <Enter> (or <Return>). An example of the main menu is presented in the picture: Cronyx FMUX / 4E1-SAT-SNMP revision A, 28/04/2006 Mode: Normal; Sensor=Open Link: 8448 kbps, Ok, Cable cross V.35 DTR, RTS, ETC, DSR, CTS, CD, RXC 1. - Page 28 FMUX/SAT Multiplexer • "LOF" – loss of frame synchronization; • "AIS" – AIS signal is being received; • "Loop" – local loop enabled on the link: the received signal is turned back; • "Remote loop" – request for remote loop enabling. When BER tester is enabled, the "Link" line also shows information about test results: • "Test pattern not detected" – if the test pattern was not detected in received data; • "Test error rate=..." – error rate in received data, 10 to 10 (shown in place of "Test pattern not detected" message); • "Time total/loss=.../..." – total test time (days hours:minutes:seconds)/time in "Test pattern not detected" state (seconds); • "Bit errors=..." – data error counter; • "Code=..." – test pattern code. © 2006 Cronyx...
-
Page 29: Menu Structure
4. Test pattern 1. Port configuration... 2. Link... 6. Configure... 3. SNMP... 4. Sensor input: Alarm on 7. Login to remote device closed / Alarm on open 5. Factory settings 0. Reset 6. Save parameters 7. Restore parameters © 2006 Cronyx... -
Page 30: Link Statistics" Menu
FMUX/SAT Multiplexer 4.3. "Link statistics" Menu "Link statistics" mode is designed for viewing link ports status and statistics counters: Link statistics: Session #5, 0 days, 0:45:44 Mode: Normal; Sensor=Open Link: 8448 kbps, Ok, Cable cross V.35 DTR, RTS, ETC, DSR, CTS, CD, RXC -Errored seconds- Receive Transmit Status Link: remote: C - clear counters, R - refresh mode, any key to break..._ Information on the screen is updated once per two seconds. To return to upper level... -
Page 31: E1 Port Ptatistics" Menu
C - clear counters, R - refresh mode, any key to break..._ The screen information is updated once per three seconds. To return to the upper level menu, you must press <Enter> (or <Return>). Press “R” to toggle screen refresh mode between overlapping and redraw. In overlapping mode the screen will not be cleared when information is updated. To reset statistics counters to zero, press "C". "E1 port statistics" line contains current session number and time passed from switch- ing on or restarting the multiplexer. Session number increments every time the device is restarted. Description of lines in the upper part of the screen, including "Mode" and "Link", is presented in "Upper level menu" section. Further, E1 port states and statistics counters are displayed: • "CV" column – the number of code violations; • "Receive" column (under "-Errored seconds-" caption ) – contains the number of seconds during which frame synchronization was lost in the link. ("Transmit" column is not used for this model, and contains dash for each E1 port.) The ports' "Status" is shown as a set of flags: • "OK" – normal state, frame synchronization present; • "LOS" – loss of signal in the link; • "AIS" – link failure signal is being received (the "all ones" code); • "Loop" – loop enabled; • "Tloop" – tributary loop enabled. States are not shown for unused ports. © 2006 Cronyx... -
Page 32: Event Counters" Command
FMUX/SAT Multiplexer 4.5. "Event counters" Command For more information about counters use "Event counters" command: Alive: 0 days, 0:24:39 since last counter clear Link counters - data encoding errors - payload checksum errors Mux counters - E1 port 0 data FIFO errors - E1 port 1 data FIFO errors... -
Page 33: Loop" Menu
3. Port loop... 4. Tributary loop... Command: _ The following loops are implemented: • "Link loop" – local loop on the link. When loop is "Enabled", data received from the link port are turned back; • "Remote link loop" – remote loop on the link. When it is switched in "Enabled" state, request is sent towards the link, to enable loop in the link port of the remote multiplexer; • "Port loop..." – switches to E1 port loop management menu; • "Tributary loop..." – switches to E1 port tributary loop management menu. Loop modes are not stored in nonvolatile memory. © 2006 Cronyx... -
Page 34: Port Loop" Menu
FMUX/SAT Multiplexer "Port loop" Menu "Port loop" menu is designed for managing loops on E1 ports: Port loop Mode: Normal; Sensor=Open Link: 8448 kbps, Ok, Cable cross V.35 DTR, RTS, ETC, DSR, CTS, CD, RXC 1. E1 port 0 loop: Disabled 2. E1 port 1 loop: Disabled 3. E1 port 2 loop: Disabled 4. -
Page 35: Test" Menu
"Error insertion rate: ...” command selects error insertion rate, from 10 to 10 er- rors/bit, or disables error insertion mode, in this case "No errors inserted" message is displayed in place of numeric value. "Insert single error" command inserts single error. "Test pattern: ...” command allows using either pseudo-random code as a test pattern, or selecting fixed 8 bit code. Test results information is displayed in the following lines: • "Time total: ...” – total test time; • "Sync loss: ...” – time during which test pattern synchronization was lost; • "Bit errors: ...” – bit error counter; • "Error rate: ...” – error rate in the received data, from 10 to 10 . If testing is not en- abled, "Testing disabled" message is displayed in this field, if no test pattern is detected in the received data, the "Test pattern not detected" message is shown. Error rate measurement device modes are not saved in nonvolatile memory. © 2006 Cronyx... -
Page 36: Configure" Menu
FMUX/SAT Multiplexer 4.8. "Configure" Menu "Configure" menu allows setting multiplexer operating modes: Configure Mode: Normal; Sensor=Open Link: 8448 kbps, Ok, Cable cross V.35 DTR, RTS, ETC, DSR, CTS, CD, RXC 1. Port configuration... 2. Link... 3. SNMP... 4. Sensor input: Alarm on closed 5. Factory settings 6. -
Page 37: Link" Menu
1. Transmit data strobe: Normal (data valid on falling edge) 2. Receive data strobe: Normal (data valid on falling edge) Command: _ The menu allows configuring the following parameter values: • "Transmit data strobe: ... ” – for transmitted data strobing: • "Normal (data valid on falling edge)"; • "Inverted (data valid on rising edge)"; • "Receive data strobe: ... ” – for received data strobing: • "Normal (data valid on falling edge)"; • "Inverted (data valid on rising edge)". © 2006 Cronyx... -
Page 38: Snmp" Menu
FMUX/SAT Multiplexer "SNMP" Menu "SNMP" menu is designed for setting network IP addresses and SNMP protocol param- eters: SNMP Mode: Normal; Sensor=Open Link: 8448 kbps, Ok, Cable cross V.35 DTR, RTS, ETC, DSR, CTS, CD, RXC MAC address: 00-09-94-00-01-54 1. IP address/netmask: 144.206.181.188 / 24 2. Gateway IP address: 144.206.181.254 3. Get community: public 4. -
Page 39: Sensor Input" Command
"Alarms"). "Factory settings" Command "Factory settings" command restores device modes to their initial state: • E1 port use mode – all ports "In use"; • transmitted and received data strobe mode – "Normal (data valid on falling edge)"; • alarm input sensor contact mode – "Sensor input: Alarm on closed". "Save parameters" Command After configuring parameters (or executing "Factory settings" command) you should store the parameters in non-volatile memory (NVRAM) of the multiplexer using "Save parameters" command. In this case the saved parameters will be restored when the de- vice is restarted. "Restore parameters" Command If parameters were changed, but not saved to NVRAM using "Save parameters" com- mand, then configuration stored in NVRAM may be restored using "Restore parameters" command. © 2006 Cronyx... -
Page 40: Login To Remote Device" Command
"Login to remote device" command gives ability to connect to the menu of the remote multiplexer. An example of remote menu is given below. To disconnect from remote menu, enter ^X (Ctrl-X). Remote login... (Press ^X to exit) Cronyx FMUX / 4E1-SAT-SNMP revision A, 28/04/2006 Mode: Normal; Sensor=Open Link: 8448 kbps, Ok, Cable cross V.35 DTR, RTS, ETC, DSR, CTS, CD, RXC 1. Link statistics 2. E1 port statistics 3. -
Page 41: Section 5. Management Over Snmp
• IP address/netmask – Ethernet port IP address and netmask length; • Gateway IP address – router gateway IP address. • Get community – information request access password. • Get IP address/netmask – information request access restriction IP address and net- mask length. Information request access is permitted only for hosts, whose IP addresses equal to the one specified by "Get IP address" parameter. Higher-order bits are used for IP address comparison, the number of which is specified by "Netmask". Additional parameters must be configured for access to parameter settings: • Set community – parameter configuration access password. • Set IP address/netmask – parameter configuration access restriction IP address and netmask length. Parameter configuration access right must be granted to authorized hosts only. In case of emergencies, device is able to sent SNMP traps. The following parameters must be configured to enable this: • Traps – allow sending emergency traps. • Authentication traps – allow sending unauthorized access traps. • Trap community – password for sending emergency traps. • Trap destination IP address – IP address for sending emergency traps. SNMP traps are sent when following events occur: • Multiplexer power-up or reload – COLD START trap. • Unauthorized access attempt over SNMP protocol – AUTHENTICATION FAILURE trap. • Loss of signal or frame synchronization in the link – LINK DOWN trap. © 2006 Cronyx... -
Page 42: Management Information Blocks (Mibs)
FMUX/SAT Multiplexer • Link switching to the normal mode – LINK UP trap. • Loss of signal at the E1 port – PORT DOWN trap. • Appearance of signal at the E1 port – PORT UP trap. 5.2. Management Information Blocks (MIBs) The following management information blocks (MIBs) are implemented in the multi- plexer: • SNMPv2-MIB – standard management information block, including common sys- tem parameters (system), network interfaces (if), IP protocol (IP, ICMP), UDP protocol (UDP), and SNMP protocol statistics (SNMP). • CRONYX-FMUX-MIB – special management information block, containing E1 ports and link ports states. CRONYX-FMUX-MIB specification files are available on the following address: www.cronyx.ru. © 2006 Cronyx... - Page 43 © 2006 Cronyx...
