Installation and Operation Guide
XX217-00-00
FMC-PS Power Supply
for FMC-RK Rack-Mount Card Cage
Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788
Tel: 631-952-CCTV (2288) Fax: 631-951-CCTV (2288) Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
www.vicon-security.com
Document Number: 8009-8217-00-00
Issued: 0111
Product specifications subject to change without notice.
Copyright © 2011 Vicon Industries Inc. All rights reserved.
Advertisement
Table of Contents
Summary of Contents for Vicon 217-00-00 Series
- Page 1 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
- Page 3 The product shows a significant change in performance. 2. Retain Instructions - Retain all safety and operating 19. Replacement Parts - Use only Vicon specified replacement instructions for future reference. parts or an approved equivalent to prevent unit damage and 3.
- Page 4 Important Safeguards – Indoor Use (Cont) 25. For Rack-Mounted Units Only – The following precautions apply to all rack-mounted units. Elevated Operating Ambient - If installed in a closed or multi- unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
-
Page 5: Power Led
FMC-PS Installation and Operation │ 1 General The FMC-PS integral 115/230 VAC power supply is mounted in the FMC-RK Rack-Mount Card Cage. The design of the FMC-PS eliminates single-point failures in the event of a major fault within any module installed in the FMC-RK chassis rack. Through the use of automatic electronic current limit- ing within each rack-mountable module, only the faulty module shuts down, and the operation of the other modules within the rack continue unimpaired. - Page 6 │FMC-PS Installation and Operation BLACK RED or BLACK WITH WHITE STRIPE CHASSIS GROUNDING SPARE 1.25A STUD (6-32 Thread) SLOW BLOW FUSE Rear Panel ELECTRICAL Input Voltage: 90-264 VAC @ 70 W Maximum Output Voltage: 9 VDC +/- 5% @ 6.5 Amps @ 75˚C Detachable, IEC-connected AC Line Cord allows easy field replacement or exchange for various worldwide AC power plug configurations (use only manufac- turer’s supplied cord).
-
Page 7: Installation Considerations
FMC-PS Installation and Operation │ 3 Installation InstallatIon ConsIderatIons This power supply is supplied as a rack module only. Units should be installed in dry locations protected from extremes of temperature and humidity. Unit is to be installed only in the FMC-RK Card Cage. WarnInG: Before installing, be sure that the power supply is turned off and that the rack power supply is disconnected from any power source. -
Page 9: Vicon Standard Equipment Warranty
Vicon Security Management Systems (SMS) All Models: All hardware is warranted for two years from date of original retail purchase. 10. Any product sold as “special” or not listed in Vicon’s commercial price list: One year from date of original retail purchase. -
Page 10: Corporate Headquarters
Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Vicon Germany Kornstieg 3...
