PCB Piezotronics IMI Sensors HTM602D01 Installation And Operating Manual page 19

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
1.200 [30.48]
1.000 [25.40]
.040 [1.02]
63 [1.6]
.013 [.33] A
A 

.001 [.03]
1 FOR METRIC ACCELEROMETER USE METRIC MOUNTING BOLT MODEL M081A73, M6x1.0-6g X 1.34[34.0] LONG
4
3
ELECTRICAL CONNECTOR
5/8-24 UNEF-2A
2 PIN (MIL-C-5015)
MOUNTING BOLT
1
MODEL 081A73
1/4-28 UNF - 2A x 1.34 [34.0] LONG (SUPPLIED)
.600 [15.24]
1.25 [31.8] MIN
MOUNTING HOLE PREPARATION
A
Ø.218[5.54]
1/4-28 UNF-2B
(M) OPTION
Ø.199[5.05]
M6x1.0-6H
3
SIGNAL/POWER
 .50[12.7] MIN

.38[9.7] MIN
 .50[12.7] MIN
 .38[9.7] MIN
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010
ANGLES  2 DEGREES
FILLETS AND RADII
.003 - .005
2
REV
E ADDED MOUNTING HOLE PREP INFO
1.000 [25.40]
GROUND
A B
DRAWN CHECKED
DIMENSIONS IN MILLIMETERS
BB 11/30/15 ECB 11/30/15 BAM
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25
INSTALLATION DRAWING
ANGLES  2 DEGREES
CASE ISOLATED
ACCELEROMETER
FILLETS AND RADII
0.07 - 0.13
2
1
REVISIONS
DESCRIPTION DIN
44844
B
A
ENGINEER
11/30/15
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
35227
IDENT. NO.
52681
SCALE: 2X SHEET 1 OF 1
1
