Digital Equipment DGT-IR-673B40 Quick Start Manual

Specification

Model DGT-IR-673B40
Pick up Element 1/3" SONY EXview HAD CCD
Effective Picture Elements
PAL:976(H)x582(V)
(H×V)
Horizontal Resolution 700 TV Line
0.001 Lux
Minimum Illumination
0Lux (with IR LED ON)
S/N Ratio 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter
PAL: 1/50s~1/100,000s
Gama Characteristic
IR Distance
40 Meters (with ￠ 5 X42PCS Infrared LED)
IR Status Under 10Lux by CDS
IR Power On CDS AUTO Control
Video Output 1Vpp, 75
Auto Gain Control
Power / / / / C urrent DC12V(+/-10%) / 7 50mA
Lens 4-9mm Manual Zoom Lens
Dimension (mm) 260(W)x112(H)x85(D)mm
Weight (g)
1600
Storage Temperature
-30~+60 ℃ RH95% MAX
Operating Temperature -10~+45 ℃ RH95% MAX

Packing List

No
Name
1.
IR Color Camera
DGT-IR-673B40
2.
User Guide DGT-IR-673B40
II
0.45
Auto
Franchiser：
Model Number
1
1
DGT-IR-673B40
Color Camera
IR Color Camera
Notes : : : :
B efore providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
