Page 1 DEEP SEA ELECTRONICS PLC DSE7400 Configuration Suite Software Manual Document Number 057-160 Author: Allan Jones 7400 Configuration Suite Software Manual Issue 2 http://bestgenerator.spb.ru/?page_id=6765...
Page 2 The DSE logo is a UK registered trademarks of Deep Sea Electronics PLC. Any reference to trademarked product names used within this publication is owned by their respective companies. Deep Sea Electronics Plc reserves the right to change the contents of this document without prior notice. Amendments List Issue...
Page 3: Table Of Contents
7400 Configuration Suite Software Manual TABLE OF CONTENTS BIBLIOGRAPHY ....................6 DESCRIPTION ....................6 INSTALLATION AND USING THE DSE CONFIGURATION SUITE ....6 EDIT CONFIG ....................7 SCREEN LAYOUT ........................7 MODULE ............................. 8 4.2.1 MODULE OPTIONS ............................... 9 4.2.2 CONFIGURABLE STATUS SCREENS ......................
Page 4 7400 Configuration Suite Software Manual 4.9.5 GAS ENGINE OPTIONS ............................73 4.9.6 CRANKING ................................74 4.9.7 SPEED SETTINGS ............................... 75 4.9.8 PLANT BATTERY ..............................76 4.9.9 INLET TEMPERATURE ............................77 4.10 COMMUNICATIONS ........................78 4.10.1 COMMUNICATION OPTIONS......................... 78 4.10.2 RS232 PORT ..............................79 4.10.2.1 BASIC ....................................
Page 5 7400 Configuration Suite Software Manual 5.17 DATALOG ..........................136 5.18 PLC ............................137 5.19 EXPANSION ..........................138 ALARM TYPES .................... 139 http://bestgenerator.spb.ru/?page_id=6765...
Page 6: Bibliography
DSE modules supported by the software The DSE Configuration Suite allows the DSE7400 family of modules to be connected to a PC via USB ‘A – USB B’ cable. Once connected the various operating parameters within the module can be viewed or edited as required by the engineer.
Page 7: Edit Config
Edit Configuration module 4 EDIT CONFIG This menu allows module configuration, to change the function of Inputs, Outputs and LED’s, system timers and level settings to suit a particular application. 4.1 SCREEN LAYOUT Move to the The type of Previous or Next configuration configuration page file being edited...
Page 8: Module
Edit Configuration - Module 4.2 MODULE The module page is subdivided into smaller sections. Select the required section with the mouse. This section allows the user to change the options related to the module itself.
Page 9: Module Options
Edit Configuration - Module 4.2.1 MODULE OPTIONS Free entry boxes to allow the user to give the configuration file a description. Typically this is used to enter the job number, customer Allows the user to name, engineers name etc. select the function of the modules user configurable LED indicators.
Page 10 Edit Configuration - Module Miscellaneous Options All Warnings Are = Normal Operation, the warnings and pre-alarms will automatically reset once the Latched triggering condition has cleared. = Warnings and pre-alarms latch when triggered. Resetting the alarm is performed by either an external reset applied to one of the inputs or, the ‘Stop/Reset’ pushbutton must be operated (once the triggering condition has been cleared).
Page 11: Configurable Status Screens
Edit Configuration - Module 4.2.2 CONFIGURABLE STATUS SCREENS Configurable Status Screens allow the operator to design the status screen to match the requirements of the end user or application more closely. For instance it is possible to configure the module to show the factory set ‘summary screen’...
Page 12: Event Log
Edit Configuration - Module 4.2.3 EVENT LOG 4.2.3.1 DISPLAY OPTIONS The module display option allows the operator to choose between `Date and Time` or `Engine Hours` displayed on the bottom of the screen. 4.2.3.2 LOGGING OPTIONS The event log can be configured to allow users to select which events are stored. 4.2.3.3 SMS MESSAGING When using the controller, logged events will also cause modem ‘dial outs’...
Page 13: Data Logging
Edit Configuration - Module 4.2.4 DATA LOGGING NOTE: - Data logging to internal and external memory is available. The Data Logging page is subdivided into smaller sections. Select the required section with the mouse. Select the logging interval 4.2.4.1 CONFIGURATION of the data.
Page 14: Application
Edit Configuration - Application 4.3 APPLICATION 4.3.1 APPLICATION Allows selection of the Engine type being used (ie Conventional Diesel Engine, Gas Engine or Electronic Engine) Auto Voltage Sensing to automatically select the See overleaf for description of the parameters..module configuration from available ‘alternative configurations’...
Page 15: Ecu (Ecm) Options
Edit Configuration - Application 4.3.2 ECU (ECM) OPTIONS Parameter Description Engine type Select the engine type appropriate to your system Conventional Engine: Select this if you have a traditional (non ECU) engine, either Energise to Run or Energise to Stop. Conventional Gas Engine: Select this if you have a traditional (non ECU) engine and require GAS engine functionality.
Page 16: Disable Protections
Edit Configuration - Application 4.3.3 DISABLE PROTECTIONS This feature is provided to assist the system designer in meeting specifications for “Warning only”, “Protections Disabled”, “Run to Destruction”, “War mode” or other similar wording. Options Description Enable = The module will operate as normal and provide engine shutdown if required. = Protections disabled function is activated.
Page 17: Inputs
Edit Configuration - Inputs 4.4 INPUTS The inputs page is subdivided into smaller sections. Select the required section with the mouse. 4.4.1 OIL PRESSURE Click to edit the Select the ‘sensor curve’. See sensor type section entitled Editing the sensor curve.
Page 18: Coolant Temperature
Edit Configuration - Inputs 4.4.2 COOLANT TEMPERATURE 4.4.2.1 COOLANT TEMPERATURE ALARMS Select the Click to edit the sensor type ‘sensor curve’. See section entitled Editing the sensor curve. Enable or disable the alarms. The relevant values below will appear greyed out if the alarm is disabled.
Page 19: Coolant Temperature Control
Edit Configuration -Inputs 4.4.2.2 COOLANT TEMPERATURE CONTROL The Coolant temperature control settings provide for control of coolant heaters / coolers using the Coolant Temperature Sensor as the control input. Outputs should be configured to Coolant Cooler Control and/or Coolant Heater Control to achieve this. Enable or disable the alarms.
Page 20: Fuel Level
Edit Configuration - Inputs 4.4.3 FUEL LEVEL Click to edit the Select the ‘sensor curve’. See sensor type section entitled Editing the sensor curve. Click and drag to alter Click to enable or the time disable the alarms. delay The relevant values below will appear greyed out if the alarm is disabled.
Page 21: Flexible Sensor
Edit Configuration -Inputs 4.4.4 FLEXIBLE SENSOR The following screen shot shows the configuration when set for Temperature Sensor. When set to other Sensor Type, consult the relevant manual section for details (Digital inputs, Oil Pressure input etc) Select the Click to edit the sensor type ‘sensor curve’.
Page 22: Editing The Sensor Curves
Edit Configuration - Inputs 4.4.5 EDITING THE SENSOR CURVES While the configuration suite holds sensor specification for the most commonly used resistive sensors, occasionally it is required that the module be connected to a sensor not listed by the configuration suite. To aid this process, a sensor editor has been provided.
Page 23: Digital Inputs
Edit Configuration -Inputs 4.4.6 DIGITAL INPUTS The digital inputs page is subdivided into smaller sections. Select the required section with the mouse. Input function. See section entitled Input functions for details of all available functions As this example shows a predefined function, these parameters are greyed out as they are...
Page 24: Digital Input Functions
Edit Configuration - Inputs 4.4.7 DIGITAL INPUT FUNCTIONS Where a digital input is NOT configured as “user configured”, a selection can be made from a list of predefined functions. The selections are as follows: Under the scope of IEEE 37.2, function numbers can also be used to represent functions in microprocessor devices and software programs.
Page 25 Edit Configuration -Inputs Function Description Close Generator Closes the Generator load switch (synchronising first if required) IEEE 37.2 - 52 AC circuit breaker Coolant Temperature High This input is used to give a Coolant Temperature High shutdown from a switch digital normally open or closed switch.
Page 26 Edit Configuration - Inputs Function Description Generator Closed Auxiliary This input is used to provide feedback to allow the DSE7400 to give IEEE 37.2 - 3 Checking or true indication of the contactor or circuit breaker switching status. It interlocking relay should be connected to the generator load switching device auxiliary contact.
Page 27 Edit Configuration -Inputs Function Description Oil Pressure Switch A digital normally open or closed oil pressure switch gives this input. It allows oil pressure protection using the switch and the analogue input to be used in parallel to give protection or to be used for oil pressure indication only.
Page 28 Edit Configuration - Inputs Function Description Smoke limit This input instructs the module to give a run at idle speed command to IEEE 37.2 – 18 accelerating or the engine either via an output configured to smoke limit or by data decelerating device commands when used with supported electronic engines.
Page 29 Edit Configuration -Inputs Function Description Transfer to Mains/ Open This input is used to transfer the load to the mains supply (AMF Generator module) when running in MANUAL MODE or provide the ‘Open Generator’ signal in a non AMF Module.) IEEE 37.2 - 52 AC circuit breaker Transfer to generator/Open This input is used to transfer the load to the generator when running in...
Page 30: Outputs
Edit Configuration - Outputs 4.5 OUTPUTS 4.5.1 DIGITAL OUTPUTS These are greyed out as they are fixed, not Outputs A & B adjustable unless a CAN applicable to engine has been DSE8610/DSE86 selected 20 only Select what the Select if the relay is to output is to be energise or de-energise used to control...
Page 31: Virtual Leds
Edit Configuration - Outputs 4.5.2 VIRTUAL LEDS Allows the configuration of ‘status’ items. These items are not available for viewing on the module itself but can be seen in the SCADA section of the PC software, or read by third party systems (i.e. BMS or PLCs) using the Modbus protocol.
Page 32: Output Sources
Edit Configuration - Outputs 4.5.3 OUTPUT SOURCES The list of output sources available for configuration of the module relay outputs also applies to the LED configuration and expansion relay outputs. Under the scope of IEEE 37.2, function numbers can also be used to represent functions in microprocessor devices and software programs.
Page 33 IEEE 37.2 – 52 ac circuit breaker selects the generator to be on load this control source will be active. Close Gen Output Pulse DSE7400 Used to control the load switching device. Whenever the module IEEE 37.2 – 52 ac circuit breaker...
Page 34 Edit Configuration - Outputs Output source Activates… Is not active…. Combined Under and Overvoltage Active when the generator is shutdown due to either under OR overvoltage shutdown IEEE 37.2 – 27AC under voltage relay IEEE 37.2 – 59AC over voltage relay Combined Under and Overvoltage Active when the generator alarm for either under OR overvoltage is active warning...
Page 35 Edit Configuration - Outputs Output source Activates… Is not active…. Fuel Relay Becomes active when the controller requires Becomes inactive whenever the set the governor/fuel system to be active. should be stopped, including between crank attempts, upon controlled stops and upon fault shutdowns. Fuel Usage Alarm Becomes active when the amount of fuel used over a set time period exceeds the set value.
Page 36 Edit Configuration - Outputs Output source Activates… Is not active…. Inhibit Retransfer to Mains Indicates when mains fails,Gens fails and mains not enough capacity to take load inhibit retransfer. Interlock Override Comes on just before and just after the gen-set goes into parallel enabling an output for a mechanical or electrical interlock kW Overload Shutdown / Active when the measured kW are above the setting of the kW overload shutdown /...
Page 37 Edit Configuration - Outputs Output source Activates… Is not active…. Maintenance Alarm 1,2,3 Due Indicates that the specified maintenance alarm is due Manual Mode Active when the controller is in MANUAL Inactive in any other mode. mode Mute / Lamp test button pressed This output indicates that the alarm mute / Lamp test pushbutton is being operated.
Page 38 Edit Configuration - Outputs Output source Activates… Is not active…. Over Speed Shutdown Active if the engine speed exceeds the Over Speed Shutdown setting IEEE 37.2 – 12 over speed device Over Speed Warning Active if the engine speed exceeds the Over Speed Warning setting IEEE 37.2 –...
Page 39 Edit Configuration - Outputs Output source Activates… Is not active…. Return delay in progress This output source will be active to indicate that the return timer is running. Short Circuit Generator This output indicates that the module has detected a short circuit on the generator output.
Page 40 Edit Configuration - Outputs Output source Activates… Is not active…. Under Frequency Warning Active when the generator frequency falls Inactive when • below the Low Frequency Warning The set is stopped IEEE 37.2 - 81 frequency relay • During starting sequence before the safety delay time has expired.
Page 41: Timers
Edit Configuration - Timers 4.6 TIMERS Many timers are associated with alarms. Where this occurs, the timer for the alarm is located on the same page as the alarm setting. Timers not associated with an alarm are located on the timers page. The Timers page is subdivided into smaller sections.
Page 42 Edit Configuration - Timers Timer Description Pre-heat Give a ‘pre start’ time during which the Preheat output and Starting alarm will become active (if configured) Pre-heat bypass Should the set be stopped, the Pre-heat bypass timer begins. Should the set be called to start again, before the timer expires, the pre-heat sequence is bypassed as heating is not required since the set is still warm after the last run.
Page 43: Load / Stopping Timers
Edit Configuration - Timers 4.6.2 LOAD / STOPPING TIMERS Click and drag to change the setting. Timers increment in steps of 1second up to one minute, then in steps of 30 seconds up to 30 minutes, then in steps of 30 minutes thereafter (where allowed by the limits of the timer).
Page 44: Generator
Edit Configuration - Generator 4.7 GENERATOR The generator page is subdivided into smaller sections. Select the required section with the mouse. Click to enable or disable the alarms. 4.7.1 GENERATOR OPTIONS The relevant values below appear greyed out if the alarm is disabled.
Page 45: Generator Breaker Control
Edit Configuration - Generator Parameter Description = There is no alternator in the system, it is an engine only application Alternator fitted = An alternator is fitted to the engine, it is a generator application. Poles The number of poles on the alternator VT Fitted = The voltage sensing to the controller is direct from the alternator = The voltage sensing to the controller is via Voltage Transformers (VTs or PTs)
Page 46: Generator Voltage Alarms
Edit Configuration - Generator 4.7.2 GENERATOR VOLTAGE ALARMS Click to enable or disable the alarms. The relevant values below appear greyed out if the alarm is disabled. Type the value or click the up Select the type of and down alarm required.
Page 47: Generator Frequency Alarms
Edit Configuration - Generator 4.7.3 GENERATOR FREQUENCY ALARMS Click to enable or disable the alarms. The relevant values below appear greyed out if the alarm is disabled. Type the value or click the up and down arrows to Click and drag to change the change the setting.
Page 48: Generator Current
Edit Configuration - Generator 4.7.4 GENERATOR CURRENT The Generator Current page is subdivided into smaller sections. Select the required section with the mouse. 4.7.4.1 GENERATOR CURRENT OPTIONS Timer Description CT Primary Primary rating of the Current Transformers CT Secondary Secondary rating of the Current Transformers CT Location Determine the location of the Current Transformers Gen: The CTs are in the feed from the generator and shows only generator current and...
Page 49: Generator Current Alarms
Edit Configuration - Generator 4.7.4.2 GENERATOR CURRENT ALARMS Click to enable or disable the option. The relevant values below appear greyed out if the alarm is disabled. Click and drag to change the setting. Often called Negative Sequence Current, this checks that the alternator is not loaded ‘out of balance’...
Page 50 Edit Configuration - Generator GENERATOR OverCURRENT ALARM Overcurrent Alarm The overcurrent alarm combines a simple warning trip level combined with a fully functioning IDMT curve for thermal protection. Immediate warning IEEE 37.2 -50 instantaneous overcurrent relay If the current exceeds the Trip level the Immediate Warning activates. IDMT Alarm IEEE 37.2 -51 AC time overcurrent relay (shutdown / electrical trip) If the IDMT Alarm is enabled, the 7400 Series controller begins following the IDMT ‘curve’.
Page 51 Edit Configuration - Generator...
Page 52 Edit Configuration - Generator Creating an Excel spreadsheet of the IDMT curve. T = t / ( ( I ) – 1 ) The formula used: Can be simplified for addition into a spreadsheet. This can be useful for ‘trying out’ differering values of t (Time Multiplier) and viewing the results, without actually testing this on the engine.
Page 53: Short Circuit
Edit Configuration - Generator 4.7.4.3 SHORT CIRCUIT IEEE 37.2 -51 AC time overcurrent relay (shutdown / electrical trip) For overload conditions caused by a short circuit, the overcurrent alarm is not fast enough to protect the system. The Short Circuit alarm performs this protection. If the Short Circuit alarm is enabled, and the current is excessive, the controller begins following the IDMT ‘curve’.
Page 54: Negative Phase Sequence
Edit Configuration - Generator 4.7.4.4 NEGATIVE PHASE SEQUENCE (Negative Sequence Current / Unbalanced Load) Unbalanced loads cause negative sequence current in the alternator stator. These currents cause harmonics which can eventually lead to overheating and melting of the rotor. An unbalanced load is however, permissible within limits.
Page 55: Earth Fault
Edit Configuration - Generator 4.7.4.5 EARTH FAULT IEEE 37.2 -51 AC time overcurrent relay (shutdown / electrical trip) When the module is suitably connected using the ‘Earth Fault CT’. The module measures Earth Fault and can optionally be configured to generate an alarm condition when a specified level is surpassed. If the Earth Fault alarm is enabled, the controller begins following the IDMT ‘curve’.
Page 56: Generator Power
Edit Configuration - Generator 4.7.5 GENERATOR POWER The Power page is subdivided into smaller sections. Select the required section with the mouse. 4.7.5.1 OVERLOAD PROTECTION Overload protection is a subpage of the Generator Power page. Click to enable or disable the option. The relevant values below will appear greyed out if the...
Page 57: Load Control
Edit Configuration - Generator 4.7.5.2 LOAD CONTROL Click to enable or disable the option. The relevant values below will appear greyed out if the alarm is disabled. Click to enable or disable the option. The relevant values below will appear greyed out if the alarm is disabled.
Page 58: Reverse Power
Edit Configuration - Generator Setting Description Load Shedding Control Provides control of configurable outputs set to Load shedding control. = Load Shedding Control is disabled. = The module will monitor the load and control any outputs configured to Load Shedding Control (1-5) Outputs in Scheme: The number of outputs (max 5) that will be included in the function.
Page 59: Mains
Edit Configuration - Mains 4.8 MAINS The Mains page is subdivided into smaller sections. Select the required section with the mouse. 4.8.1 MAINS OPTIONS This is ‘read only’ for information purposes. The AC system is configured in the ‘Generator Options’ page. Parameters are detailed overleaf…...
Page 60 Edit Configuration - Mains Timer Description AC System These settings are used to detail the type of AC system to which the module is connected: 3 phase 4 wire, 1 phase 2 wire, 2 phase 3 wire – L1-L2, 2 phase 3 wire – L1-L3, 3 phase 3 wire, 3 phase 4 wire delta This list is not exhaustive.
Page 61: Mains Voltage Alarms
Edit Configuration - Mains 4.8.2 MAINS VOLTAGE ALARMS Click to enable or disable the alarms. The relevant values below will appear greyed out if the alarm is disabled. Type the value or click the up and down arrows to change the settings Click and drag to change the setting.
Page 62: Mains Frequency Alarms
Edit Configuration - Mains 4.8.3 MAINS FREQUENCY ALARMS Click to enable or disable the alarms. The relevant values below will appear greyed out if the alarm is disabled. Type the value or click the up and down arrows to Click and drag to change the change the setting.
Page 63: Mains Current
Edit Configuration - Mains 4.8.4 MAINS CURRENT NOTE: Mains Current Alarms are provided on DSE7420 modules V1.3 and higher only, and only when the Current Transformers are fitted into the ‘load leg’. Parameter Description Alarm Action NOTE: Mains Current Alarms generate a Mains Failure in addition to the configured Alarm Action.
Page 64: Overcurrent Alarm
Edit Configuration - Mains 4.8.4.1 OVERCURRENT ALARM The overcurrent alarm combines a simple warning trip level combined with a fully functioning IDMT curve for thermal protection. Immediate Warning IEEE 37.2 -50 instantaneous overcurrent relay If the current exceeds the Trip level the Immediate Warning activates. IDMT Alarm IEEE 37.2 -51 AC time overcurrent relay (shutdown / electrical trip) If the IDMT Alarm is enabled, the controller follows the IDMT ‘curve’.
Page 65 Edit Configuration - Mains...
Page 66 Edit Configuration - Mains Creating an Excel spreadsheet of the IDMT curve. T = t / ( ( I ) – 1 ) The formula used: Can be simplified for addition into a spreadsheet. This can be useful for ‘trying out’ differering values of t (Time Multiplier) and viewing the results, without actually testing this on the controller.
Page 67: Short Circuit
IEEE 37.2 -51 AC Time Overcurrent Relay (shutdown / electrical trip) If the Short Circuit alarm is enabled, the DSE7400 Series controller begins following the IDMT ‘curve’. If the Trip is surpassed for an excess amount of time the Alarm triggers (Shutdown or Electric trip as selected in Action).
Page 68: Earth Fault
If the Earth Fault alarm is enabled, the DSE7400 Series controller begins following the IDMT ‘curve’. If the Trip is surpassed for an excess amount of time the Alarm triggers (Shutdown or Electric trip as selected in Action).
Page 69: Engine
Edit Configuration - Engine 4.9 ENGINE The Engine page is subdivided into smaller sections. Select the required section with the mouse. 4.9.1 ENGINE OPTIONS This item is not adjustable here, it’s read only. To change this item, visit the Module | Application menu.
Page 70: Sensing Options
Edit Configuration - Engine 4.9.1.1 SENSING OPTIONS Parameter Description Disable ECM = An ECM is fitted to the DSE module and being used for speed sensing. Speed Sensing = An ECM is fitted to the DSE module but another form of speed sensing fitted to the DSE module is being used.
Page 71: Can Options
Edit Configuration - Engine 4.9.2 CAN OPTIONS When enabled, DSE module counts Engine Run Hours. When disabled, Engine ECU provides Run Hours. When enabled, DSE module periodically ‘powers up’ the engine ECU when the engine is stopped. This can be utilised to provide coolant temperature measurement when the engine is stopped.
Page 72: Dm1 Signals
Edit Configuration - Engine 4.9.3.2 DM1 SIGNALS DM1 signals are messages from the CAN ECU. The following parameters allows configuration of how the DSE module responds to these messages. 4.9.3.3 ADVANCED Allows configuration of selected additional CAN messages from the engine ECU.
Page 73: Gas Engine Options
Edit Configuration - Engine 4.9.5 GAS ENGINE OPTIONS Controls the amount of time that the Gas Choke output will be active during the starting sequence. Controls the amount of time between energising the Gas Ignition and Controls the amount of time energising the Fuel between de-energising the output.
Page 74: Cranking
Edit Configuration - Engine 4.9.6 CRANKING Crank disconnect settings are used to detect when the set fires during the starting sequence. As the set is cranked, the first parameter that passes it’s crank disconnect setting will result in the cessation of the cranking signal.
Page 75: Speed Settings
Edit Configuration - Engine 4.9.7 SPEED SETTINGS Click to enable or disable the option. The relevant values below will appear greyed out if the Select the type of alarm alarm is disabled. required. For details of these, see the section entitled Alarm Types elsewhere in this document.
Page 76: Plant Battery
Edit Configuration - Engine 4.9.8 PLANT BATTERY Click and drag to change the setting. Type the value or click the up and down arrows to change the settings Alarm IEEE designation Plant Battery Under volts IEEE 37.2 -27 DC Under voltage relay Plant Battery Over volts IEEE 37.2 -59 DC Over voltage relay...
Page 77: Inlet Temperature
Edit Configuration - Engine 4.9.9 INLET TEMPERATURE Provides inlet temperature alarms when the module is used in conjunction with electronic (ECU) engines that support the reading of inlet temperature. If a supported ECU engine is not selected on the Application page of the configuration, the whole page is greyed out and cannot be enabled.
Page 78: Communications
Edit Configuration - Communications 4.10 COMMUNICATIONS 4.10.1 COMMUNICATION OPTIONS Provides a means of giving the control an identity name. This is used in the SCADA section to allow the operator to see the site name and genset identity that is currently connected to the SCADA. As this could be a remote module connected over modem or Ethernet connection this is a very useful feature.
Page 79: Rs232 Port
Edit Configuration - Communications 4.10.2 RS232 PORT 4.10.2.1 BASIC Modbus Slave ID Baud rate adjustable from 1200-57600 Selects how the port is to be used These items are greyed out until a relevant option in Port Usage is selected. SERIAL PORT CONFIGURATION Timer Description Port usage...
Page 80 Edit Configuration - Communications MODEM SETTINGS Timer Description Alarm Number The phone number that the module will dial upon an alarm condition. This number must be connected to a PC modem on a PC running the Configuration Suite Software. GSM Modem = The connected modem is a fixed line telephone modem = The connected modem is a GSM (cellular) modem.
Page 81: Advanced
Edit Configuration - Communications 4.10.2.2 ADVANCED Modem initialisation strings. These set up the modem to perform the functions required. INITIALISATION STRINGS The initialisation strings are commands that are sent to the modem upon powering up the DSE module and additionally at regular intervals subsequently, whenever the module initialises (resets) the modem. Factory set initialisation strings Setting Description...
Page 82 Edit Configuration - Communications Wavecom Fastrak Xtreme GSM Modem initialisation strings When connected to the Wavecom Fastrak Xtreme GSM modem, the initialisation strings must be altered by changing the factory set &D3 to &D2. Setting Description &D2 Hang up on DTR-drop (required for Wavecom Fastrak Supreme) &D3 Reset on DTR-drop...
Page 83: Troubleshooting Modem Communications
<ENTER> This saves the new setting in the modem. Power can now be removed. The next time power is applied, the modem starts with the new settings (Baud rate = 9600), suitable to communicate with the DSE7400 series module.
Page 84: Rs485 Port
Edit Configuration - Communications 4.10.4 RS485 PORT Modbus Slave ID Baud rate adjustable from 1200-57600 Timer Description Master inactivity timeout The module looks by default at the USB port for communications. When activity is detected on the RS232 or RS485 port, the module switches to look at the relevant port for further data.
Page 85: Ethernet Port
This means that only a single, unique IP address is required to represent an entire group of computers. For our DSE7400 application, this means that the WAN IP address of the modem/router is the IP address we need to access the site from an external (internet) location.
Page 86: Scheduler
Edit Configuration - Communications 4.11 SCHEDULER The Exercise Scheduler is used to give up to 16 scheduled runs. This run schedule is configurable to repeat every 7 days (weekly) or every 28 days (monthly). The run can be on load or off load. Click to enable or disable the option.
Page 87: Maintenance Alarm
Edit Configuration - Maintenance 4.12 MAINTENANCE ALARM Three maintenance alarms are available to provide maintenance schedules to the end user. For instance Maintenance Alarm 1 can be used for an oil change schedule, Maintenance Alarm 2 for a battery change schedule etc. Click to enable or disable the option.
Page 88: Alternative Configurations
• DSE7400 Series Fascia Editor • Via external signal to DSE7400 Series module input configured to “Alt Config x” select. • Auto Voltage Sensing. Whereby during the starting sequence, the AC system, voltage and frequency of the connected supply is monitored. The module selects the most appropriate configuration (alternative 1, 2 or 3 or the main configuration) to suit the connected supply.
Page 89: Example Of Usage
Edit Configuration – Alternative Configurations 4.13.3 EXAMPLE OF USAGE The DSE module contains a configuration file, holding the settings for inputs, outputs, timers, voltage and frequency trip points etc. This is called the ‘main configuration’. Additionally ‘alternative configuration’ files are present, holding a subset of the main configuration file. This allows another collection of settings for items such as voltage and frequency trip points.
Page 90: Using The Alternative Configuration To Handle Speed Change
Selecting between the main and alternative configurations is achieved using either: • Configuration Suite Software (Selection for ‘Default Configuration) • DSE7400 Series Fascia Editor • Via external signal to the module input configured to “Alt Config x” select. • Auto Voltage Sensing. Whereby during the starting sequence, the AC system, voltage and frequency of the connected supply is monitored.
Page 91: Expansion
Edit Configuration – Expansion 4.14 EXPANSION The Expansion page is subdivided into smaller sections. Select the required section with the mouse. See overleaf for description of the different expansion modules.
Page 92: Dse2130 Input Modules
Edit Configuration – Expansion 4.14.1 DSE2130 INPUT MODULES Select the DSENet ID of the input expansion you wish to configure. The ID of the expansion input module is set by rotary decimal switch accessible under the removable cover of the device. The following is then shown: Click to enable or disable the option.
Page 93: Analogue Inputs (E-H)
Edit Configuration – Expansion 4.14.1.2 ANALOGUE INPUTS (E-H) Configure the sensor type. Select Digital Input to use the analogue input as a digital input Depending upon your selection above, either the Analogue Input or Digital Input configuration screen is shown Used as an Analogue Input Edit the sensor curve if required.
Page 94: Dse2131 Ratiometric Expansion Input Module
Edit Configuration – Expansion 4.14.2 DSE2131 RATIOMETRIC EXPANSION INPUT MODULE Select the DSENet ID of the input expansion you wish to configure. The ID of the expansion input module is set by rotary decimal switch accessible under the removable cover of the device. The following is then shown: Click to enable or disable the option.
Page 95 Edit Configuration – Expansion Depending upon your selection of Sensor Type, one of the following configuration screens are shown : Used as a Digital Input Select the required function of the input and whether it is open or close to activate. Select the required alarm type of the input and when it is active.
Page 96 Edit Configuration – Expansion The following screen shot shows the configuration when set for Temperature Sensor. When set to other Sensor Type, consult the relevant manual section for details (Digital inputs, Oil Pressure input etc) Select the Click to edit the sensor type ‘sensor curve’.
Page 97: Editing The Sensor Curves
Edit Configuration – Expansion 4.14.2.1 EDITING THE SENSOR CURVES Click Interpolate then select two points as prompted to draw a straight line between Click and drag the them. points on the graphs to change the settings Click CANCEL to ignore and lose any changes you have made Click OK to accept...
Page 98: Dse2133 Rtd / Thermocouple Input Module
Edit Configuration – Expansion 4.14.3 DSE2133 RTD / THERMOCOUPLE INPUT MODULE Select the DSENet ID of the input expansion you wish to configure. The ID of the expansion input module is set by rotary decimal switch accessible under the removable cover of the device. The following is then shown: Click to enable or disable the option.
Page 99 Edit Configuration – Expansion Increases temperature alarms to 1300 deg C Choose between Type J or Type K thermocouples or RTD (PT100) Set the alarm trip points if required.
Page 100: Dse2152 Analogue Output Module
Edit Configuration – Expansion 4.14.4 DSE2152 ANALOGUE OUTPUT MODULE Select the DSENet ID of the output expansion you wish to configure. The ID of the expansion output module is set by rotary decimal switch accessible under the removable cover of the device. The following is then shown: Click to enable or disable the option.
Page 101: Editing The Output Curve
Edit Configuration – Expansion 4.14.4.1 EDITING THE OUTPUT CURVE Show and hide the knee point (middle point) of the output curve Choose the x axis Click and drag the points on the start and end points graphs to change the settings. In this example 0 Hz –...
Page 102: Dse2157 Relay Modules
Edit Configuration – Expansion 4.14.5 DSE2157 RELAY MODULES Select the DSENet ID of the relay expansion you wish to configure. The ID of the relay board is set by rotary decimal switch accessible under the removable cover of the device. The following is then shown: Click to enable or disable the option.
Page 103: Dse2548 Led Expansion
Edit Configuration – Expansion 4.14.7 DSE2548 LED EXPANSION Select the DSENet ID of the LED expansion you wish to configure. The ID of the Annunciator is set by rotary decimal switch accessible on the back of the device. The following is then shown: Click to enable or disable the option.
Page 104: Advanced
Edit Configuration – Advanced 4.15 ADVANCED These settings are provided for advanced users only. Take care when changing these options and ensure you fully understand the consequences of any change made.
Page 105: Advanced Options
Edit Configuration – Advanced – PLC Logic 4.15.1 ADVANCED OPTIONS 4.15.1.1 PROTECTIONS This feature is provided to assist the system designer in meeting specifications for “Warning only”, “Protections Disabled”, “Run to Destruction”, “War mode” or other similar wording. WARNING! - Enabling this feature will prevent the set being stopped upon critical alarm conditions.
Page 106: Plc Logic
Edit Configuration – Advanced – PLC Logic 4.15.2 PLC LOGIC PLC Logic adds comprehensive PLC functionality to the DSE controller. This is an advanced section, used entirely at your own risk. 4.15.2.1 MENU PLC Logic Conditions PLC Logic Actions PLC Logic Counters and Timers configuration In PLC logic, the ladder of logic is made up of a series of rungs.
Page 107: Flags
Edit Configuration – Advanced – PLC Logic 4.15.2.2 FLAGS A flag is set when a condition within the DSE controller is met. For instance, if the module is in Auto Mode an internal flag is set. This flag is exposed as an output source when configuring module outputs and LEDs. In addition to internal flags, a further twenty (20) custom flags are available (named PLC Flag 1-20).
Page 108: Counters
Edit Configuration – Advanced – PLC Logic 4.15.2.4 COUNTERS The PLC logic section contains twenty (20) user counters for use in the ladder. A counter is configured by clicking in the menu bar. The ‘Edit counter limits’ window appears. Click and drag to change the setting, or press keyboard left and right arrow keys to change by small amounts.
Page 109: Plc Functions
Edit Configuration – Advanced – PLC Logic 4.15.2.5 PLC FUNCTIONS PLC Functions allow the PLC logic to create alarm conditions or drive ‘virtual inputs’ on the controller. A PLC function is configured in the same way as a module digital input: Predefined Functions Function.
Page 110 Edit Configuration – Advanced – PLC Logic User Defined alarms Configures when the input is active: Never, always, active from starting, active from the end of the safety timer Example of a user configured input Close or open to activate This is the text that will be displayed on the module screen...
Page 111: Creating And Editing Rungs
Edit Configuration – Advanced – PLC Logic 4.15.2.6 CREATING AND EDITING RUNGS • Click a symbol in the tool bar and drag it to the bar ( to create the first rung in your ladder. • Click a symbol in the tool bar and drag it to a blank space below existing rungs to create a new rung. •...
Page 112: Conditions
Edit Configuration – Advanced – PLC Logic 4.15.2.7 CONDITIONS Conditions Test flag (for instance : test module inputs, test for certain condition) Test an instrumentation value Test a counter Test a timer Test for a specific time period in the day...
Page 113 Edit Configuration – Advanced – PLC Logic Conditions Test for a certain day Test for a certain week Test for a certain month Test for a module button press...
Page 114: Actions
Edit Configuration – Advanced – PLC Logic 4.15.2.8 ACTIONS Actions Set a PLC flag (Set to 1) Reset a PLC flag (Set to 0) Toggle a flag (swap 0/1 or 1/0) Drive a flag (automatically clears when the condition is false) Increment a counter Decrement a counter Set a counter to zero...
Page 115 Edit Configuration – Advanced – PLC Logic Actions Drive a PLC function Write a value to a Gencomm register Reset an alarm...
Page 116: Examples
Edit Configuration – Advanced – PLC Logic 4.15.2.9 EXAMPLES AUTO MUTE after 30 seconds and provide a manual mute function using Digital Input C. PLC Function 1 configured to Alarm Mute. Digital Input C configured to Indication. This input will be checked for by the PLC logic.
Page 117: Configurable Gencomm
Edit Configuration – Advanced – PLC Logic 4.15.3 CONFIGURABLE GENCOMM PAGES For advanced Modbus users of the controller, configurable Gencomm pages are available. The intention is to allow the user to create personal collections of data in subsequent registers to minimise the number of modbus reads required by the master, and hence speed up data collection.
Page 118: Scada
SCADA 5 SCADA SCADA stands for Supervisory Control And Data Acquisition and is provided both as a service tool and also as a means of monitoring / controlling the generator set. As a service tool, the SCADA pages is to check the operation of the controller’s inputs and outputs as well as checking the generators operating parameters.
Page 119: Generator Identity
SCADA 5.1 GENERATOR IDENTITY Shows the module’s current settings for Site ID and genset ID. This information is particularly helpful when the current connection is made remotely by modem or internet for example or when the connected set is one of a number of sets on an RS485 data link. 5.2 MIMIC This screen provides a mimic of the control module and allows the operator to change the control mode of the module.
Page 120: Languages
SCADA 5.3 LANGUAGES Select new language Click to send the new language to the module 5.4 DIGITAL INPUTS Shows if the input channel is active or not. This input is closed and is active. The input is configured to be close to activate State of the input (open or closed to battery negative)
Page 121: Digital Outputs
SCADA 5.5 DIGITAL OUTPUTS State of the output (open or closed) Shows if the output channel is active or not. This output is closed but is active. The output is configured to be Close Mains de-energise. As the relay is normally closed (N/C) and the Close Mains source is not present, the relay is activated to open the N/C relay.
Page 122: Mains
SCADA 5.7 MAINS DSE7420 AMF MODULES ONLY Shows the modules measurements of the mains supply. 5.7.1 FREQUENCY AND VOLTAGES Shows the modules measurements of the mains supply...
Page 123: Power
SCADA 5.7.2 POWER Shows the modules measurements of the mains supply power...
Page 124: Generator
SCADA 5.8 GENERATOR The Generator section is subdivided into smaller sections. Select the required section with the mouse. 5.8.1 FREQUENCY, VOLTAGES AND CURRENT Shows the modules measurements of the supply.
Page 125: Power
SCADA 5.8.2 POWER Shows the modules measurements of the supply power.
Page 126: Engine
SCADA 5.9 ENGINE Shows the modules measurements of the engine parameters. 5.10 FLEXIBLE SENSOR Shows the measurement of the Flexible Sensor (If configured)
Page 127: Alarms
SCADA 5.11 ALARMS Shows any present alarm conditions. For a description of the different alarm types, see the section entitled Alarm Types elsewhere in this manual.
Page 128: Status
SCADA 5.12 STATUS Shows the module’s current status.
Page 129: Event Log
SCADA 5.13 EVENT LOG Shows the contents of the module’s event log. Click to save the log Click to save the log to to a pdf (Adobe an Excel or csv file for Click to print the log Acrobat) file use in an external spreadsheet program...
Page 130: Enhanced Canbus
SCADA 5.14 ENHANCED CANBUS If the module is connected to a compatible electronic engine, the following information is read from the ECU (if supported by the engine ECU).
Page 131: Remote Control
SCADA 5.15 REMOTE CONTROL The remote control section of the SCADA section is used for monitoring and control of module ‘remote control’ sources. Any of the module outputs, expansion outputs, LED indicators, or remote Annunciator LEDs can be configured to Remote Control 1-10. This output source is energised/de-energised by click the respective check box as shown below in the Activate column below.
Page 132: Maintenance
SCADA 5.16 MAINTENANCE The Maintenance section is subdivided into smaller sections. Select the required section with the mouse. 5.16.1 RECALIBRATE TRANSDUCERS This section allows the analogue sensor inputs to be calibrated to remove inaccuracies caused by the tolerance of the sensor devices. The engine can be running when the instruments are calibrated and reference should be made to a third party accurate sensing device to ensure accurate recalibration.
Page 133: Expansion Calibration
SCADA 5.16.3 EXPANSION CALIBRATION This section allows the analogue sensor inputs of the DSE2130 input expansion modules to be calibrated to remove inaccuracies caused by the tolerance of the sensor devices. The engine can be running when the instruments are calibrated and reference should be made to a third party accurate sensing device to ensure accurate recalibration.
Page 134: Accumulated Instrumentation
SCADA 5.16.6 ACCUMULATED INSTRUMENTATION Allows the user to view or change the module’s accumulated instrumentation. Display of the Type the new module’s value or click current value the up and for the down arrows to parameter change the settings Click Set to adjust the module to the selected value...
Page 135: Maintenance Alarm Reset
SCADA 5.16.7 MAINTENANCE ALARM RESET Three maintenance alarms active in the control module. Each is reset individually; only one alarm is shown below for clarity. Reset the maintenance alarm based upon the module’s configuration. 5.16.8 MODULE PIN NOTE : If the PIN is lost of forgotten, it will not be possible to access the module! Allows a PIN (Personal Identification Number) to be set in the controller.
Page 136: Datalog
SCADA 5.17 DATALOG Allows viewing of the module datalog (if configured). NOTE: - Data logging is a ‘live’ function – Maximum 8hrs duration is shown so long as the PC is left connected to the controller. Navigation sliders Zoom slider The data is automatically collated and presented in the graphs.
Page 137: Plc
SCADA 5.18 PLC Allows monitoring of the PLC functions within the controller. Green highlighting shows the condition is True. Live timer and counter display subject to the speed of update over the communications link Flag State – Clear means the flag is not set.
Page 138: Expansion
SCADA 5.19 EXPANSION Allows monitoring of the controller’s expansion modules (if fitted) For example:...
Page 139: Alarm Types
Alarm Types 6 ALARM TYPES The protection included with the DSE control modules provides increasing levels of notification, depending upon the severity of the situation: Alarm type Description Indication No audible alarm or common warning signal occurs. Indication alarms are only used to illuminate indicators or to activate outputs. Warning Audible alarm and common alarm signal is generated.
