- Page 1 INSTRUCTION MANUAL Cutter MCC401 001671 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model MCC401 Blade diameter 110 mm Hole diameter 20 mm Max. cutting capacity 32 mm No load speed (min 13,000 Overall length 226 mm Net weight 3.0 kg Safety class • Due to our continuing programme of research and development, the specifications herein are subject to change without notice. - Page 3 If operating a power tool in a damp location is preventive safety measures reduce the risk of unavoidable, use a residual current device starting the power tool accidentally. (RCD) protected supply. Use of an RCD reduces 21. Store idle power tools out of the reach of the risk of electric shock.
- Page 4 Always use undamaged wheel flanges that are tool out of your control. of correct diameter for your selected wheel. 14. Do not run the power tool while carrying it at Proper wheel flanges support the wheel thus your side. Accidental contact with the spinning reducing the possibility of wheel breakage.
- Page 5 Do not attach a saw chain woodcarving blade OPERATING INSTRUCTIONS or toothed saw blade. Such blades create frequent kickback and loss of control. Removing or installing diamond wheel Do not "jam" the wheel or apply excessive (optional accessory) pressure. attempt make excessive depth of cut.
-
Page 6: Adjusting Depth Of Cut
Adjusting depth of cut Switch action 1. Wing bolt 1. Switch trigger 2. Base 2. Lock button 001672 001673 Loosen the wing bolt on the depth guide and move the CAUTION: base up or down. At the desired depth of cut, secure the Before plugging in the tool, always check to see •... -
Page 7: Maintenance
MAINTENANCE CAUTION: Always be sure that the tool is switched off and • unplugged before carrying out any work on the tool. Never use gasoline, benzine, thinner, alcohol or the • like. Discoloration, deformation or cracks may result. After use Blow away dust from the inside of the tool by running the tool at an idle for a while. - Page 8 Makita Corporation www.makita.com 885047-3...
