Harman Kardon AVR 525 Reference Manual

AVR 525 FRONT PANEL CONTROLS
1 Main Power Switch
2 System Power Control
3 Power Indicator
4 Headphone Jack
5 Tone Mode
6 Speaker Selector
7 Surround Mode Group Selector
8 Surround Mode Selector
9 Tuning Selector
)
Button
‹
! Tuner Band Selector
@ Set Button
#
Button
›
$ Preset Station Selector
% Input Source Selector
^ Tuner Mode Selector
& Optical 3 Digital Input
* Input/Output Status Indicator
( Coaxial 3 Digital Input/Output
Ó Video 4 Input/Output Jacks
Ô Bass Control
 Balance Control
Ò Treble Control
Ú Channel Adjust Selector
Û Delay Adjust Selector
Ù Digital Input Selector
ı Volume Control
ˆ Input Indicators
˜ Main Information Display
¯ Remote Sensor Window
˘ Surround Mode Indicators
