M2 GEAR PACK — PNEUMATIC CONSOLE QUICK START GUIDE
1
POWER SWITCH
Used to turn On/Off the M2 pneumatic console
2
START/STOP BUTTON
Use to start or stop treatment. To pause treatment, press start/stop
and hold for 3 seconds. Press start/stop again to resume
BATTERY STATUS
3
Indicates how much charge is in battery
4
TIME BUTTON
Used to set length of treatment time
5
STATUS INDICATOR
•
Power is on
•
Treatment in progress
•
Error indication
6
PRESSURE DIAL
Light – 20 to 35 mmHg
Medium – 40 to 65 mmHg
Intense – 70 to 100 mmHg
DC ADAPTER SOCKET
7
Used for connecting the universal power adapter
8
AIR CONNECTION PORTS (2)
Used to connect garments to the pneumatic console
9
AIR CONNECTION BLOCKER PLUG
Use blocker plug when only one garment is in use
Mueller Sports Medicine, Inc., One Quench Dr., P.O. Box 99, Prairie du Sac, WI 53578, USA
800-356-9522, Fax 800-852-4334, www.MuellerSportsMed.com
Scan for complete
7
1
(On Back)
3
5
4
6
9
instructions
2
8
L98207MR-A
