  • Page 1 To learn more about EMAC’s products and services and how they can help your project http://ftp.emacinc.com/Tech_Info/About_EMAC_Products_and_Services.pdf Authorized Distributor, Integrator, and Value-Added Reseller Manual downloaded from ftp.emacinc.com For purchase information please contact info@emacinc.com For technical support please submit a ticket at...
  • Page 2 CPC-2400 Mini Biscuit PC Development Board User’s Manual...
  • Page 3 Copyright notice This document is copyrighted, October 1999. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 4 Product warranty Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for one year from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
  • Page 5 If any of these items are missing or damaged, contact your distributor or sales representative immediately. Technical support and sales assistance If you have any technical questions about the CPC-2400 or any other Advantech products, please visit our support website at: http://support.advantech.com.tw...

  • Page 6: Table Of Contents

    Contents Chapter 1 Hardware Configuration ......1 Introduction ..............2 Specifications ..............2 Safety precautions ............3 Jumper settings ............4 1.4.1 LCD shift clock select (J1) ........5 1.4.2 LCD 3.3/5 V select (J2) ........5 1.4.3 Reset switch (J4) ........... 5 1.4.4 VGA source select (S1) ........
  • Page 7 Appendix A Pin Assignments ........ 15 Parallel port connector (CN1) ..........16 24-bit LCD display connector (CN2) ........17 36-bit LCD display connector (CN3) ........18 CRT display connector (CN7) ..........19 Floppy drive connector (CN11) ........... 20 IDE hard drive connector (CN12) ........21 COM1 RS-232 serial port (CN13)........
  • Page 8 Table 1-2: LCD 3.3/5 V select (J2) ..............5 Table 1-3: VGA source select (S1) ..............5 Table 2-1: Connectors ..................9 Table 2-2: CPC-2400 serial port default settings ........... 12 Table A-1: Parallel port connector ..............16 Table A-2: 24-bit LCD display connector ............17 Table A-3: 36-bit LCD display connector ............

  • Page 9: Chapter 1 Hardware Configuration

    Hardware Configuration This chapter gives background informa- tion on the CPC-2400. It shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Card specifications • Safety precautions • Jumper settings...

  • Page 10: 1.1 Introduction

    1.1 Introduction The CPC-2400 is a development board designed with a SODIMM socket for a mini biscuit and connectors for functions such as VGA, LCD, LAN, FDD, IDE, PC/104, ISA and a printer port. The CPC-2400 can help users to design their own board easier.

  • Page 11: 1.3 Safety Precautions

    1.3 Safety precautions The following sections tell how to make each connection. In most cases, you will simply need to connect a standard cable. All of the connector pin assignments are shown in Appendix A. Warning! Always completely disconnect the power cord from your chassis whenever you are working on it.

  • Page 12: 1.4 Jumper Settings

    Closed Closed Closed 2 - 3 Closed 2 - 3 Closed Closed Closed Closed 2 - 3 Closed 2 - 3 Closed 2 - 3 Open Open Open Open Open CPC-2400 User's Manual...

  • Page 13: Lcd Shift Clock Select (J1)

    1.4.1 LCD shift clock select (J1) This jumper is used to decide clock phase. "Shift clock -" is the negative phase of "Shift clock". Table 1-1: LCD shift clock select (J1) Function Pins 1-2 Pins 2-3 Shift clock Closed Open Shift clock - Open Closed...
  • Page 14 CPC-2400 User's Manual...

  • Page 15: Chapter 2 Connecting Peripherals

    Connecting Peripherals This chapter tells how to set up the CPC-2400 hardware, including connect- ing peripherals, switches and indicators.

  • Page 16: 2.1 Board Layout: Connector Locations

    2.1 Board layout: connector locations CPC-2400 User's Manual...

  • Page 17: Table 2-1: Connectors

    The following table lists the connectors on the CPC-2400. Table 2-1: Connectors Number Function Parallel port connector LCD 24-bit connector LCD 36-bit connector SODIMM socket LCD FPC connector VGA/COM/KB/MS FPC connector VGA connector Ethernet connector CN10 VGA FPC connector CN11...

  • Page 18: Floppy Drive Connector (Cn11)

    2.2 Floppy drive connector (CN11) You can attach up to two floppy disk drives to the CPC-2400 on-board connector. You can use any combination of 5.25" (360 KB / 1.2 MB) and/or 3.5" (720 KB / 1.44 / 2.88 MB) drives.

  • Page 19: Lcd Inverter Connector (Cn22)

    LCD brightness control and can be adjusted via R6 or R7. 2.7 VGA display connector (CN7) The CPC-2400 provides a VGA controller for a high resolution VGA interface. The CPC-2400's CN7 is a DB-15 connector for VGA monitor input. Pin assignments for the CRT display are detailed in Appendix A.

  • Page 20: Serial Ports (Cn13: Com1/Rs-232; Cn14: Com2/Rs-232)

    2.10 Serial ports (CN13: COM1/RS-232; CN14: COM2/RS-232) The CPC-2400 offers two serial ports: COM1 in RS-232 and COM2 (CN13: RS-232, CN14:RS-232). These ports let you connect to serial devices (a mouse, printers, etc.) or a communication network. You can select the address for each port (for example, 3F8H [COM1], 2F8H [COM2]) or disable each port..

  • Page 21: Keyboard And Ps/2 Mouse Connector (Cn17)

    6-pin mini-DIN connector to a standard DIN connector and to a PS/2 mouse connector. 2.13 ISA slot (CN19 ~ 21) The 16-bit ISA slot are used for connecting the CPC-2400 to an ISA expansion card. 2.14 Enhanced IDE connector (CN12) You can attach two IDE (Integrated Device Electronics) drives to the CPC-2400.
  • Page 22 CPC-2400 User's Manual...

  • Page 23: Appendix A Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Parallel port connector • 24-bit LCD display connector • 36-bit LCD display connector • CRT display connector • Floppy drive connector • IDE hard drive connector •...

  • Page 24: Parallel Port Connector (Cn1)

    Parallel port connector (CN1) Table A-1: Parallel port connector Signal \STROBE \ACK BUSY SLCT AUTOFD INIT SLIN CPC-2400 User's Manual...

  • Page 25: 24-Bit Lcd Display Connector (Cn2)

    24-bit LCD display connector (CN2) 3 ..Table A-2: 24-bit LCD display connector Signal Signal VDDSAFE5 VDDSAFE5 VDDSAFE3 VDDSAFE3 Vcon SHIFT CLOCK FILM ENABKL ENAVEE Note: The model number of the CN2 socket is DF13A-40DP-1.25V (Hirose Electric Co., Ltd.) Appendix A Pin Assignments...

  • Page 26: 36-Bit Lcd Display Connector (Cn3)

    36-bit LCD display connector (CN3) ..18 Table A-3: 36-bit LCD display connector Signal Signal Note: The model number of the CN3 socket is DF13A-20DP-1.25V (Hirose Electric Co., Ltd.) CPC-2400 User's Manual...

  • Page 27: Crt Display Connector (Cn7)

    CRT display connector (CN7) Table A-4: CRT display connector Signal Signal GREEN BLUE H-SYNC V-SYNC Appendix A Pin Assignments...

  • Page 28: Floppy Drive Connector (Cn11)

    Table A-5: Floppy drive connector Signal Signal DENSITY SELECT* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active CPC-2400 User's Manual...

  • Page 29: Ide Hard Drive Connector (Cn12)

    IDE hard drive connector (CN12) Table A-6: IDE hard drive connector Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15...

  • Page 30: Com1 Rs-232 Serial Port (Cn13)

    COM1 RS-232 serial port (CN13) Table A-7: COM1 RS-232 serial port Signal CPC-2400 User's Manual...

  • Page 31: Com2 Rs-232 Serial Port (Cn14)

    COM2 RS-232 serial port (CN14) Table A-8: COM2 RS-232 serial port RS-232 port RS-232 port Keyboard and mouse connector (CN17) Table A-9: Keyboard and mouse connector Signal KB DATA MS DATA KB CLOCK MS CLOCK Appendix A Pin Assignments...

  • Page 32: At Power Connector (Cn18)

    AT power connector (CN18) Table A-10: AT power connector Signal +5 V +12 V LCD power inverter (CN22) Table A-11: LCD power inverter Signal +12 V ENABKL CPC-2400 User's Manual...
