TREASURE GOLD PLUS
BATTERY
•
The control box is powered by a 9-volt battery located at the bottom of the control
box.
•
Lift the cover, pull out the battery connector cable, insert the battery, and close the
lid.
•
The equipment can work as long as the LED indicator is on.
•
It is recommended to use rechargeable batteries.
ANTENA LOCATOR
•
The antenna locator works with a 9-volt battery.
•
It is recommended to use a rechargeable battery.
SYSTEMS
GOLD DISCRIMINATION
Gold System
To select the next Gold mode, turn on the device at the LOCATOR ANTENNA position, then set
the selector lever to the ON GOLD position.
In this mode, you will be able to detect only gold by employing the antenna.
DISCRIMINATION System
To select the DISCRIMINATION system, turn on the instrument where LOCATOR ANTENNA is
displayed, then set the selector lever to the ON DISCRIMINATION position.
With the DISCRIMINATION function, you can select the type of metal you want to detect, such
as:
IRON
COPPER
BRONZE
GOLD JEWEL COIN
SILVER
GOLD FINE /MINERAL GOLD, GOLD NUGGETS, GOLD BULLION
IONIC SENSOR
TREASURE GOLD PLUS 2021
BIRTBE DETECTORS
OPERATING MANUAL
BURIED TREASURE DETECTOR
Advertisement
Table of Contents
Summary of Contents for Detector Power TREASURE GOLD PLUS 2021
- Page 1 TREASURE GOLD PLUS 2021 BIRTBE DETECTORS OPERATING MANUAL BURIED TREASURE DETECTOR TREASURE GOLD PLUS BATTERY • The control box is powered by a 9-volt battery located at the bottom of the control box. • Lift the cover, pull out the battery connector cable, insert the battery, and close the lid.
- Page 2 The ionic system can detect the ions produced by noble metals such as gold and silver. To perform the prospecting with this system, first, turn on the equipment with the LOCATOR ANTENNA lever, then increase the sensitivity regulator to a sensitive point. This detection system is efficient in dry soils (not humid) where the metals react with the sun's temperature and release the ions detected by the equipment.
- Page 3 Performance Demonstration Metals that you will need to perform the test practices: 1- Un objeto de hierro, cobre, plata, oro. An object of iron, copper, silver, or gold. Bury each of these metals in different places at a maximum depth; keep in mind that this equipment can detect up to 60 meters deep.
- Page 4 TEST TO CHECK THE DEPTH The buried metal object produces magnetic radiation. The depth of the buried object is the same distance that produces magnetic radiation. To know the depth of the metal, the following process must be performed: Once you have located the center of the target, you should stand on top of the center, and point your antenna towards the ground, then raise the antenna until it reaches the level, and walk straight from the detected center towards the north, keep the antenna level and at the moment the antenna turns back as to go back to the center, you should point from that place...
