- Page 1 INfaa028_US_CA 370-102 370-104 CHI L DREN ELECTRI C MOTORCYCLE MANUAL Suitable age 37-95 months. This product should be assembled by adult. This instruction contains important safety information content,please keep it as a reference. ASSEMBLY INSTRUCTION...
-
Page 2: Specifications
About the products Thank you for choosing our children electric car.We always keep pursuing being outstanding and designing comfortable and safe ride on car for children.Let Beisida children carriage be with every children's growth. Please read this instruction carefully before use,it will tell you the right way of assembling and operating.To avoid incorrect operations damaging the product or injuring your children. - Page 3 Q'ty Q'ty Part Part Part Part Part Picture Picture (pcs) (pcs) Number Number Name Name Name Front Foot wheel board Right Left rear rear wheel wheel (Plum) Front Front axle Rear Rear axle Front Screw fork parts Wrench Charger CHI L DREN' S ELECTRI C CAR I N STRUCTI O N Pl e ase read thi s i n structi o n careful l y before use.
- Page 4 Explosion map Main body Front fork Front fender Head stock Faucet Rear axle Right rear wheel Rear cap Gasket Front axle Front cap Front wheel Left rear wheel...
- Page 5 Assembling The vehicle should be assembled by adult before use.It will take 30minutes to complete. The small parts might cause choke,please keep away from the children. Please check the number of the parts before assembling,and keep the packaging bags away from the children in in case of choke. Wire terminal 1.Installation of head Connect the wire terminal with the body, then clip the two feet of the head...
- Page 6 Front Fender Front cap Gasket Front cap Front Gasket fork Front wheel Front axle 3.Front wheel mounting Figure take off the front axle, the fender set in the front fork pipe. Turn the front axle from left to right through the gasket, front fork tube, gasket, front wheel, gasket, front fork tube, gasket, and then put a nut at both ends of the front axle, and then tighten with a wrench.
- Page 7 License plate 5.Installation of license plate As shown in the picture, the license plate is inserted into the corresponding hole of the car body , and the license plate is fixed in the body with the self tapping screw. 6.Pedal installation Pedal board in the groove on the body , to ensure that it has been installed in place, not easy to fall...
-
Page 8: How To Operate Your Vehicle
GIVE SAFETY EDUCATION BEFORE USE 1.To avoide harmed by the little spare partsl ,less than 3years old can't drive. 2.Assembled and charged Only by adult, 3.The max loading is 25 kgs,suitabal for 37-95 months old children. Do not over loading for safety. 4.This product is not traffic tool,keep driving on hard and flat ground. - Page 9 Please sit on the seat when driving. Only one child drive every time. Driving must be under the adult supervision Note the driving in safe place,keep driving on hard and flat grount, DO not drive in dangerous places. a.ditch pit,river side,slopes or other uneven ground. b.Beside the road or other places for cars and people walking.
- Page 10 CHARGE This product charge should by adult for safey. Before first use should open the seat,the line s connected(red to red, black to black)please charge at least 8-12 hours. The charging jack is on the fuel tank cap,the steps as follows: When drive slow,should charge 8-12 hours in time,can't be over 20 hours.
-
Page 11: Maintenance
MAINTENANCE 1.Check the main parts regularly,check if there's any damage of the battery,charger,plug,cover and the other parts,check if the screws are tight,check if the wire lead is old .If any damage, please stop use and deliver to the professional service. 2.Clean the iron parts with little lubricating oil after a time of use to avoid rust. - Page 12 MALFUNCTION ELIMINATES: 1,Check whether the power switch is off. 2,Check whether the forward/backward switch is in the neutral gear (in the middle) 3,Check the fuse is damaged,if so ,change it. Vehicle 4,Check whether the battery wires are couldn't connected well? move 5,Charger's dc in the charging socket will make it not work,if so ,take it out.
