Summary of Contents for Netafim Elevate Series
- Page 1 Elevate Series Horticulture Luminaires Installation Manual...
- Page 2 PRODUCTS AND THE ASSOCIATED DOCUMENTATION, THEY MAY STILL INCLUDE FAULTS. NETAFIM™ WILL NOT ACCEPT RESPONSIBILITY FOR DAMAGE RESULTING FROM USE OF NETAFIM'S PRODUCTS OR USE OF THIS MANUAL. NETAFIM™ RESERVES THE RIGHT TO MAKE CHANGES AND IMPROVEMENTS TO ITS PRODUCTS AND/OR THE ASSOCIATED DOCUMENTATION WITHOUT PRIOR NOTICE. FOREIGN LANGUAGES...
- Page 3 Elevate Horticulture Luminaires Elevate yield and other crop characteristics with the industry's highest performing spectrally tunable grow light. Specs & Recommendations • Industrial UL Class P programmable power supplies • Input Voltage: 90~305Vac (480Vac available – contact manufacturer) • High Efficiency Industrial LED Driver: ~ 93% •...
-
Page 4: Getting Started
Getting Started PARTS & ACCESSORIES Elevate 8F Lightbar A (4) Mounting Rails (3) Lightbar B (4) LED Driver Power Supplies T-Slot Cable Routing Clips (24) Elevate 4V Mounting Rails (3) LED Driver Power Supplies Lightbar B (4) T-Slot Cable Routing Clips (12) Accessories Fixture Mounting DC Cable... -
Page 5: Best Practices
Best Practices MOUNTING & OPERATING Preparation Unpack, count, and confirm all parts per packing slip. 2. Identify and confirm main power voltage and receptacle type. 3. Ensure lightbars are mounted in the correct quantity and position on the mounting rails. Connect female (output) end of DC splitters to male (input) cable of appropriate lightbars. -
Page 6: Operation
A standard commercial 0-10V dimming control may be used to manually control the Elevate power supplies via the Netafim Power Supply purple (dim+) and gray (dim-) control leads. {Note that pending NEC wire color codes will necessitate transition from gray to pink on the (dim-) lead.} Manual dimming controls will generally make it difficult to identify and repeat a given dim level or spectrum mix. -
Page 7: Maintenance
Warranty / Product Guarantee Netafim, Inc. is committed to the success of our grower partners. We strive together with our customers for 100% satisfaction. If anything in your order is wrong, we will make it right. We back this commitment with a five-year warranty on all Netafim light bars and Power Supplies. - Page 8 Grow Lights Product Description Units Part No. Component Details Fully assembled; 8-Bar High Performance Vertical Flower Ready to mount; Spectrum 16 units/pallet Elevate-8F See included Grow Light Tunable Bloom Light accessories below Fully assembled; Vertical Vegetative 4-Bar High Performance Ready to mount; 16 units/pallet Elevate-4V Veg Light See included...
- Page 9 NETAFIM LIGHTING 04/22...
