- Page 1 16E1 Fiber Optical Multiplexer User’s Manual...
-
Page 2: Table Of Contents
16E1+4ETH Optical Multiplexer CONTENTS 1 General information ..........................2 2 product character ............................2 3 Technical index ............................3 3.1 Environment requirement ......................3 3.2 Power supply ........................... 3 3.3 Consumption ........................... 3 3.4 E1 interface ............................3 3.5 10/100Base-T Port .......................... 3 3.6 RS232/Console port ........................ -
Page 3: General Information
FPGA chips and it is easy to upgrade. It is single board structure and the largest transmission capacity is 16E1 and 4*100M line Ethernet data. the Ethernet bandwidth is set on base on multiple of 32K.The outer design use the standard 19 inches rack, so the volume is small, weight is light and operation is convenient and credit. -
Page 4: Technical Index
16E1+4ETH Optical Multiplexer 3 Technical index 3.1 Environment requirement Operating temperature: -10°C ~ 60°C Storing temperature: －40°C ~ +85°C Relative humidity: 95 % 3.2 Power supply AC220V：input voltage AC 100V～260V DC-48V：input voltage -72V～-36V 3.3 Consumption consumption: ≤ 10W 3.4 E1 interface... -
Page 5: Rs232/Console Port
16E1+4ETH Optical Multiplexer Connector: RJ45 3.6 RS232/Console port Rate： 9600Kbps (Asynchronous) Interface characteristic： Satisfies ITU-T V.24 standard Connector：RJ45 3.7 Optical interface Optical wavelength: 1310nm/1550nm for single-mode optic interface for option 850nm/1310nm for multi-mode optic interface for option Optical interface: SC/FC/ST for option... -
Page 6: Function
16E1+4ETH Optical Multiplexer 4 Function 4.1panels... - Page 7 16E1+4ETH Optical Multiplexer...
-
Page 8: Led
16E1+4ETH Optical Multiplexer 4.2 LED Color Status Description LPWR Green The local device is power on. RPWR Green The remote device is power on. Green F1 fiber port is linked. Green F2 fiber port is linked. On means connect normal, flick means date receive and... -
Page 9: Ethernet
16E1+4ETH Optical Multiplexer Shield Ch.16 E1 warning Shield the Ch.15~16 E1 warning Shield the Ch.14~16 E1 warning Shield the Ch.13 ~16 E1 warning Shield the Ch.12~16 E1 warning Shield the Ch.11~16 E1 warning Shield the Ch.10~16 E1 warning Shield the Ch.9~16 E1 warning Shield the Ch.8~16 E1 warning... -
Page 10: E1 Interface
16E1+4ETH Optical Multiplexer 4.8 E1 interface It support BNC( 75ohm) or RJ45 (120ohm) RX: 75Ω unbalance E1 input TX: 75Ω unbalance E1 output RJ45 pins as following: 4.4 Ethernet This multiplexer can offer 2 channels for 10/100M ,full/duplex auto-negotiation LAN interface, support VLAN protocol, this interface can continuous learn MAC addresses in the LAN that connected with it, and send the address as frame in another LAN. -
Page 11: Console Port
16E1+4ETH Optical Multiplexer Ethernet buffer memory: 64Mbits SDRAM Physical interface: RJ45 slot, support AUTO-MDIX Ethernet operating diagram: Ethernet RJ45 ports connection: 4.5 Console port For 4-Ethernet VLAN operation. - Page 12 16E1+4ETH Optical Multiplexer This is for PC hyper-terminal control.
-
Page 13: Hot Line Phone
16E1+4ETH Optical Multiplexer 4.6 Hot line phone Please connect to telephone set. For point-to-point application, when off- hook at any side, the other one will ring. Then the user at the other side should also off-hook to answer. 4.9 Power supply Dual power supply: AC220V and DC-48V：... -
Page 14: Installation
16E1+4ETH Optical Multiplexer 5 Installation 5.1 Equipment installation After unpacking and before installation, make sure checking the following: Make sure the package is well. If the package is damaged, contact service office quickly for solution. Check the package according to the product list, if find equipment severe damaged or lack of some components, please contact installation worker or service office of us. -
Page 15: Cautions About Installation
16E1+4ETH Optical Multiplexer manual). A clean, steady environment and firm installation should be provided for desktop or wall hanging equipment. 5.1.2 Cautions about installation Avoid severe liberation and mechanical damage during the process of delivering and installation. Arrange fiber appropriately, fiber bending radius≥50 mm. -
Page 16: Package
AC220 Power wire -----------------------------------------------1 User’s manual-----------------------------------------------------1 Note： 16E1+4ETH Optical Multiplexer is a sensitive electronic item, please do handle with care when carrying or delivering and pay attention to against humidity. This unit will be warranted for 1 year.
