The HDMI over IP Extender kit boosts or extends the video/audio transmission distance over 100 meters in
HDTV 1080p format to the display(s), linking with Gigabit Ethernet Switch. This unit provides a convenient
and cost effective solution to transmit high quality audio visual signals from the source to HDTVs at a remote
location and/or when integrating with several home theater devices/equipments.
This item is applicable to the following:
1) one to one signal extension
2) matrix connection
3) Video/Audio Broadcasting
4) Digital Signage
5) TV Wall
6) Multi-Casting
Package Includes:
HDMI Transmitter x 1
HDMI Receiver x 1
5V Switching Power Supply x 2
User's Manual x 1
Features:
Compatible with HDMI V-1.3b, DVI 1.0 and HDCP 1.2
HDCP Compliant
Supports max. video resolution: 1920x1200@60Hz (digital), 1600x1200@60Hz (analog)
Supports high resolution video: 480i, 480p, 720p, 1080i, 1080p,
Delivers video/audio signal through a single standard Ethernet cable
Extends signals up to 100 meters from the source at 1080p or longer (linking with Gigabit Ethernet Switch)
High Speed compression to guarantee low latency and excellent picture quality
Audio -> System: Stereo L/R
Sampling Rate: 48KHz
Resolution: 16bits
Supports Refresh Rate: 24Hz, 30Hz, 60Hz
Allows and enables you to learn and reset EDID
LED indications for operation modes
Plug-and-Play installation
Supports DVI with HDMI-to-DVI adapter
Supports castcading
Allows for group transmission (one TX unit to max.256 RX units - Max.: 16 groups)
The most cost effective solution for one-to-one, one-to-many, and many-to-many signal extension
Easy to install and simple to operate and the most effective solution for long signal extension.
Ideal for video broadcasting, remote monitoring, conferencing, educational facilities.
Technical Specifications
• Video Bandwidth: 10.2 Gbps (HDMI 1.3b)
• Input TMDS signal: 1.2 volts (peak-to-peak)
HDMI Over IP Extender (EC-HE3115-IP)
Advertisement
Table of Contents
Related Manuals for Ever Connect EC-HE3115-IP
Summary of Contents for Ever Connect EC-HE3115-IP
- Page 1 HDMI Over IP Extender (EC-HE3115-IP) The HDMI over IP Extender kit boosts or extends the video/audio transmission distance over 100 meters in HDTV 1080p format to the display(s), linking with Gigabit Ethernet Switch. This unit provides a convenient and cost effective solution to transmit high quality audio visual signals from the source to HDTVs at a remote location and/or when integrating with several home theater devices/equipments.
- Page 2 • Weight: 1 kg (Transmitter + Receiver) • Dimensions: 108mm x 75mm x 25mm / 4.2” x 3”x 1” (L x W x H) Specification: Product HDMI Over Single Cat. 5 IP Extender (EC-HE3115-IP) HDMI Version 1.3b HDMI Source Input Port...
- Page 3 Front Panel of the Transmitter 1) 4-dip Switch for group (many-to-many) connection – maximum 16 groups 2) IR receiver 3) LED – Green Flashing – linking in progress...
- Page 4 Green｀ON＇- Connection established and in operation 4) Power LED 5) Link Button Switch – short press – on/off to remote connection long press – on/off for a local TV display 6) Reset Button 7) Firmware update (with PC) 8) DC Jack 9) RJ45 Jack 10) HDMI –...
- Page 5 12) HDMI – output for connecting with a remote TV 13) RS-232 Control – Serial over IP for multi-casting/signage application 14) IR Extension – Extension over Cat. 5e cable Set-up for Group Connection 1) This product supports 16 transmitters for group connection, using 4-Dip switch. It works as a matrix switcher.
- Page 6 copper cables will result in no or poor resolution. The HDMI Repeater is recommended to use for a distant connection - over 15ft. 3. Make sure all HDMI connectors are tightly secured to all HDMI ports. 4. Turn off and again, turn on all the equipments. 5.
