Cornwell Tools CSE1500 Operating Manual

1500 lb. engine sling
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

OPERATING MANUAL

SPECIFICATIONS

Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500 Lb.
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . .14.3 Lbs.
Manufactured to comply with the
ASME PASE-2019 Safety Standard
CSE1500
•
1500 Lb. Engine Sling
PARTS LIST
•
Copyright © Professional Tool Products, 2020
1
CSE1500
All rights reserved
04/16/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSE1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cornwell Tools CSE1500

  • Page 1 CSE1500 1500 Lb. Engine Sling OPERATING MANUAL WARNING INFORMATION PARTS LIST • • SPECIFICATIONS Capacity ....... 1500 Lb.
  • Page 2 CSE1500 1500 Lb. Engine Sling WARNING INFORMATION This is the safety alert symbol. It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards. Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury.
  • Page 3 CSE1500 1500 Lb. Engine Sling OPERATING INSTRUCTIONS This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to potential personal injury hazards. Obey all instructions to avoid possible injury. The load leveler is designed to be used with a portable shop crane to handle and position engines and other large vehicle components. The drive screw adjusts the sling's lift point in relation to the mounting chains to compensate for off-center loads, or adjusts to a certain angle for component removal or installation.
  • Page 4 CSE1500 1500 Lb. Engine Sling WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEAR from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials.
