- Page 2 250ft roll of four conductor speaker cable (4) x OS800 800 watt outdoor speakers Water resistant junction box with wire nuts If any piece is damaged or missing, please call Carillon Technical Support at 1-800-295-0220 or email us at carillonsupport@brgproducts.com CBS6000 Quick Start Guide ©2022...
- Page 3 CBS6000 Quick Start Guide ©2022...
- Page 4 Next, wire the Junction Box. The Junction Box will have two terminal blocks labeled “RED (+)” and “BLACK (-).” You will connect all positive wires to the block marked “RED (+)” and all negative wires to “BLACK (-).” CBS6000 Quick Start Guide ©2022...
- Page 5 Strip back ¼ to ½ inch of each wire exposing the core. Use a small screwdriver or similar tool to open each terminal by pushing straight back on the corresponding white tab. This will open the terminal and you can place the stripped end of the wire through. CBS6000 Quick Start Guide ©2022...
- Page 6 INSTRUCTED BY BRG TECHNICAL SUPPORT DO NOT SET A PASSWORD FOR THE COMPUTER DO NOT PUT THE COMPUTER TO SLEEP THE CARILLON COMPUTER SHOULD RUN 24/7 AND WILL AUTOMATICALLY RESTART EACH MORNING TO PERFORM SELF-CHECK FUNCTIONS AND CLEAR ANY FAULT CBS6000 Quick Start Guide ©2022...
- Page 7 Desktop Speakers to the included power strip. Make sure the switch on the power strip is in the “ON” position. You should see a red light on the Relay, as well as power to the desktop speakers. Step 5: Turn on the computer. CBS6000 Quick Start Guide ©2022...
- Page 8 Wire nut the red and black speaker wire from the junction box to the Speakon cable “pig tail.” NOTE: The black wire with the texture or without writing on the “pig tail” is the negative (black). CBS6000 Quick Start Guide ©2022...
- Page 9 Once set, the amplifier will shut off on its own. Leave everything powered on and the preprogramed bell schedule should automatically play. Thank you!!! ______________________________________ We hope you enjoy your BRG Carillon System. If you have any questions, comments, or concerns do not hesitate to reach out by calling 1.800.295.0220 CBS6000 Quick Start Guide ©2022...
